Ricoh D182 Manuel

OR-C2 Training

Slide 1 Version 1.0

D182/D183/D184

Service Training

OR-C2

This course explains the new series of middle-range copiers OR-C2.

OR-C2 Training

Slide 2

Appearance

ARDF: Standard for

some models

Optional finisher

Optional one-

bin Tray

Optional two-tray

feed unit

No additional notes

OR-C2 Training

Slide 3

D182/D183/D184

Service Training

Product Overview

This section provides an overview of the machine, and the options that can be

installed.

OR-C2 Training

Slide 4

What Models are there in the Series?

Comparing Basic Specifications

OR-C2a (D182)

25 cpm

OR-C2b (D183)

30 cpm

OR-C2c (D184)

33 cpm

Controller: GW+

Contains new features introduced with the latest models

that use this controller

Java VM is standard (built into the controller)

USB/SD slots built into the operation panel

Memory

Basic models (no scanner or printer kits built in)

» 512 MB memory, no HDD

SP models (with scanner and printer kits built in)

» 1.5 GB memory, 250 GB HDD

No additional notes

OR-C2 Training

Slide 5

What Models are there in the Series?

Regional Variations in Standard Models

2 models

1) Basic model, no

ARDF, normal

operation panel

2) SP model, no

ARDF, normal

operation panel

2 models

1) Basic model, no

ARDF, normal

operation panel

2) SP model, no

ARDF, normal

operation panel

3 models

1) Basic model, no ARDF, normal

operation panel

2) SP model, ARDF, normal

operation panel

3) SP model, ARDF, Smart

operation panel

SP model only

ARDF is standard;

Smart Operation

Panel is option

C2c

2 models

1) Basic model, no

ARDF, normal

operation panel

2) SP model, no

ARDF, normal

operation panel

2 models

1) Basic model, no

ARDF, normal

operation panel

2) SP model, no

ARDF, normal

operation panel

3 models

1) Basic model, no ARDF, normal

operation panel

2) SP model, ARDF, normal

operation panel

3) SP model, ARDF, Smart

operation panel

SP model only

ARDF is standard;

Smart Operation

Panel is option

C2b

1 model

SP model , no

ARDF, normal

operation panel

1 model

SP model , no

ARDF, normal

operation panel

2 models

1) SP model, ARDF, normal

operation panel

2) SP model, ARDF, Smart

operation panel

SP model only

ARDF is standard;

Smart Operation

Panel is option

C2a

RCNRARERAC

Basic models can be upgraded with one or more of the following options:

Printer Unit Type M7

Scanner Enhance Option Type M7

Printer/Scanner Unit Type M7

Hard Disk Drive Option Type M7

Memory Unit Type M1 1.5GB

No additional notes

OR-C2 Training

Slide 6

Comparing Specifications with OR-C1

80 ipm (A4), 79 ipm (LT)50 ipmScanning Speed (max)

4.54.54.54.54.55.4First Copy Time

300 dpi200 dpiScanning Resolution

w/ HDD: 15.5 s, w/o HDD 14.5 sw/ HDD: 20 s, w/o HDD: 14 sWarm-up Time

31503150Paper Feed Capacity (max)

11501150Paper Feed Capacity (standard)

250 GB120 GBHDD

1.5 GB1 GBRAM (maximum)

9 inches8.5 inchesOperation panel

333025332823CPM

cbacba

OR-C2OR-C1

No additional notes

OR-C2 Training

Slide 7

Changes to the Engine

The machine is the same as the OR-C1, except for the

following points:

Scanner: This is the same as the MET-C1.

SBU board: This is also the same as the MET-C1.

Operation panel: This has been increased from 8.5 inches

to 9 inches. This is also the same as the MET-C1.

Boards: A GW+ controller is used. The BCU and IPU have

been changed.

Main switch: This is the same type as CH-C1 and MET-C1.

This means that the method of turning power off before

removing machine components is different from OR-C1.

The metal frame was modified because of the changes to

the scanner, controller board, and main PCBs.

No additional notes

OR-C2 Training

Slide 8

Yield of Consumables

Toner cartridges

360 g

11 k prints

Same toner as OR-C1

Yields are based on these conditions:

A4 (LT) long-edge feed

5% image coverage ratio

OR-C2 Training

Slide 9

Targets

Average Print Volume

OR-C2a: 4 k/month

OR-C2b: 5 k/month

OR-C2c: 7 k/month

No additional notes

OR-C2 Training

Slide 10

Reliability Information

PM Interval

Components of the PCU: 60k

Others: 120 k

MPBF Target (Mainframe)

OR-C2a: 102.6 k

OR-C2b: 106.4 k

OR-C2c: 111.1 k

Call Ratio Target (Mainframe)

OR-C2a: 0.039

OR-C2b: 0.047

OR-C2c: 0.063

Machine Life

OR-C2a: 900k or 5 years

OR-C2b: 1,200k or 5 years

OR-C2c: 1,800k or 5 years
