User Manual for your
ICON80IX
NOTE: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.
2
Contents
Environmental note 3
Important safety information 4 - 7
Specifications 8 - 10
Product and aperture dimensions 8
Product specifications 8
Standard accessories 9
Electrical details 9
Cooling fan 9
Control panel 10
Setting and using the oven programmer/timer 10-15
Setting clock (the time of day) 10
Before first use 11
Selecting a cooking function and temperature 11
Setting the minute minder function 12
Setting the duration function 13
Setting the end cook function 13
Delayed start cooking time setting 13
Child lock 14
Symbol of temperature sensor short circuit or broken circuit 14
Function introduction 15 - 18
Oven functions 15
Cooking guidelines 16
Warnings 17
Shelfpositions 18
Cleaning and maintenance 19-22
Replacing the oven bulb 20
Removing the oven door for cleaning 21
Removing the inner door glass for cleaning 22
Installation 23 - 26
Electrical connection 23
Installing the oven into the kitchen cabinet 25
Positioning the appliance 25
Ventilation requirements 26
My appliance isn’t working correctly 27 - 29
3
Environmental note
o The packaging materials that the manufacturer uses are
environmentally friendly and can be recycled.
o Please discard all packaging material with due regard for the
environment.
4
IMPORTANT SAFETY INFORMATION
Your safety is of the utmost importance to us. Please
make sure that you read this instruction booklet before
attempting to install or use the appliance. If you are
unsure of any of the information contained in this booklet,
please contact the Customer Care Department.
General Information
o This appliance is designed for domestic household use and can be
built into a standard kitchen cabinet or housing unit.
o IMPORTANT: The adjacent furniture or housing and all materials
used in the installation must be able to withstand a minimum
temperature of 85°C above the ambient temperature of the room
it is located in, whilst in use.
o Certain types of vinyl or laminate kitchen furniture are particularly
prone to heat damage or discolouration at temperatures below the
guidelines given above.
o Any damage caused by the appliance being installed in
contravention of this temperature limit, or by placing adjacent
cabinet materials closer than 4mm to the appliance, will be the
liability of the owner.
o The use of this appliance for any other purpose or in any other
environment without the express agreement of the manufacturer
will invalidate any warranty or liability claim.
o Your new appliance is guaranteed against electrical or mechanical
defects, subject to certain exclusions that are noted in the
manufacturer’s Conditions Of Guarantee. The foregoing does not
affect your statutory rights.
o Repairs may only be carried out by service engineers that
are approved by the manufacturer.
5
Warning and safety instructions
o This appliance complies with all current European safety
legislation. The manufacturer does wish to emphasise that this
compliance does not remove the fact that the appliance surfaces
will become hot during use and retain heat after operation.
o This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Child Safety
o We strongly recommend that babies and young children are
prevented from being near to the appliance and not allowed to
touch the appliance at any time.
o If it is necessary for younger family members to be in the kitchen,
please ensure that they are kept under close supervision at all
times.
General Safety
o Do not place heavy objects on the oven door or lean on the oven
door when it is open, as this can cause damage to the oven door
hinges.
o Do not leave heated oil or fat unattended, as this is a fire risk.
o Do not place pans or baking trays directly on the base of the oven
cavity, or line it with aluminium foil.
o Do not allow electrical fittings or cables to come into contact with
areas on the appliance that get hot.
o Do not use the appliance to heat the room it is located in or to
dry clothing.
o Do not install the appliance next to curtains or soft furnishings.
6
o Do not attempt to lift or move cooking appliances by using the
oven door or handle, as this may cause damage to the appliance
or result in injury to the person lifting the appliance.
Cleaning
o Cleaning of the oven should be carried out on a regular basis.
o Great care should be taken whilst using this appliance and when
following the cleaning procedure.
o IMPORTANT: The appliance must be disconnected from the
mains before following the cleaning procedure.
Installation
This appliance must be correctly installed by a
suitably qualified person, strictly in accordance
with the manufacturer’s instructions.
o The manufacturer declines any responsibility for injury or
damage, to person or property, as a result of improper use
or installation of this appliance.
o Heat, steam and moisture will be created during use of the
appliance, take care to avoid injury and ensure that the room is
adequately ventilated. If the appliance is going to be used for
prolonged periods of time, then additional ventilation may be
required.
o Please consult with your qualified installer if you are in any doubt
about the amount of ventilation that you will require.
7
Declaration of conformity
This appliance complies with the following European Directives:
- 2014/35/EU regarding “low voltage”
- 2014/30/EU regarding “electromagnetic disturbances”
- Regulation (EC) N° 1935/2004 regarding “materials in contact with
food”
o The above directives comply with 93/68/EEC regarding CE marking.
o The manufacturer declares that the oven is built using certified
materials and requires the appliance to be installed in accordance
with the standards currently in force. This appliance must be used by
a trained person for domestic purposes only.
8
Specifications
Product Dimensions Aperture Dimensions
Height: 595 mm 600 mm
Width: 595 mm 560 mm
Depth: 575 mm 560 mm (min)
Product specifications
o 10 oven functions
o Energy efficiency class: A
o Oven net/gross capacity: 80/82 liters
o LCD fully programmable timer
o Cooling fan
o Thermostatically controlled grill
o Double-glazed removable door
o Removable inner door glass
o Mark resistant coating
o Oven light
9
Standard accessories
Accessory Name
Quantity
Baking tray
1
Grill
2
1
Handle
1
Screws(ST4x35)
4
Electrical details
Rated Voltage: 220-240 Vac, 50/60 Hz
Supply Connection: 13A
Rated max power : 2.90 kW
Mains Supply Lead: 3 x 1.5mm²
Oven Light Bulb: 25 W/300°C screw type pygmy
Cooling fan
o A tangential cooling fan is fitted inside of this appliance, to make
the internal temperature of the oven stable and the external
surface temperature lower.
o After you have finished cooking and switched off the oven, the
cooling fan will continue to run for a period of time afterwards.
The length of time will depend on how long the oven has been
switched on for and at how high a temperature.
10
Control Panel
Touch buttons
Child lock Clock Timer Temperature
Time/Temperature decreasing Time/Temperature increasing
Pause/Cancel Confirm/Start
Symbol in the display
Clock time Cooking duration End cooking time
Child lock indicator Timer
Setting and using the oven programmer/timer
Setting clock (the time of day)
o Once you new appliance has been connected to the power supply,
the left area of display shows “12:00” as default, while a buzzer
sounds. You can set up the clock now.
o Press the button, the hour digit will flash, use or
buttons to adjust the number. Press the button again, the
minute digit will flash, use or buttons to adjust the number.
Press the button again, the time is applied.
