Chapter

Before Using the Camera ........................ 22

Checking the Package Contents .................. 22

Installing the strap and lens cap ................... 22

Powering the Camera .............................. 23

Charging the Battery ..................................... 23

Loading the Battery ....................................... 24

Using an AC Adapter .................................... 26

SmartMedia Memory Cards ..................... 27

What is a SmartMedia Memory Card? ......... 27

Inserting a SmartMedia Memory Card.......... 28

How to Use the Mode Dial ....................... 30

Menus....................................................... 31

Setting the Date and Time ....................... 34

How to Hold the Camera.......................... 36

Adjusting the Camera............................... 38

Diopter Adjustment........................................ 38

Adjusting the Brightness of the

LCD Monitor .................................................. 38

GETTING STARTED

Before Using the Camera

Checking the Package Contents

Check that your digital camera comes complete with all the accessories listed

below. Read the warranty card and keep it in a safe place.

• Digital camera ...................................... 1

• Lens cap .............................................. 1

• AV interface cable................................ 1

• Soft case .............................................. 1

• Battery (Lithium ion battery)................. 1

• Battery charger .................................... 1

• Wrist strap............................................ 1

• Operation manual (this manual)........... 1

• Warranty card/Registration card .......... 1

• PC Connection cable (RS-232C) ......... 1

• Macintosh Cable (AUX) ....................... 1

• USB Cable ........................................... 1

• Software CD-ROM ............................... 1

Installing the strap and lens cap

Attach the wrist strap and the lens cap.

Pass the small loop of the strap

through the wrist strap eyelet and

pass the other end through the loop

as illustrated.

Important

Note

• Do not swing the camera around by

its strap.

Attach the lens cap by pressing the

buttons in the direction of the arrow.

Remove the lens cap by gripping and pressing.

Getting Started

Powering the Camera

This section explains how to load and charge the battery, and how to connect

the AC adapter to power the camera from a household electrical outlet.

Charging the Battery

When using the camera for the first time or when the battery symbol ( ) lights,

charge the battery to its full capacity following the procedure described below.

qSet the battery on the battery charger.

wInsert the plug into an electrical outlet.

Charging will start and continue as shown below. When charging is completed,

disconnect the power plug from the power outlet.

■Precautions

•Do not use the batteries other than the Ricoh DB-20.

•Use only a Ricoh BJ-1 battery charger to charge the battery.

•Do not use the BJ-1 battery charger to charge batteries other than the DB-20

battery.

•Charge the battery in a well ventilated area with an ambient temperature of

10°C –40°C (50°F –104°F).

•When the battery reaches the end of its service life, even if charged correctly,

it will be effective for shorter and shorter periods. Replace with a new battery.

•After charging, the battery will feel hot, but this is normal.

•After charging, remove the power plug from the electrical outlet. Failure to do

so may result in fire.

Charge lamp Contents

Lights red Charging has started.

Lights green The completion of charging (90% of full charge), after

approximately 60 min.

Lamp off Full charge has been reached, approximately 40 min. after

the lamp lights green.

Loading the Battery

Load the battery (rechargeable lithium ion battery) before operating the camera.

Important

Note

•Before using the camera for the first time, be sure to charge the

battery. (The battery leaves the factory in an uncharged state.) See

[Charging the Battery] →p.23.

qCheck that the camera is turned off,

and then open the battery cover by

pressing and sliding it in the direction

shown.

See

•“Turning on the Camera”(p.41).

wLoad the battery.

Important

Note

•Do not bring metallic objects, such

as a needle, into contact with the

battery contact surface or electrical

connections. Electrostatic damage

could result.

eClose the battery cover.

Close the battery cover until it clicks into position.

●Shooting and Playback Guidelines

The table below shows the approximate recording and playback times, as

measured under the following test conditions:

[Test conditions]

During shooting: Shoot continuously in recording mode with the power turned

on (shoot at intervals of 30 seconds, without turning the

camera off in the middle, with the flash fired 50%, at a

temperature of 20°C)

During playback:Leave the camera continuously turned on in playback mode at

a temperature of 20°C

Battery Type

Lithium ion battery

(fully charged)

Approximate Recording Time Approximate Playback Time

50 minutes 50 minutes

Getting Started

Tips to Extend Recording and Playback Times

* The battery life indicated on the previous page tends to decrease depending on the

ambient temperature.

In a cold environment, warming the battery by hand, for example, may allow you to

take more pictures.

* Increased use of the flash or zoom feature or the LCD monitor will accelerate

expiration of the battery. Keep their usage to a minimum.

* Copying or erasing images repeatedly will also accelerate expiration of the battery.

* The battery life may be extended by shooting images without using the LCD monitor.

■Handling Precautions

•Read the instruction manual supplied with the battery before using it.

•Use only the specified lithium ion battery. Check the type of battery in

“Accessories”(p.110).

•Cleaning the contact area of the battery terminal and the battery with a dry

cloth may extend the life of the battery.

•Do not use a battery with a low voltage (such as one which has already

caused the battery symbol ( ) to flash) as this may cause malfunction of the

camera (malfunction of the LCD monitor or flashing or lighting of the AF LED,

flash LED or self-timer LED).

•If the camera is used continuously for a long period, the battery may become

hot. Allow to cool before unloading it.

•Except when charging the battery, store the charger and the battery

separately.

•Store the battery in the case provided.

•If the camera is not to be used for a long period, discharge the battery

completely before removing it from the camera and store in a cool place.

Recharge the battery fully before reusing the camera.

Note

•When using the camera for an extended period near an electrical

source, it is recommended to use an AC adapter (optional). See

“Using an AC Adapter”(p.26).

•It is advisable to have a spare battery handy when powering the

camera by the battery alone.

•The battery symbol ( ) lights to show that the battery voltage is low.

Recharge the battery. See “Charging the Battery”(p.23).

Using an AC Adapter

When using the camera for long periods of time to record or playback images,

connect an AC adapter (optional) to the camera and power the camera from a

household electrical source.

Using the AD Adapter

Before using the AC adapter, be sure to read the safety precautions in the

accompanying manual.

qCheck that the camera is turned off. Connect the AC adapter cable

to the power supply terminal (DC input) on the camera.

See

•“Turning on the Camera”(p.41).

wInsert the power plug into the electrical outlet.

Note

•If the battery is loaded in the camera while it is connected to the

household power source, the camera is powered from the AC source

and not by the battery.

•Unload the battery when using the camera for long periods of time.

Important

Note

•Insert the power plug and connection cable securely. If the plug or

cable works loose during recording, the data may be lost or damaged.

•If you connect or disconnect the AC adapter while operating the

camera (recording, playback, or erasing), the camera will switch off to

determine the power source. This may cause the data to be lost or

damaged. To avoid this, connect or disconnect the AC adapter while

the camera is turned off.

Getting Started

SmartMedia Memory Cards

This section explains the types and usage of SmartMedia memory cards.

What is a SmartMedia Memory Card?

Files are recorded as data on the SmartMedia memory card in your camera.

The following types of SmartMedia memory cards can be used:

•Capacity: 2 MB, 4 MB, 8 MB, 16 MB, 32 MB, 64 MB

•Operating voltage: 3.3 V

Note

•There are numerous types of SmartMedia memory cards. Before using

a commercially available SmartMedia memory card, check with the

manufacturer that it is compatible with your camera.

•By using an optional PC card adapter or floppy disk adapter, you can

insert a SmartMedia memory card directly into the PC card slot or

floppy disk drive of your PC.

■Protecting Against Accidental Writing

シールを

貼る

Attaching a write protect pad to a

SmartMedia memory card will prevent

accidental erasure or overwriting of recorded

files.

Remove the write protect pad from the

SmartMedia memory card to record or erase

data.

Note

•If the write protect pad gets dirty, wipe it clean with a soft, dry cloth.

■Handling Precautions

●SmartMedia Memory Cards

•Never remove the SmartMedia memory card while data is being recorded or

erased.

•Do not bend, subject to strong force or shock, or drop the SmartMedia

memory card.

•Avoid using or storing SmartMedia memory cards in environments that are

subject to static electricity or electrical interference.

•Avoid using or storing SmartMedia memory cards in environments that are

subject to high temperature and humidity, where dust accumulates, or in

atmospheres where corrosive substances are present.

Attach a

write

protect

pad.

•Keep the contact surface of the SmartMedia memory card clean and free

from dust and foreign matter. Should the contact surface get dirty, wipe it

clean with a soft, dry cloth.

•Keep the SmartMedia memory card slot free from dust and foreign matter.

•To avoid possible hazards, keep SmartMedia memory cards away from

flames and do not dispose of them in fire.

•SmartMedia memory cards have a limited service life. Cards that have been

used over an extended period of time may fail to record additional files.

●Data

•Data recorded on a SmartMedia memory card may be lost by improper

handling by the customer or a third party, by being subjected to static

electricity or electrical interference, or during camera malfunction or repair.

Ricoh Co., Ltd. assumes no liability for damages incurred by such loss of

recorded data.

•Do not remove the battery from the camera, turn off the camera, or connect

the AC adapter while data is being recorded on the SmartMedia memory

card. The data stored on the SmartMedia memory card may be lost or

damaged.

•You are advised to copy important data from the SmartMedia memory card

onto other media, such as floppy disks or hard disks.

Inserting a SmartMedia Memory Card

Check that the camera is turned off before inserting the SmartMedia memory

card.

Important

Note

•Never insert or remove a SmartMedia memory card while the camera

is turned on. The data stored on the SmartMedia memory card may be

lost or damaged, or the camera may malfunction.

•When using a new SmartMedia memory card, or when using a

SmartMedia memory card that has been used on other equipment,

such as a personal computer, the SmartMedia memory card must first

be formatted (initialized) with the camera. See “Formatting a Card/

Internal Memory”→(p.98).

■Inserting Card

qCheck that the camera is turned off,

and then open the card door.

See

•“Turning on the Camera”(p.41).

Getting Started

wInsert the SmartMedia memory card

into the card insert slot and close the

card door.

Push the SmartMedia memory card fully into

position, with the contact surface facing

down.

Note

•Insert the SmartMedia memory card in the correct direction. Do not

insert it at an angle.

•The camera will not turn on when the card door is open.

■Removing Card

qCheck that the camera is turned off,

and then open the card door.

See

•“Turning on the Camera”(p.41).

wPull the SmartMedia memory card

straight out of the slot.

eClose the card door.

Important

Note

•Never remove the SmartMedia memory card while data is being

recorded or erased. The data stored on the card may be lost or

damaged.

•When the SmartMedia memory card has been removed, place it in the

antistatic case supplied or other protective cover.

Set with the contact

surface facing down

How to Use the Mode Dial

The camera offers a number of recording and playback modes. Select the

desired mode with the mode dial.

•Still picture mode : This mode is used for normal shooting.

•Sound mode : This mode is used for recording sound.

•Text mode : This mode is used for recording text.

Recording is in two colors, black and white,

without any gradations.

•Continuous shooting mode : In this mode, the subject is shot

continuously while the shutter button is

depressed.

•Motion picture mode : This mode is used for recording motion

pictures with sound.

•Play mode : This mode is used for playing recorded

image files.

•Settings mode : This mode is used for entering or changing

the camera settings.

qTurn the mode dial to select the

desired mode.

The information displayed on the LCD

monitor varies depending on the mode. For

details, see the reference pages listed below.

•(still picture) →p.41

•(sound) →p.50

•(text) →p.49

•(continuous shooting) →p.50

•(motion picture) →p.51

•(play) →p.76

•(settings) →p.98

Autres manuels pour RDC-7

Table des matières

Autres manuels Ricoh Appareil photo numérique

Ricoh

Ricoh Aficio G700 Manuel utilisateur

Ricoh

Ricoh G700SE Guide de sécurité

Ricoh

Ricoh RDC-6000 Manuel utilisateur

Ricoh

Ricoh GR Digital II Manuel d'utilisation et d'entretien

Ricoh

Ricoh Caplio R2 Manuel utilisateur

Ricoh

Ricoh Pentax K-3 II Manuel utilisateur

Ricoh

Ricoh Aficio G700 Manuel d'utilisation et d'entretien

Ricoh

Ricoh Caplio 400G wide F Guide de démarrage rapide

Ricoh

Ricoh Pentax K-3 II Manuel utilisateur

Ricoh

Ricoh R8 Instructions de montage

Ricoh

Ricoh AUTO TLS EE Manuel utilisateur

Ricoh

Ricoh Caplio RR660 Manuel utilisateur

Ricoh

Ricoh Pentax K-S1 Mode d’emploi

Ricoh

Ricoh G700SE Manuel utilisateur

Ricoh

Ricoh WG-80 Manuel utilisateur

Ricoh

Ricoh Caplio GX8 Manuel utilisateur

Ricoh

Ricoh Caplio GX Manuel utilisateur

Ricoh

Ricoh THETA Manuel utilisateur

Ricoh

Ricoh EV-G030B1 Manuel utilisateur

Ricoh

Ricoh Pentax K-1 Manuel utilisateur

Ricoh

Ricoh Caplio RR330 Manuel utilisateur

Ricoh

Ricoh GR DIGITAL M Manuel utilisateur

Ricoh

Ricoh Caplio R5 Manuel utilisateur

Ricoh

Ricoh Caplio RR-1 Manuel utilisateur

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

Sony

Sony MCA-20 Manuel utilisateur

Sony

Sony Alpha DSLR-A290 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Sony

Sony A6700 Guide de l'utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur
