RetroSound RetroRadio Apache Manuel utilisateur
MODERN SOUND FOR YOUR CLASSIC
www.retromanufacturing.com
USER’S MANUAL, MOTOR 2
TM
1
TABLE OF CONTENTS
WELCOME 2
WHAT’S IN THE BOX 3
PRECAUTIONS 4
INSTALLATION INSTRUCTIONS 7
WIRING DIAGRAM 10
OPERATING YOUR RADIO
GENERAL OPERATION 14
TONE CONTROLS 17
SYSTEM SETTINGS 18
USB DEVICE INSTRUCTIONS 22
BLUETOOTH®INSTRUCTIONS 24
TROUBLESHOOTING 26
FREQUENTLY ASKED QUESTIONS 27
SPECIFICATIONS 30
LIMITED WARRANTY 31
REPLACEMENT PARTS 32
INSTALLATION NOTES 33
2
Copyright © 2019 Retro Manufacturing, LLC
WELCOME
Thank you for purchasing a RetroSound® Apache RetroRadioTM.
Apache has the advanced features you expect from a modern
car stereo.
General Features
• Built-in Bluetooth®for hands-free calling and audio streaming
• Selectable 32,000 color LCD illumination with user pre-sets
• AM/FM tuner with 30 pre-sets
• Plays MP3, WMA and FLAC les via USB input
• Selectable international tuner frequencies
• Built-in amplier with TRUE 25 watts RMS x 4-channels
(45 watts peak x 4-channels)
• 3 EQ pre-sets plus user-controlled bass, mid-range,treble, fader, and
balance adjustments
• InniMount bracket system for maximum installation exibility
• Available with period-correct knobs, bezel and/or faceplate
• Inputs: 1 rear-mounted standard USB port and 2 rear auxiliary inputs
• Outputs: 4-channel pre-amp outputs (front, rear)
• Separate power antenna and amplier turn-on lead(s)
• 1 year parts and labor warranty
The information enclosed in this user’s manual is to be used as a guide to assist
you with installation and operation of your radio. This guide does not cover
every installation possibility, vehicle, or every aspect of the installation process.
Retro Manufacturing, LLC, RetroSound®, or its subsidiaries, assume no
responsibility for any installation. This manual may be updated from time to time.
Visit our website for the latest updates: www.retromanufacturing.com.
The Bluetooth®word mark and logos are registered trademarks owned by Bluetooth SIG,
Inc. and any use of such marks by Retro Manufacturing, LLC is under license.
3
WHAT’S IN THE BOX
The items shown below are packaged with your Motor box.
The items shown below are packaged with your RetroRadio
TM
face box.
Main Wiring Harness
(plugs into back of radio)
Power and Speaker
Wiring Harnesses
(both plug into
Main Wiring Harness)
Motor 2 Radio Body Bluetooth
®
Microphone
RetroRadio
TM
Face
Shaft Mounting Hardware
Radio Face
Mounting Screws
Shafts
InniMount Brackets
Metal Mounting Backstrap
and Hardware
Plastic Washer Kit Bracket Mounting Hardware
4
Copyright © 2019 Retro Manufacturing, LLC
PRECAUTIONS
PLEASE OBSERVE THESE PRECAUTIONS WHEN INSTALLING
AND USING THIS UNIT:
This user’s manual does not cover all possible installation scenarios.
If you feel that you can’t install this unit yourself take it to a local
car audio professional. If you have questions about installing your
at 888.325.1555.
• Do not disassemble, modify the unit or attempt to repair the
unit yourself. If the unit needs to be repaired, consult your
dealer or Retro Manufacturing, LLC.
• Do not use the unit when it is out of order. If the unit is out of
order or is in an abnormal state (has foreign objects in it, is
exposed to water, smokes or smells), turn it off immediately
and consult your dealer or Retro Manufacturing, LLC.
• Refer fuse replacement to qualied service personnel. If the
fuse fails, eliminate the cause and have it replaced by a
qualied service technician with the fuse prescribed for this
unit. Incorrect replacement of the fuse may lead to smoke, re
or damage to the unit.
• If the unit does not turn on, check the connections rst. Then
check the fuse in your vehicle’s fuse panel and the fuse at the
unit’s wiring harness. Do not expose the unit to direct sunlight
or excessive heat. Excessive heat will raise the interior
temperature of the unit which may damage it.
• Do not use the unit where it is exposed to moisture or dust.
Exposure of the unit to moisture or dust may lead to smoke, re
or other damage to the unit and will void your warranty. Make
sure the unit does not get wet in car washes or on rainy days.
5
PRECAUTIONS
• Refer wiring and installation to qualied service personnel.
Installation of this unit requires special skills and experience.
Retro Manufacturing, LLC is not liable for any problems
resulting from improper installation of the unit. Please be sure
to follow the instructions carefully while attempting installation.
• Follow the instructions to wire the unit. Failure to follow the
instructions could cause damage to the unit, re, injury or death.
• Be careful not to damage the leads. Prevent them from
being caught in the vehicle chassis or from being damaged
by screws or moving parts such as seat rails. Do not scratch,
pull, bend or twist the leads. Do not install them near heat
sources or place heavy objects on them. If the wiring must
be routed around sharp metal edges, protect them by
wrapping them with vinyl tape or similar protections.
NOTE: Cutting the main wiring harness, antenna lead, USB or auxiliary cables will
void the warranty of your radio.
• We recommend only using the supplied parts when installing
this unit. If mounting the radio face or body remotely, use
extreme caution not to damage internal parts when
choosing brackets and screws.
• Do not interfere with safety-related vehicle components.
Do not wire or afx this unit to the fuel tank, brakes, suspension,
steering wheel, pedals, etc. Check for electric wiring, piping
and other items before installing the unit.
• Never install the unit in a location where it interferes with your
eld of vision.
• Use the supplied metal backstrap to secure the rear of the
unit. Failure to secure the rear of the unit will damage the
shafts and void your warranty.
6
Copyright © 2019 Retro Manufacturing, LLC
PRECAUTIONS
• Never splice into the power lead to supply other equipment
with power.
• After installation and wiring, always check the normal operation
of other electrical equipment.
• Make sure that no wires interfere with driving or entering/exiting
of the vehicle.
• Insulate all exposed wires to prevent short-circuiting or electric shock.
• Do not operate the unit for prolonged periods with the engine off.
Prolonged operation with the engine turned off will drain the
battery.
• Keep the volume of your radio at a level that allows you to hear
outside noises such as emergency sirens and train crossing
warnings. Prolonged exposure to high volume levels may result
in hearing loss.
• This unit requires 12-volts to both the red and yellow power leads.
The unit will not work without 12-volts to both of these leads.
• Always disconnect the negative (-) battery cable before
beginning installation. Verify the battery ground by checking
that one wire is connected to the vehicle’s starter mounting
bolt or engine block and the other to the vehicle’s chassis using
at least 8 gauge wire. Make sure the alternator or generator
connections are secure and free from corrosion, rust or dirt.
• This unit is designed for operation with a negative ground 12-volt
DC battery system. Do not operate this unit with other battery
systems, especially an 18 or 24-volt DC or a positive ground
system. If you have a 6-volt system, you need to either convert
to 12-volt DC or purchase a separate inverter that would increase
the voltage to 12-volts.
NOTE: The inverter needs to be rated at 10 amps or higher in order for the radio to
operate properly.
7
STEP 1: Install the Radio Face
Plug the ribbon cable (included with the Motor) into the front
of the Motor radio body and the back of the radio face. After
doing this, attach the radio face to the front of the radio body
using the four radio face mounting screws provided in the
radio face box.
The RetroSound®logo on the Motor radio body should be facing
upwards. Make sure to not install the face to the body upside down.
NOTE: Optionally, the radio face can be mounted remotely up to nine feet away
from the Motor radio body using an optional Face to Body Extension Cable (sold
separately). In some installation applications, a bracket (not included) can be used
to mount the radio face to the radio body at an angle.
INSTALLATION INSTRUCTIONS
Figure 1 - Installing the Radio Face
Radio Face
Radio Body Face Mounting
Screws
8
Copyright © 2019 Retro Manufacturing, LLC
INSTALLATION INSTRUCTIONS
STEP 2: Install InfiniMount Brackets
Attach each InniMount bracket to the correct side of the radio
using the supplied screws. Before tightening the screws, you need
to adjust the brackets up, down, forward or backward. You may
also rotate, cut, or bend the brackets to achieve the perfect t
(See Figure 2). Complete the assembly with at least two screws
tightened on each side.
NOTE: In some installations the brackets must be moved far enough forward or
backwards or rotated so that only two screws will align with the threaded screw holes
on the radio. Two screws are sufcient to hold the brackets in place.
You may need to cut, trim or bend the brackets to achieve a perfect t. You can
even drill new mounting holes into the bracket if you need to. The InniMount system is
designed to be modied. Modifying your brackets will NOT void your warranty.
Figure 2 - Attach InniMount Brackets
R
9
INSTALLATION INSTRUCTIONS
STEP 3: Mount Shafts to Brackets
To match the the location of your shafts to the proper width of your
vehicle’s dash, rst measure the distance between your existing shaft
holes from center to center.
Mount a shaft to each bracket using the supplied shaft nuts
and washers. Finger tighten the shaft nuts to prepare for the nal
installation (See Figure 3). Once you ensure proper width, tighten
the screws and nuts (DO NOT OVERTIGHTEN).
OVERTIGHTENING THE SHAFT NUTS WILL DAMAGE THE SHAFTS.
DAMAGE FROM OVERTIGHTENING WILL VOID YOUR WARRANTY.
Finally, plug the shafts into each side of the body (See Figure 4).
Figure 3 - Mount Shafts to Brackets
Shaft Washers
Shaft Nuts
Figure 4 - Plug Shafts into the Body
