Ricoh AC204 Manuel utilisateur
For safe and correct use of this machine,
please be sure to read the Safety Information
in this manual before you use it.
i
English
Safety Information .................................................. ii
Control Panel Functions ........................................... 1
Changing the Display Language ................................ 4
About the Software .................................................
System Requirements ............................................. 6
Installing the Software ............................................ 7
Removing Software ................................................. 9
Viewing the User’s Guide ....................................... 10
For safe and correct use of this machine,
please be sure to read the Safety Information
in this manual before you use it.
ii
Safety Information
When using this machine, the following safety precautions should always be followed.
Safety During Operation
In this manual, the following important symbols are used:
WARNING:
WARNING:
Indicates a potentially hazardous situation which, if instructions are
not followed, could result in death or serious injury.
CAU ION:
Indicates a potentially hazardous situation which, if instructions are not
followed, may result in minor or moderate injury or damage to property.
• Connect the power cord directly into a wall outlet and never use an
extension cord.
• Disconnect the power plug (by pulling the plug, not the cable) if the power
cable or plug becomes frayed or otherwise damaged.
• o avoid hazardous electric shock or laser radiation exposure, do not
remove any covers or screws other than those specified in this manual.
• urn off the power and disconnect the power plug (by pulling the plug, not
the cable) if any of the following occurs:
•You spill something into the machine.
•You suspect that your machine needs service or repair.
• he external housing of your machine has been damaged.
• Do not incinerate spilled toner or used toner. oner dust might ignite when
exposed to an open flame.
• Disposal can take place at our authorized dealer.
•Dispose of the used toner bottle in accordance with the local
regulations.
iii
English
CAU ION:
Power Supply
The socket-outlet shall be in stalled near the product and shall be easily accessible.
Ozone Safety (if applicable)
Some product (see specification in the Operating Instructions) generates ozone during
operation.
Normally, the ozone level is safe for operators. If ozone odor may appear, ventilate the room.
For Fax or elephone
Do not use this product near water, for example, near a bathtub, wash bowl, kitchen sink or
laundry tub, in a wet basement or near a swimming pool. Avoid using a telephone during an
electrical storm. There may be a remote risk of electric shock from lightning. Do not use a
telephone in the vicinity of a gas leak to report the leak.
Laser Safety:
For North America
CDRH Regulations
This equipment complies with requirements of 21 CFR subchapter J for class 1 laser products.
This equipment contains a milliwatt, 760–800 nanometer wavelength, GaAIAs laser diode.
This equipment does not emit hazardous radiation, since the beam is totally enclosed during
all customer modes of operation and maintenance.
Caution:
Use of controls or adjustment or performance of procedures other than those specified in this
manual might result in hazardous radiation exposure.
• Protect the machine from dampness or wet weather, such as rain and snow.
• Unplug the power cord from the wall outlet before you move the machine. While moving the
machine, you should ta e care that the power cord will not be damaged under the machine.
• When you disconnect the power plug from the wall outlet, always pull the plug (not the
cable).
• Do not allow paper clips, staples, or other small metallic objects to fall inside the machine.
• Keep toner (used or unused) and toner bottle out of the reach of children.
• Be careful not to cut yourself on any sharp edges when you reach inside the product to
remove misfed sheets of paper or masters.
• For environmental reasons, do not dispose of the machine or expended supply waste at
household waste collection points. Disposal can ta e place at an authorized dealer.
• The inside of the machine could be very hot. Do not touch the parts with a label indicating the
“hot surface”. Otherwise, an injury might occur.
iv
Positions of Labels and Hallmarks for
WARNING and CAU ION Labels
This machine has labels for WARNING and CAUTION at the positions shown below. For
safety, please follow the instructions and handle the machine as indicated.
In accordance with IEC 60417, this machine uses the following symbols for the main power
switch:
means POWER ON.
means POWER OFF.
1
English
Control Panel Functions
4
811
10
12
2
7
1
9
356
1
Used to store frequently dialled fax numbers
and dial them with the touch of one button. Also
use in conjunction with the
Menu/Exit
button
to access the corresponding menu function.
Allows you to one-touch buttons to the
locations 21 through 40.
2
F
a
c
s
i
m
i
l
e
Adjusts the resolution of the current fax job
documents.
Used to choose the receive mode. The selected
mode is displayed in Standby mode.
Used to search for a number in the memory.
Also used to delete digits in editing mode.
Used to store frequently dialed fax numbers and
dial them using the associated 2-digit speed dial
number. Also used to alternately display
alternately the currently active job and any
pending jobs.
Redials the last number in Standby mode or
inserts a pause into a fax number in the edit
mode.
Used to perform a hook-switch operation, such
as call waiting.
01
21
System Data
02
22 03
23 04
24 05
25
System ID Date & Time SystemSetup Memory Clear
06
26 07
27 08
28 09
29 10
30
Delay TX Memory TX Priority TX Polling
11
31 12
32 13
33 14
34 15
35
Group Dial
Add/Cancel
Maintenance Schedule JobTx Confirm
16
36 17
37 18
38 19
39 20
40
System ListPhone Book Tx Journal Rx Journal Help List
2
3
(status map)
When an error occurs, the lamp in the
corresponding location on the Status map turns
on, as well as the error indicator, and the error
message appears on the display so that you can
locate the error.
For details on the meaning of
error messages,refer to the products
Operating Instruction.
(Error
indicators)
Turns on when a paper jam occurs.
Turns on when the toner or drum has
almost run out.
Turns on when the input tray you are using
is empty.
Turns on when an error occurs on the
system.
4
Displays the current status and prompts during
operation.
5
C
o
p
y
Used to adjust the contrast of the current copy
or fax job.
Used to select the text type for the current copy
job or fax job.
Used to specify the paper tray you want to use
in Fax or Copy mode.
Used to set up special copy features, such as
AutoFit, Clone, and Collation.
The current copy job will use both sides of the
paper when printed.
Allows you to save paper by printing 2 pages on
a single sheet of paper (available in the Copy
mode only).
ex) The paper is jammed in the exit area.
3
English
* Navigation buttons
6
Used to dial a number or enter alphanumeric
characters.
7
Engages the telephone line.
8
Enters the menu functions in conjunction with
the one-touch buttons. Also backs you up to the
previous menu level or exits the menu.
9
*
Scrolls though the menu items. When you set
the copy size or the copy page number, they can
be used to change the number.
Scrolls though the options available for the
selected menu item. In the Copy mode,
allows you to change the zoom rate and to
change the number of copies.
10
Selects the mode to activate: FAX or COPY. Also,
confirms the selection on the display.
11
Used to start a job.
12
Used to stop an operation at any time.
Also, used to clear/cancel the copy options such
as the zoom rate and multi copy pages in Copy
mode.
4
Changing the Display Language
To change the language that is displayed on the LCD display,
take the following steps:
1
Press
Menu/Exit
and then
System Setup
from the one-
touch dial keypad.
2
Press
or
until “SELECT LANGUAGE” appears on the top
line of the display. The current setting appears on the
bottom line of the display.
3
Press
or
until you see the language you want on the
display.
4
Press
Mode/Enter
to save the selection.
5
To return to Standby mode, press
Clear/Stop
.
English
About the Software
You must install software using the supplied CD-ROM after you
have set up your machine and connected it to your computer.
The CD-ROM includes:
• The software for this machine
• Operating Instructions
• Adobe Acrobat Reader
The CD-ROM provides you with the following software:
MFP Driver
To use your machine as a printer and scanner in Windows, you
must install the MFP driver. For information about installing the
MFP driver in Windows, see page .7.
Remote Control Panel
It is automatically installed when you install the MFP driver. For
information about using the program, refer to the Facsimile
Refernce.
