RF-Star RF-TI1352P2 Manuel utilisateur

RF-TI1352P2 CC1352P7 SimpleLinkTM High-

Performance Sub-1G + 2.4 G Multi-band Module

With Integrated Power Amplifier

Version 1.0

Shenzhen RF-star Technology Co., Ltd.

Oct. 31th, 2023

RF-TI1352P2

www.szrfstar.com V1.0 - Oct., 2023

Shenzhen RF-star Technology Co., Ltd. Page 1 of 22

1 Device Overview

1.1 Description

RF-TI1352P2 is an RF module based on TI SoC CC1352P7 with an integrated power amplifier. It integrates a 48 MHz

and a 32.768 kHz crystal, a 256 KB ROM, a 704 KB Flash, and the IPEX connectors and half-hole RF output pins of

different radio frequency to guarantee the external antenna connection. Its ARM® Cortex®-M4F core application

processor optimized for long-range and low-power. It features small size, robust connection distance, and rigid reliability.

The multi-band module supporting multiprotocol for both Sub-1 GHz and 2.4 GHz through a DMM driver for Thread,

Zigbee®, Matter, Bluetooth® 5.3 Low Energy, IEEE 802.15.4g, IPv6-enabled smart objects (6LoWPAN), MIOTY®,

proprietary systems, including the TI 15.4-Stack (Sub-1 GHz and 2.4 GHz). 1.27-mm pitch stamp stick package for easy

assembling and cost-effective PCB design.

1.2 Key Features

•TX power:

- Up to +20 dBm (Sub-1 GHz) with temperature

compensation

- Up to +5 dBm (2.4 GHz) with temperature

•RF Section

-Bluetooth 5.2 Low Energy

-ZigBee, Thread, Matter

-IEEE 802.15.4

-IPv6-nabld smart objects (6LoWPAN)

-MIOTY®

-Wireless M-Bus

-Wi-SUN®

-KNX RF

-Amazon Sidewalk

-Proprietary systems

-SimpleLinkTM TI 15.4-Stack (Sub-1 GHz)

-Dynamic Multiprotocol Manager (DDM) driver

compensation

•Excellent receiver sensitivity

- -121 dBm @ Sub-1 GHz (SimpleLink Long-range

Mode)

- -110 dBm @ Sub-1 GHz (50 kbps)

- -104 dBm for Bluetooth 125 kbps (LE coded PHY)

•Wide Operation Range

- 1.8 V to 3.8 V single power supply

- Operating temperature: -40 °C to +85 °C

- Storage temperature: -40 °C to +125 °C

•Microcontroller

- Powerful 48 MHz ARM® Cortex®-M4F

processor

- 2-pin cJTAG and JTAG debugging

- Supports OTA upgrade

•Memory

- 704 KB of in-system programmable flash

- 256 KB of ROM for protocols and library

functions

- 8 KB of Cache SRAM

- 80 KB of ultra-low leakage SRAM

•Ultra-low power sensor controller with 4KB of

SRAM

- Sample, store, and process sensor data

- Operation independent from system CPU

- Fast wake-up for low-power operation

•Rich Peripherals

RF-TI1352P2

www.szrfstar.com V1.0 - Oct., 2023

Shenzhen RF-star Technology Co., Ltd. Page 2 of 22

- 24 GPIOs, digital peripherals can be routed

to any GPIOs

- 4× 32-bit or 8× 16-bit general-purpose

timers

- 12-bit ADC, 200 kSamples/s, 8 channels

- 2 × comparators with internal reference DAC

(1 × continuous time, 1 × ultra-low power)

- Programmable current source

- 2 × UART

- 2 × SSI (SPI, MICROWIRE, TI)

- I2C

- I2S

- Real-time clock (RTC)

- Capacitive sensing, up to 8 channels

- Integrated temperature and battery monitor

•Security Enablers

- AES 128-bit and 256-bit Crypto accelerator

- ECC and RSA public key hardware accelerator

- SHA2 accelerator (full suite up to SHA-512)

- True random number generator (TRNG)

•External system

- On-chip buck DC/DC converter

- TCXO support

•Dimension: 26.9 mm × 16.9 mm × 2.1 mm

1.3 Applications

•Building security systems – motion detector,

electronic smart lock, door and window sensor,

garage door system, gateway

•HVAC – thermostat, wireless environmental

sensor, HVAC system controller, gateway

•Fire safety system – smoke and heat detector,

fire alarm control panel (FACP)

•Video surveillance – IP network camera

•Elevators and escalators – elevator main

control panel for elevators and escalators

•Smart meters – water meter, gas meter,

electricity meter, and heat cost allocators

•Grid communications – wireless

communications – Long-range sensor

applications

•Other alternative energy – energy harvesting

•Industrial transport – asset tracking

•Factory automation and control

•Medical

•Electronic point of sale (EPOS) – Electronic

Shelf Label (ESL)

•Wired networking – wireless LAN or Wi-Fi

access points, edge router

•Portable electronics – RF smart remote control

•Home theater & entertainment – smart

speakers, smart display, set-top box

•Connected peripherals – consumer wireless

module, pointing devices, keyboards and

keypads

•Gaming – electronic and robotic toys

•Wearables (non-medical) – smart trackers,

smart clothing

RF-TI1352P2

www.szrfstar.com V1.0 - Oct., 2023

Shenzhen RF-star Technology Co., Ltd. Page 3 of 22

1.4 Functional Block Diagram

Figure 1. Functional Block Diagram of RF-TI1352P2

1.5 Part Number Conventions

The part numbers are of the form of RF-TI1352P2 where the fields are defined as follows:

Figure 2. Part Number Conventions of RF-TI1352P2

1352

RF-STAR

Company Name

Chip Manufacturer

Chipset

TI CC1352P7

Module Version

TheSecond PA Version

CC1352P7

GPIOs

Power

Filter

48.0 MHz

32.768 kHz

Reset

Sub-1 GHz

Antenna

Matching

2.4

GHz

Antenna

Matching

IPEX

Connector

Half-hole

Interface

Power Supply

1.8 V ~ 3.8 V

PA (Sub-1

GHz) Antenna

Matching

Switch

IPEX

Connector

Half-hole

Interface

Ant

Switch

Ant

Switch

                RF-TI1352P2
www.szrfstar.com                                                                         V1.0 - Oct., 2023
Shenzhen RF-star Technology Co., Ltd.                                                                                                                    Page  4  of  22
Table of Contents
Device Overview............................................................................................................................................................. 1
1 Description............................................................................................................................................................ 1
2 Key Features ....................................................................................................................................................... 1
3 Applications.......................................................................................................................................................... 2
4 Functional Block Diagram .............................................................................................................................. 3
5 Part Number Conventions.............................................................................................................................. 3
Table of Contents................................................................................................................................................................ 4
Module Configuration and Functions ...................................................................................................................... 6
1 Module Parameters........................................................................................................................................... 6
2 Module Pin Diagram ......................................................................................................................................... 7
3 Pin Functions....................................................................................................................................................... 8
Specifications .................................................................................................................................................................10
1 Recommended Operating Conditions .....................................................................................................10
2 Handling Ratings..............................................................................................................................................10
3 PA Output Control............................................................................................................................................10
Application, Implementation, and Layout.............................................................................................................11
1 Module Photos..................................................................................................................................................11
2 Recommended PCB Footprint....................................................................................................................11
3 Schematic Diagram.........................................................................................................................................12
4 Antenna................................................................................................................................................................12
4.1 Antenna Design Recommendation ..............................................................................................12
4.2 Antenna Output Mode Modification..............................................................................................13
4.3 External Antenna Design Recommendation of the Half-Hole ANT Pin..........................13
4.4 IPEX Connector Specification........................................................................................................15
5 Basic Operation of Hardware Design ......................................................................................................15
6 Trouble Shooting..............................................................................................................................................16
6.1 Unsatisfactory Transmission Distance........................................................................................16
6.2 Vulnerable Module..............................................................................................................................17
6.3 High Bit Error Rate .............................................................................................................................17
7 Electrostatics Discharge Warnings ...........................................................................................................17
8 Soldering and Reflow Condition.................................................................................................................17

RF-TI1352P2

www.szrfstar.com V1.0 - Oct., 2023

Shenzhen RF-star Technology Co., Ltd. Page 5 of 22

5 Optional Package Specification ..............................................................................................................................19

6 Revision History ............................................................................................................................................................21

7 Contact Us.......................................................................................................................................................................22

RF-TI1352P2

www.szrfstar.com V1.0 - Oct., 2023

Shenzhen RF-star Technology Co., Ltd. Page 6 of 22

2 Module Configuration and Functions

2.1 Module Parameters

Table 1. Parameters of RF-TI1352P2

Chipset

CC1352P7

Supply Power Voltage

1.8 V ~ 3.8 V, 3.3 V is recommended

Frequency

800 MHz ~ 928 MHz, 2402 MHz ~ 2480 MHz

Maximum Transmit Power

+20.0 dBm (Sub-1 GHz)

+5 dBm (2.4 GHz)

Receiving Sensitivity

-121 dBm @ Sub-1 GHz (Long-range Mode)

-110 dBm @ Sub-1 GHz (50 kbps)

-104 dBm @ Sub-1 GHz (100 kbps)

-97 dBm @ Bluetooth 5.0 (1 Mbps)

-92 dBm @ Bluetooth 5.0 (2 Mbps)

-104 dBm @ Bluetooth 5.0 (125 kbps LE Coded PHY)

GPIO

Flash

704 KB

ROM

256 KB

SRAM

88 KB

Power Consumption

RX current: 5.8 mA @3.6 V, 868 MHz

6.9 mA @3.0 V, 2.4 GHz

TX current: 63.0 mA @ +20 dBm, 3.3 V, 915 MHz

85.0 mA @ +20 dBm, 3.0 V, 2.4 GHz

22.0 mA @ +10 dBm, 2.4 GHz

MCU 48 MHz (CoreMark): 2.9 mA (60 μA/MHz)

Sensor Controller: 30.1 μA @ low power mode, 2 MHz, running infinite loop

808 μA @ active mode, 24 MHz, running infinite loop

Standby mode: 0.85 µA

Sleep Mode: 150 nA

Support Protocol

Thread, Zigbee®, Matter, Bluetooth® 5.3 Low Energy, IEEE 802.15.4g, IPv6-

enabled smart objects, (6LoWPAN), MIOTY®, Wireless M-Bus, Wi-SUN®, KNX

RF, Amazon Sidewalk, proprietary systems, SimpleLink™ TI 15.4-Stack (Sub-1

GHz)

RF-TI1352P2

www.szrfstar.com V1.0 - Oct., 2023

Shenzhen RF-star Technology Co., Ltd. Page 7 of 22

Crystal

48 MHz, 32.768 kHz

Package

SMT packaging (1.27-mm half-hole pitch stamp stick)

Dimension

26.5 mm × 16.9 mm × 2.1 mm

Type of Antenna

Half-hole ANT interface, IPEX connector

Operating Temperature

-40 ℃ ～ +85 ℃

Storage Temperature

-40 ℃ ～ +125 ℃

2.2 Module Pin Diagram

Figure 3. Pin Diagram of RF-TI1352P2

RF-TI1352P2

www.szrfstar.com V1.0 - Oct., 2023

Shenzhen RF-star Technology Co., Ltd. Page 8 of 22

3.3 Pin Functions

Table 2. Pin Functions of RF-TI1352P2

Name

Chip Pin

Function

Description

None connect

-None connect

DIO5

DIO_5

Digital

GPIO, high-drive capability

DIO6

DIO_6

Digital

GPIO, high-drive capability

DIO7

DIO_7

Digital

GPIO, high-drive capability

DIO8

DIO_8

Digital

GPIO

DIO9

DIO_9

Digital

GPIO

DIO10

DIO_10

Digital

GPIO

DIO11

DIO_11

Digital

GPIO

DIO12

DIO_12

Digital

GPIO

DIO13

DIO_13

Digital

GPIO

DIO14

DIO_14

Digital

GPIO

DIO15

DIO_15

Digital

GPIO

VDD

VDDS

VDD

Power Supply: 1.8 V ~ 3.8 V, recommend to 3.3 V

GND

Ground

TMSC

JTAG_TMSC

Digital

JTAG TMSC, high-drive capability

TCKC

JTAG_TCKC

Digital

JTAG TCKC

RES

RESET_N

Digital

Reset, active low. Internal pullup.

DIO16

DIO_16

Digital

GPIO, JTAG_TDO, high-drive capability

DIO17

DIO_17

Digital

GPIO, JTAG_TDI, high-drive capability

DIO18

DIO_18

Digital

GPIO

DIO19

DIO_19

Digital

GPIO

DIO20

DIO_20

Digital

GPIO

DIO21

DIO_21

Digital

GPIO

RF-TI1352P2

www.szrfstar.com V1.0 - Oct., 2023

Shenzhen RF-star Technology Co., Ltd. Page 9 of 22

DIO22

DIO_22

Digital

GPIO

DIO23

DIO_23

Digital or Analog

GPIO, analog capability

DIO24

DIO_24

Digital or Analog

GPIO, analog capability

DIO25

DIO_25

Digital or Analog

GPIO, analog capability

DIO26

DIO_26

Digital or Analog

GPIO, analog capability

DIO27

DIO_27

Digital or Analog

GPIO, analog capability

DIO28

DIO_28

Digital or Analog

GPIO, analog capability

None connect

GND

Ground

2G4-OUT

RF Out

2.4 GHz antenna pinout

GND

Antenna Ground

SUB-OUT

RF Out

Sub 1GHz antenna pinout

GND

Ground

Table des matières

Autres manuels RF-Star Matériel informatique

RF-Star

RF-Star RF-ZM-2530P1 CC2530 Manuel utilisateur

RF-Star

RF-Star RF-BM-ND08C Manuel utilisateur

RF-Star

RF-Star RF-43UH Manuel utilisateur

RF-Star

RF-Star RF-BM-ND04C Manuel utilisateur

RF-Star

RF-Star RF-BM-BG22C3 Manuel utilisateur

RF-Star

RF-Star SimpleLink RF-BM-2642B1 Manuel utilisateur

RF-Star

RF-Star RF-42UP Manuel utilisateur

RF-Star

RF-Star CC254X Series Manuel utilisateur

RF-Star

RF-Star RF-BM-4077B1 Manuel utilisateur

RF-Star

RF-Star RF-BM-4044B4 Manuel utilisateur

RF-Star

RF-Star RF-BM-ND06 Manuel utilisateur

RF-Star

RF-Star CC254 Series Manuel utilisateur

RF-Star

RF-Star RF-BM-BG22A3 Manuel utilisateur

RF-Star

RF-Star RF-BM-4077B1L Manuel utilisateur

RF-Star

RF-Star RF-BM-ND04 Manuel utilisateur

RF-Star

RF-Star RF-BM-ND06 Manuel utilisateur

RF-Star

RF-Star EFR32MG24 Series Manuel utilisateur

RF-Star

RF-Star RF-ZM-2530B1 Manuel utilisateur

RF-Star

RF-Star RF-DG-40A Manuel utilisateur

RF-Star

RF-Star RF-BM-4044B2 Manuel utilisateur

RF-Star

RF-Star EFR32BG24 Series Manuel utilisateur

RF-Star

RF-Star RF-BM-ND10 Manuel utilisateur

RF-Star

RF-Star RF-BM-ND01 Manuel utilisateur

RF-Star

RF-Star RF-BM-ND08 Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur
