Reolink TrackMix WiFi Guide de démarrage rapide

Operational Instruction

@ReolinkTech https://reolink.com

Apply to: Reolink TrackMix WiFi

EN/DE/FR/IT/ES

Technical Support

If you need any technical help, please visit our ocial support site and

contact our support team before returning the products:

https://support.reolink.com.

Technische Unterstützung

Wenn Sie technische Hilfe benötigen, besuchen Sie bitte unsere

ozielle Support-Website und kontaktieren Sie unser Support-Team,

bevor Sie die Produkte zurückschicken, https://support.reolink.com.

Support technique

Si vous avez besoin d’aide, veuillez contacter Reolink avant de

retourner votre produit. La plupart des questions peuvent être

répondues via notre centre de support en ligne à l’adresse

https://support.reolink.com.

Assistenza Tecnica

Se avete bisogno di assistenza tecnica, visitate il nostro sito uciale di

Centro Assistenza e contattate il team di supporto prima di restituire i

prodotti, https://support.reolink.com.

Soporte técnico

Si necesita cualquier ayuda técnica, por favor, consulte nuestro sitio

ocial de soporte y póngase en contacto con nuestro equipo de

soporte antes de devolver el producto: https://support.reolink.com.

REOLINK INNOVATION LIMITED

FLAT/RM 705 7/F FA YUEN COMMERCIAL BUILDING 75-77 FA YUEN

STREET MONG KOK KL HONG KONG

Product Ident GmbH

UK REP

EU REP

APEX CE SPECIALISTS LIMITED

Hoferstasse 9B, 71636 Ludwigsburg, Germany

Email: prodsg@libelleconsulting.com

Addr.: 89 Princess Street, Manchester, M14HT, UK

Email: [email protected]

January 2023

QSG1_A

58.03.005.0090

English English1 2

What's in the Box ···················································2

Camera Introduction ················································3

Connection Diagram ················································5

Set UP the Camera ·················································6

Mount the Camera··················································7

Troubleshooting ···················································10

Specication························································11

Notication of Compliance ··········································11

What's in the Box

Contents

Quick Start Guide

Camera Waterproof Lid Power Adapter

4.5m Power

Extension Cable

Pack of Screws

Mounting Hole

Template

Ethernet Cable

Surveillance Sign

English English3 4

Camera Introduction

* Press for about 10 seconds to

restore the device to factory

settings.

8 9 10

Antenna

Speaker

Mount

SD Card Slot

lnfrared Light

Reset Button

Built-in Mic

Lens

Daylight Sensor

Spotlight

Waterproof Lid

Network Cable

Power Port (Optional)

English English5 6

Connection Diagram

Before initial setup, follow the steps below to connect your camera.

1. Connect the camera to a LAN port on your router with an Ethernet

cable.

2. Use the power adapter to power on the camera.

Camera

Network Cable

Router

Power Cable

Power Adapter

Set UP the Camera

• On Smartphone

• On PC

Scan to download

the Reolink App.

Download path of the Reolink Client: Go to https://reolink.com > Support

> App & Client.

Download and launch the Reolink App or Client software, and follow the

onscreen instructions to nish initial setup.

NOTE:

• When setting up the WiFi camera, you need to follow the onscreen

instructions to nish the WiFi conguration rst.

English English7 8

Mount the Camera

• Do not face the camera towards any light sources.

• Do not point the camera towards a glass window. Otherwise, it may

result in poor image quality because of the window glare caused by

infrared LEDs, ambient lights or status lights.

• Do not place the camera in a shaded area and point it towards a

well-lit area. Otherwise, it may result in poor image quality. To ensure

best image quality, the lighting condition for both the camera and the

capture object should be the same.

• To ensure better image quality, it’s recommended to clean the lens

cover with a soft cloth from time to time.

• Make sure the power ports are not directly exposed to water or

moisture and not blocked by dirt or other elements.

• The waterproof camera can work properly under conditions like rain

and snow. However, it doesn’t mean the camera can work underwater.

• Do not install the camera at places where rain and snow can hit the lens

directly.

Installation Tips

Mount the camera to the wall

1. Drill holes in accordance with the mounting hole template.

2. Install the mount base with screws included in the package.

3. To adjust the camera direction, you may control the camera to pan

and tilt via Reolink App or Client.

NOTE: Use the drywall anchors included in the package if needed.

English English9 10

Troubleshooting

Camera is not powering on

If your camera is not powering on, please try the following solutions:

• Plug the camera into a dierent outlet and see if it works.

• Power on the camera with another working 12V 2A DC adapter and see

if it works.

If the problem is not solved, please contact Reolink Support.

Mount the Camera to Ceiling

1. Drill holes in accordance with

the mounting hole template.

2. Install the mount base with

screws included in the package.

3. To adjust the camera direction,

you may control the camera to

pan and tilt via Reolink App or

Client.

NOTE: Use the drywall anchors

included in the package if

needed. If the picture from the camera is not clear, please try the following

solutions:

• Check the camera lens for dirt, dust or spiderwebs.

• Point the camera to a well-lit area. The lighting condition will aect the

picture quality a lot.

• Upgrade the rmware of your camera to the latest version.

• Restore the camera to factory settings and check it again.

If the problem is not solved, please contact Reolink Support.

Picture is not clear

English English11 12

Notication of Compliance

This device complies with Part 15 of the FCC Rules. Operation is subject to

the following two conditions:

this device may not cause harmful interference, and this device must

accept any interference received, including interference that may cause

undesired operation.

FCC Compliance Statement

NOTE: This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment

generates uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment o and on,

the user is encouraged to try to correct the interference by one or more

of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to

which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Changes or modications not expressly approved by the party

responsible for compliance could void the user’s authority to operate the

equipment.

Dimension: 228.2*147*129mm

Weight: 1.21KG

Operating Temperature: -10°C~+55°C (14°F~131°F)

Operating Humidity: 10%~90%

For more specications, visit https://reolink.com/.

Specication

Infrared Night Vision: Up to 30 meters (95ft)

Day/Night Mode: Auto switchover

Field of View: Horizontal 104°-38°; Vertical: 60°-21°

Hardware Features

General

English English13 14

This product comes with a 2-year limited warranty that is valid only if

purchased from Reolink Ocial Store or a Reolink authorized reseller.

Learn more: https://reolink.com/warranty-and-return/.

Limited Warranty

NOTE: We hope that you enjoy the new purchase. But if you are not

satised with the product and plan to return, we strongly suggest that

you reset the camera to factory default settings before returning.

Use of the product is subject to your agreement to the Terms of Service

and Privacy Policy at reolink.com. Keep out of reach of children.

Terms and Privacy

This marking indicates that this product should not be disposed with

other household wastes.throughout the EU. To prevent possible harm to

the environment or human health from uncontrolled waste disposal,

recycle it responsibly to promote the sustainable reuse of material

resources. To return your used device, please use the return and

collection systems or contact the retailer where the product was

purchased. They can take this product for environmentally safe recycling.

Correct Disposal of This Product

Reolink declares that the WiFi camera is in compliance with the essential

requirements and other relevant provisions of Directive 2014/53/EU, the

PoE camera is in compliance with Directive 2014/30/EU.

Simplied EU Declaration of Conformity

This equipment complies with FCC radiation exposure limits set forth for

an uncontrolled environment. This equipment shall be installed and

operated with minimum distance 20cm between the radiator & body.

FCC RF Exposure Warning Statements

By using the Product Software that is embedded on the Reolink product,

you agree to the terms of this End User License Agreement (“EULA”)

between you and Reolink. Learn more: https://reolink.com/eula/.

End User License Agreement

English English15 16

The device has been evaluated to meet general RF exposure

requirements. The device can be used in mobile exposure conditions.

The min separation distance is 20cm.

Déclaration d’exposition aux radiofréquences pour IC

L’appareil a été évalué pour répondre aux exigences générales en

matière d’exposition aux RF. L’appareil peut être utilisé dans des

conditions d’exposition mobiles.

La distance de séparation minimale est de 20cm.

Radio Frequency Exposure Statement for IC

2412MHz--- 2472MHz(19dBm)

5150MHz--- 5350MHz(18dBm)

5470MHz--- 5725MHz(18dBm)

OPERATING FREQUENCY (the maximum transmitted power)

This device contains licence-exempt transmitter(s)/re

ceiver(s) that comply with Innovation, Science and Economic

Development Canada’s licence-exempt RSS(s). Operation is subject to

the following two conditions:

(1) This device may not cause interference.

(2) This device must accept any interference, including interference that

may cause undesired operation of the device.

L’émetteur/récepteur exempt de licence contenu dans le présent

appareil est conforme aux CNR d’Innovation, Sciences et Développement

économique Canada applicables aux appareils radio exempts de licence.

L’exploitation est autorisée aux deux conditions suivantes:

(1) L’ appareil ne doit pas produire de brouillage;

(2) L’ appareil doit accepter tout brouillage

radioélectrique subi, même si le brouillage est susceptible d’ en

compromettre le fonctionnement.

ISED Statements

Deutsch Deutsch17 18

Lieferumfang ······················································18

Über die Kamera···················································19

Verbindungsdiagramm·············································21

Einrichten der Kamera ············································ 22

Montage der Kamera ············································· 23

Fehlersuche······················································· 26

Spezikation ······················································ 27

Konformitätserklärung ············································ 27

Lieferumfang

Katalog

Schnellstartanleitung

Kamera Wasserdichter Deckel Netzadapter

4,5 m

Stromverlängerungskabel

Schraubenpack

Montagelochs-

chablone

Netzwerkkabel

Überwachungsaufkleber

Autres manuels pour TrackMix WiFi

Table des matières

Langues :

Autres manuels Reolink Caméra de sécurité

Reolink

Reolink TrackMix Guide de démarrage rapide

Reolink

Reolink B800 Guide de démarrage rapide

Reolink

Reolink Argus 3 Guide de démarrage rapide

Reolink

Reolink RLC-1212A Guide de démarrage rapide

Reolink

Reolink Argus PT Lite Manuel utilisateur

Reolink

Reolink Go PT Ultra Manuel utilisateur

Reolink

Reolink E1 Pro Manuel utilisateur

Reolink

Reolink RLC-81PA Manuel utilisateur

Reolink

Reolink RLC-410-B500 Guide de démarrage rapide

Reolink

Reolink TrackMix PoE Manuel utilisateur

Reolink

Reolink Argus 2E Manuel utilisateur

Reolink

Reolink RLC-510WA Manuel utilisateur

Reolink

Reolink E1 Series Manuel utilisateur

Reolink

Reolink Argus 2 Manuel utilisateur

Reolink

Reolink Go Manuel utilisateur

Reolink

Reolink Argus 2 Manuel utilisateur

Reolink

Reolink RLC-823A 16X Manuel utilisateur

Reolink

Reolink Argus Manuel utilisateur

Reolink

Reolink RLC-1010A/B4K11 Guide de démarrage rapide

Reolink

Reolink E1 Series Manuel utilisateur

Reolink

Reolink TrackMix WiFi Manuel utilisateur

Reolink

Reolink Argus Eco Ultra Manuel utilisateur

Reolink

Reolink Argus 2 Manuel utilisateur

Reolink

Reolink E1 Pro Manuel utilisateur

Manuels Caméra de sécurité populaires d'autres marques

Okina USA

Okina USA SIR36-870VF650LP Manuel utilisateur

Divio

Divio NDR155PA Manuel utilisateur

Canon

Canon VB-C500D Manuel utilisateur

Easy Access

Easy Access EasyGuard Manuel utilisateur

Vivotek

Vivotek FD9389-EHV-v2 Manuel utilisateur

TUYA

TUYA COSMO W2 Manuel utilisateur

Eusso

Eusso UNC7500-IR Guide de configuration

urmet domus

urmet domus 1096/204 Manuel utilisateur

VC VC20 series Manuel utilisateur

Axis

Axis Q1614 Manuel utilisateur

ieGeek

ieGeek DD201 Manuel utilisateur

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuel utilisateur

Vicon

Vicon V662-D-1 Mode d'emploi

Grundig

Grundig GCH-K0274P Manuel utilisateur

Lorex

Lorex VANTAGE LBC7032 Manuel utilisateur

4xem

4xem WPT Manuel utilisateur

Samsung

Samsung SCV-3082 Manuel utilisateur

Vitek

Vitek VTC-C544 Manuel utilisateur
