Installation Guide (FAS Series) V:3.0
FAS
10
Appendix
1. Change location
In case there is a need to change the location of the assembled structure, you may install the castor bar detachable
that come with wheels to do the shifting.
Sliding block
Sliding block
2. Levelling adjustment
In case there is a need to adjust the frame levelling to the ground, you may loosen and change the position of the sliding
block so as to change the angle of resting point of the assembly frame.
Castor bar
detachable
Adjust this sliding block up or
down for front side levelling.
Secure the black knob screw
when done.
Adjust this sliding block up or
down for back side levelling.
Secure the black knob screw
when done.
Side view
-- THE END --
