REED R7700 Manuel utilisateur

reedinstruments

www com

Model

Instruction

Manual

INSTRUMENTS

Gloss Meter

R7700

REED Instruments

1-877-849-2127 | [email protected] | www.reedinstruments.com

reedinstruments

www com

INSTRUMENTS

Table of Contents

Safety ..........................................................................................................2

Features................................................................................................... 2-3

Applications.................................................................................................3

Specications..............................................................................................3

Product Description ....................................................................................4

Operating Instructions............................................................................. 4-5

Charging Battery .........................................................................................6

Safety

• Theholdershouldbekeptinasafeandcleanplacetopreventdamage

orpollutionwhiletheunitisbeingused.

• Keepthelensprotectedfrombrightlight.Ifit’sunavoidableusealight/

tight cloth.

• Whendrasticallychangingthetemperatureenvironmentoftheunit

allowtheunittimetocalibratetothenewenvironment.

• Recalibratetheunitifmeasurementlastlongerthenanhour.

Features

• Compactdesignallowsforone-handedoperation

• Multi-anglemeasurement(20/60/85°)

• BacklitLCDdisplay

• Autocalibration

• Internalmemorystoreslast254datapoints

• Built-inrechargeablebattery

• DesignedtomeetASTMD523,ASTMD1455,ASTMC584and

ASTMD2457internationalstandards

• IncludesACadapter,calibrationstandard,cleaningclothandhard

carrying case

REED Instruments

1-877-849-2127 | [email protected] | www.reedinstruments.com

reedinstruments

www com

INSTRUMENTS

Applications

Floormaintenance,Surfacequalityassurance,Stoneandtile

manufacturing,Paintandinkmanufacturing&Automobilepaint

inspection.

Specifications

MeasuringRange 0.1to200GU

MeasuringGeometry 20°/60°/85°

Accuracy +/-1.0GU

Resolution 0.1GU

Repeatability +/-0.5GU

MeasuringArea 7x14mm

Display LCD

BacklitDisplay Yes

AutoShut-off Yes(after30mins)

LowBatteryIndicator Yes

PowerSupply RechargeableLithiumBattery

InternalMemory Yes(upto254datapoints)

ProductCertications CE/RoHS

OperatingTemperature 32to104°F(0to40°C)

StorageTemperature -4to140°F(-20to60°C)

OperatingHumidityRange 0-85%

Dimensions 5.5x1.8x3”(140x45x75mm)

Weight 10.76oz(305g)

REED Instruments

1-877-849-2127 | [email protected] | www.reedinstruments.com

reedinstruments

www com

INSTRUMENTS

Product Description

1. Display

2. MeasurementButton

3. Delete Button

4. ReadButton

5. Power Button

6. Angle Button

7. CalibrationButton

Operating Instructions

Power ON / OFF

Holdthe“POWER”Buttontopoweronandofftheunit.

Calibration

Pressthe“ANGLE”buttontoselecttherightmeasuringgeometry.Place

theunitintotheincludedcalibrationstandard.Takemeasurementsby

pressingthe“MEASUREMENT”button.Comparethemeasuredvalue

withthevaluemarkedonthestandardlabel.Ifitmatchesthevalue

onthetileholder,theinstrumentiswithincalibrationandreadyfor

use.Ifthemeasuredvaluedoesnotmatchtheassignedvalue,press

the“CALIBRATION”button.Itisnecessarytoinspecttheconditionof

thecalibrationtileandinstrumentopticsbeforeeachuse.Anydustor

debrisontheopticshouldberemovedfromthelensesusingdryclean

air,thelensesmustnotbetouched.Ifthereareanypermanentmarks

orscratchesonthelens,theunitisnolongersuitableformeasuring

andshouldbereturnedtoanauthorizeddistributor.Thecalibrationtile

mustbeperfectlycleanfromsmearsandscratchesbeforeattempting

calibration.Fingerprintsanddustcanberemovedwiththesupplied

optic cleaning cloth.

REED Instruments

1-877-849-2127 | [email protected] | www.reedinstruments.com

reedinstruments

www com

INSTRUMENTS

Measurement

Placethemeasurementapertureagainstthematerial.Takemeasurements

bypressingthe“MEASUREMENT”button.Thereadingthatdisplays

within2secondsistheglossvalueatthatposition.Eachresultis

automaticallyloggedinthememory.Findthecenterofmeasurement

bytheintersectionofthearrowsmarkedonthefrontandsideofthe

instrument.

Data Logging

Allmeasurementsareautomaticallystoredinternally.254groupsofdata

canbestored.Whenmemorybecomesfullitwillautomaticallydeletethe

oldest data entry.

Data Recall

Wheninmeasuringmode(Markedby’M’onthedisplay)pressthe

“READ”buttontoaccessloggeddata(Markedby‘R’onthedisplay).

Pressthe“READ”buttoncyclethroughthevaluesforwards,pressthe

“CALIBRATION”buttontocyclethroughbackwards.Togetbacktothe

measuringmodepressanybuttonotherthen“READ&CALIBRATION”.

Delete Data

Wheninmeasuringmode(Markedby’M’onthedisplay)youcandelete

themostrecentlyloggeddatabypressingthe“DELETE”button.Toclear

thedatainmemorypressthe“DELETE”buttonfor3seconds.Thestored

readingwillbecome000.

REED Instruments

1-877-849-2127 | [email protected] | www.reedinstruments.com

reedinstruments

www com

INSTRUMENTS

Charging Battery

Whenthebatteryislowabatteryiconwillappearonthedisplayofthe

unit.Thepoweradaptershouldbeconnectedtotheinstrumentsand

pluggedintoapoweroutlet.Itcantakeupto5hourstobefullycharged.

Theinstrumentcanstillbeusedwhilethebatteryisbeingcharged.

ForserviceonthisoranyotherREEDproductorinformationonother

REEDproducts,contactREEDInstrumentsatinfo@reedinstruments.com.

Notes _________________________________________

________________________________________________

REED Instruments

1-877-849-2127 | [email protected] | www.reedinstruments.com
