Ricoh Singlex Manuel utilisateur
Ricoh Singlex
3-23-2021
This camera manual library is for reference
and historical purposes, all rights reserved.
This page is copyright by , M. Butkus, NJ.
This page may not be sold or distributed without
the expressed permission of the producer.
I have no connection with any camera company.
On-line camera manual library
Back to main camera manual page
If you find this manual useful, how about a donation of $3 to:
M. Butkus, 29 Lake Ave., High Bridge, NJ 08829-1701
and send your e-mail address so I can thank you.
Most other places would charge you $7.50 for a electronic copy
or $18.00 for a hard to read Xerox copy.
This will help me to continue to host this site,
buy new manuals, and pay their shipping costs.
It'll make you feel better, won't it?
If you use Pay Pal, use the link below.
Use the above address for a check, M.O. or cash.
www.PayPal.me/butkus
Venmo @mike-butkus-camera
(Webmaster: This is a bayonet mount lens, manual does not state
which make of bayonet.
Lens looks like a typical heavy Nikon lens. The camera has no built in
light meter)
· CONTENTS
· Taking Your Picture ............... 2
OPERATING INSTRUCTIONS
· Operating Instructions ............ 2
Description of Parts ................. 3
· Loading ................................ 5
· Advancing Film and Winding Shutter .......7
· Setting Shutter Speeds ........................ 8
· Setting the Lens Aperture .................... 8
· Focusing ............................................. 9
· Releasing the Shutter to take Picture .... 10
· Unloading the Film ............................... 11
FURTHER INSTRUCTIONS AND THE USE OF OTHER FEATURES
· Ways to Hold Camera in taking Pictures .... 12
· " Depth of Field " of Photographic Lenses and their Utilization .... 13
· Depth of Field Scale on Lens Barrel ............ 14
· Lever for Previewing Depth of Field ............ 15
· Self-timer ................................................... 16
· Infra-red Marking ...................................... 17
· Changing the Lens ..................................... 17
· Removing the Lens ................................... 18
· Replacing the Lens .................................... 18
· Flash Synchronization ............................... 19
Film Speed (ASA and DIN) Reminder Dial ...... 22
· TAKING YOUR PICTURE
1. Load and advance film until counter registers
"1"
(see page...5~7)
2. Set shutter speed (see page...8)
3. Set Iens Aperture (see page...8)
4. Focus and frame your picture (see page...9)
5. Depress shutter release button
· OPERATING INSTRUCTIONS
Familiarize yourself with your " Singlex ", before loading your first roll of film. Ex. amine your
camera carefully and operate its controls as you would be doing when actually taking pictures. A
patient study of these instructions will be rewarding.
1. Accessory Shoe for exposure meter
2. Neck strap eyelet
3. Combined preview self timer lever
4. Rewind lever (folded)
5. Back cover sliding catch
6. Aperture scale ring
7. Focusing ring
8. Lens releasing lever
9. Cartridge chamber
10. Slotted rewind shaft
11. Tripod socket
12. Sprocket release pin
13. Sprocket teeth
14. Take up spool
15. Eyepiece
16. Syncro sockets
17. Film type reminder
18. Distance scale ring
19. Depth of field scale
20. Aperture distance index diamond mark
21. Shutter speed index dot
22. Shutter speed dial
23. Shutter release and cable release socket
24. Exposure counter
25. Rapid advance lever
· LOADING
Place camera face down on a table or other solid surface. Release the back cover by pulling up its
sliding catch. The back cover will spring part-way open and may be opened fully by hand.
Push upward on the slotted rewind shaft situated inside of the chamber, towards the direction of
arrow shown in the illustration.
Insert the film tongue into the groove of the " take-up " spool as far as it will go. Secure the film on
the take-up spool by turning take-up spool once in the direction of the arrow on the spool.
Place cartridge into the film chamber. Push back and turn the slotted rewind shaft until it engages
the slot in the cartridge spool.
Make sure that the film is secure and that the film perforations are engaged with the sprocket teeth.
Locking is automatic. Now, take up the slack of loaded film by rotating the rewind lever clockwise
until tension is felt. Advance the "exposed" portion of film by winding the rapid advance lever and
tripping the shutter until the counter registers " 1".
Your camera is now loaded and " ready".
A single, full stroke of the film advance
lever, advances the film, counts the
pictures taken and sets the shutter for the
next picture. This operation is done as
follows: 1. Put your thumb on the lever
and turn it fully to the right until it stops.
Do not advance the lever part way only.
· ADVANCING FILM AND WINDING SHUTTER
2. Place your thumb to original
position to catch returning lever.
· SETTING SHUTTER SPEEDS
The desired shutter speed is set by rotating the shutter speed dial to the black dot on the camera top
cover. This may be done before or after the shutter is wound. When set at " B " or bulb, the shutter
will remain open for as long as the shutter release is held depressed. Speeds are: 1, 1/2, 1/4, 1/8,
1/15, 1/30, 1/60, 1/125, 1/500 and 1 /l non second
· SETTING THE LENS APERTURE
The desired aperture opening of lens is
set by rotating the aperture scale ring
on the lens barrel to the red diamond
mark on the "depth of field" ring. The
diaphragm automatically reopens to
full aperture after each shutter release.
Consequently, the field of view visible
before and after the shutter is released.
· FOCUSING
With your "Singlex", which is a single lens reflex camera, focusing and composing is achieved
through the lens, completely eliminating the problem of parallax. The penta-prism system
incorporates a bright fresnel lens for clear viewing even to the corners for perfect composition To
focus, frame the subject to be photographed in the viewfinder and rotate the focusing ring either to
the left or right until the split images merge into one clear image.
