Red lion IAMS 0001 Manuel utilisateur

US/UK

Page 1

Page 29

Seite 57

Models No. 0001 /

0011 / 0010

Drawing No. LP0767

Version No. 104

Revision Date 15/07

IAMS

IAMS 0001 / 0011 / 0010

CONTENTS

Warning! ............................................................................. 2

Symbol identification.......................................................... 3

Safety instructions.............................................................. 3

How to dismantle the IAMS Devices ................................. 5

When front LED lights red / display shows AO.ER............ 5

Advanced features ............................................................. 6

Application ......................................................................... 6

Technical characteristics.................................................... 6

PGMMOD00 Display/programming front.......................... 7

Applications........................................................................ 8

Order codes ....................................................................... 9

Electrical specifications...................................................... 9

Visualisation of sensor error detection and

input signal outside range ................................................. 13

Sensor error detection limits.............................................. 14

Error indications ................................................................. 14

connections........................................................................ 15

Block diagram .................................................................... 16

Setup / operating the function keys................................... 17

Routing diagram................................................................. 23

Routing diagram................................................................. 26

Advanced settings (ADV.SET) ............................................ 26

Scrolling help text in display line 3 .................................... 27

Graphic depiction of relay action Setpoint ........................ 28

Graphic depiction of relay action Window......................... 28

WARNING!

The IAMS devices are designed for connection to hazardous

electric voltages.

Ignoring this warning can result in severe personal injury or

mechanical damage.

To avoid the risk of electric shock and fire, the safety instruc-

tions of this manual must be observed and the guidelines

followed. The specifications must not be exceeded, and the

devices must only be applied as described in the following.

Prior to the commissioning of the devices, this manual must be

examined carefully.

Only qualified personnel (technicians) should install these

devices. If the equipment is used in a manner not specified by

the manufacturer, the protection provided by the equipment

may be impaired.

WARNING

To keep the safety distances, the relay contacts on the devices

must not be connected to both hazardous and non-hazardous

voltages at the same time.

The IAMS devices must be mounted on a DIN rail according to

DIN 46277.

WARNING!

Until the devices are fixed, do not connect hazardous voltages

to the devices.

The following operations should only be carried out on

disconnected devices and under ESD safe conditions:

General mounting, connection and disconnection of wires.

Troubleshooting the devices.

Repair of the device must be done by Red Lion Controls only.

HAZARD-

OUS

VOLTAGE

INSTAL-

LATION

GENERAL

WARNING

Do not open the front plate of the devices as this will cause

damage to the connector for the display / programming module

PGMMOD00. The devices contain no DIP-switches or jumpers.

SYMBOL IDENTIFICATION

Triangle with an exclamation mark: Warning / demand.

Potentially lethal situations.

The CE mark proves the compliance of the devices with

the essential requirements of the directives.

The double insulation symbol shows that the devices

are protected by double or reinforced insulation.

SAFETY INSTRUCTIONS

DEFINITIONS:

Hazardous voltages have been defined as the ranges: 75 to 1500 Volt DC, and

50 to 1000 Volt AC.

Technicians are qualified persons educated or trained to mount, operate, and

also troubleshoot technically correct and in accordance with safety regulations.

Operators, being familiar with the contents of this manual, adjust and operate

the knobs or potentiometers during normal operation.

RECEIPT AND UNPACKING:

Unpack the device without damaging it and make sure that the manual always

follows the device and is always available. The packing should always follow

the device until this has been permanently mounted.

Check at the receipt of the device whether the type corresponds to the one

ordered.

ENVIRONMENT:

Avoid direct sunlight, dust, high temperatures, mechanical vibrations and shock,

as well as rain and heavy moisture. If necessary, heating in excess of the stated

limits for ambient temperatures should be avoided by way of ventilation.

All devices fall under Installation Category II, Pollution Degree 1, and Insulation

Class II.

MOUNTING:

Only technicians who are familiar with the technical terms, warnings, and instruc-

tions in the manual and who are able to follow these should connect the devices.

Should there be any doubt as to the correct handling of the devices, please

contact your local distributor or, alternatively, Red Lion Controls Worldwide

Headquarters, 20 Willow Springs Circle, York, PA 17406 USA, Phone: +1 (717)

767-6511, Fax: +1 (717) 764-0839

Mounting and connection of the devices should comply with national legislation

for mounting of electric materials, i.a. wire cross section, protective fuse, and

location. Descriptions of input / output and supply connections are shown in the

block diagram and side label.

The following apply to fixed hazardous voltages-connected devices:

The max. size of the protective fuse is 10 A and, together with a power

switch, it should be easily accessible and close to the device. The power

switch should be marked with a label indicating that it will switch off the

voltage to the device.

Year of manufacture can be taken from the first two digits in the serial number.

UL INSTALLATION REQUIREMENTS:

Use 60/75°C copper conducters only

For use only in pollution degree 2 or better

Max. ambient temperature..................... 60°C

Max. wire size......................................... AWG 26-14

UL file number........................................ E324843

CALIBRATION AND ADJUSTMENT:

During calibration and adjustment, the measuring and connection of external

voltages must be carried out according to the specifications of this manual. The

technician must use tools and instruments that are safe to use.

NORMAL OPERATION:

Operators are only allowed to adjust and operate devices that are safely fixed

in panels, etc., thus avoiding the danger of personal injury and damage. This

means there is no electrical shock hazard, and the device is easily accessible.

CLEANING:

When disconnected, the devices may be cleaned with a cloth moistened with

distilled water.

LIABILITY:

To the extent that the instructions in this manual are not strictly observed, the

customer cannot advance a demand against Red Lion that would otherwise

exist according to the concluded sales agreement.

HOW TO DISMANTLE THE IAMS DEVICES

First, remember to demount the connectors with hazardous voltages.

Picture 1:

Detach the device from the DIN rail

by lifting the bottom lock.

When front LED lights red / display shows AO.ER

IAMS0001 and IAMS0011 are designed with a high safety level. Therefore, a

continuous measurement of the outgoing current is carried out on a 4...20

mA output signal. If the current output signal is different from the internally

calculated output value or the current output is 0 (due to e.g. an open circuit

breakage), an error mode switches on the red front LED and disables the

relays. This function is not a default option but must be actively selected via

the programming menu (S4...20 & S20...4).

The error mode can only be reset by switching off and then switching on the

supply voltage to the device.

IAMS 0001 / 0011 / 0010

• Input for RTD, TC, Ohm, potentiometer, mA and V

• 2-wire supply > 16 V

• FM-approved for installation in Div. 2

• Output for current, voltage and 2 relays

• Universal AC or DC supply

Advanced features

• Programmableviadetachabledisplayfront(PGMMOD00),process

calibration, signal and relay simulation, password protection, error diagnostics

and selection of help text in several languages.

Application

• Linearised,electronictemperaturemeasurementwithRTDorTCsensor.

• Conversionoflinearresistancevariationtoastandardanaloguecurrent/volt

age signal, i.e. from solenoids and butterfly valves or linear movements with

attached potentiometer.

• Powersupplyandsignalisolatorfor2wiretransmitters.

• Processcontrolwith2pairsofpotentialfreerelaycontactsandanalogue

output.

• Galvanicseparationofanaloguesignalsandmeasurementoffloatingsignals.

• TheIAMS0001andIAMS0011havebeendesignedaccordingtostrictsafety

requirements and are thus suitable for application in SIL 2 installations.

Technical characteristics

• WhenthedevicesareusedincombinationwiththePGMMOD00display/

programming front, all operational parameters can be modified to suit any

application. As the devices are designed with electronic hardware switches, it

is not necessary to open them for setting of DIP-switches.

• Agreen/redfrontLEDindicatesnormaloperationandmalfunction.Ayellow

LED is ON for each active output relay.

• Continuouscheckofvitalstoreddataforsafetyreasons.

• 4port2.3kVACgalvanicisolation.

PGMMOD00 DISPLAY/PROGRAMMING FRONT

Functionality

The simple and easily understandable menu structure

and the explanatory help texts guide you effortlessly and

automatically through the setup steps, thus making the

product very easy to use. Functions and setup options are

described in the section ”Setup / operating the function

keys”.

Application

• Communicationsinterfaceformodificationofoperationalparametersinthe

IAMS devices.

• Canbemovedfromonedevicetoanotherofthesametypeanddownload

the setup of the first device to subsequent devices.

• Fixeddisplayforreadoutofprocessdataandstatus.

Technical characteristics

• LCDdisplaywith4lines;Line1(H=.2inch/5.57mm)showsinputsignal,

line2(H=.2inch/3.33mm)showsunits,line3(H=.13inch/3.33mm)shows

analogue output or tag no. and line 4 shows communication and relay status.

• Programmingaccesscanbeblockedbyassigningapassword.The

password is saved in the device in order to ensure a high degree of

protection against unauthorised modifications to the setup.

Mounting / installation

• ClickPGMMOD00ontothefrontofthedevice.

4 3 2 44

10 V

1 V

10 V

1 V

APPLICATIONS

Input signals:

Current

Volt-

age

Potenti-

ometer RTD and lin.R TC

Connect., wires

Output signals:

Relays

Supply:

21.6...253 VAC

19.2...300 VDC

Analogue, 0/4...20 mA and voltage

Order codes

IAMS0001 Universal transmitter with analog output

IAMS0011 Universal transmitter with analog output / 2 relays

IAMS0010 Universal limit switch with 2 relays

PGMMOD00 Display / programming module

Electrical specifications

Specifications range:

-20°C to +60°C

Common specifications:

Supply voltage, universal ............................ 21.6...253 VAC,

or 19.2...300 VDC

Max. consumption....................................... ≤2.5 W

Fuse............................................................. 400 mA SB / 250 VAC

Isolation voltage, test / operation ............... 2.3 kVAC / 250 VAC

Communications interface .......................... Programming front PGMMOD00

Signal / noise ratio ...................................... Min. 60 dB (0...100 kHz)

Response time (0...90%, 100...10%):

Temperature input................................... ≤ 1 s

mA / V input............................................ ≤ 400 ms

Calibration temperature............................... 20...28°C

Display resolution: The temperature display automatically changes to tenths

with values less than 1000 degrees.

Accuracy, the greater of the general and basic values:

General values

Input

type Absolute

accuracy Temperature

coefficient

All ≤±0.1% of span ≤±0.01% of span / °C

Autres manuels pour IAMS 0001

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels red lion Unité de contrôle

red lion

red lion PAXCDL Manuel utilisateur

red lion

red lion ITMS4037 Manuel utilisateur

red lion

red lion DA 8DI Manuel utilisateur

red lion

red lion Graphite Series Instructions d'utilisation et d'entretien

red lion

red lion MODULAR CONTROLLER SERIES Manuel utilisateur

red lion

red lion DA Series Manuel utilisateur

red lion

red lion DA 4G LTE CAT4 Manuel utilisateur

red lion

red lion GMDIO Series Manuel utilisateur

red lion

red lion CR3000 Manuel utilisateur

red lion

red lion ICM4 Manuel utilisateur

red lion

red lion ITMA DC Manuel utilisateur

red lion

red lion PM-50 Manuel utilisateur

red lion

red lion IRMA Manuel utilisateur

red lion

red lion Gemini 5200 Manuel utilisateur

red lion

red lion Graphite GMDIO Manuel utilisateur

red lion

red lion CSOUT Manuel utilisateur

red lion

red lion ITMA Manuel utilisateur

red lion

red lion Graphite GMUIN4 Manuel utilisateur

red lion

red lion PM-50 Manuel utilisateur

red lion

red lion Graphite GMSG1 Manuel utilisateur

red lion

red lion PX2FCA Manuel utilisateur

red lion

red lion ICM5 Manuel utilisateur

red lion

red lion IAMA Series Manuel

red lion

red lion Graphite Crimson GMCC Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur

red lion IAMS 0001 Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques
