Razer RZ01-0299 Manuel utilisateur
USER MANUAL FOR
WIRELESS MOUSE
(MODEL: RZ01-0299)
WHICH ALSO CONSIST OF
A USB DONGLE (MODEL:
DGRFG6)
23 MAY
2020
FOR GAMER S. BY GAMERS.™
1
WHAT’S INSIDE
Wireless Mouse (Model: RZ01-0299)
A. Left mouse button
B. Right mouse button
C. Scroll wheel
D. Left tilt-click
E. Right tilt-click
F. Cycle DPI stage up button
G. Status indicator
H. Mouse button 5
I. Mouse button 4
J. Micro-USB port
K. Ultraslick mouse feet
L. 5G optical sensor
M. USB dongle compartment
N. Slider switch
Bluetooth mode
Power off mode
2.4GHz mode
O. Pairing indicator
P. Pair/switch button
Q. 2.4GHz Wireless USB dongle
R. USB cable
DPI stages are as follows: 800, 1800 (default), 3200, 5000, and 10000. The DPI stages can be
customized using Razer Synapse 3.
FOR GAMER S. BY GAMERS.™
2
WHAT’S NEEDED
PRODUCT REQUIREMENTS
PC with a free USB port or Bluetooth connectivity
LET’S GET YOU COVERED
You’ve got a great device in your hands complete with a 2-year limited warranty coverage. Now
maximize its potential and score exclusive Razer benefits by registering at razerid.razer.com
Got a question? Ask the Razer Support Team at support.razer.com
Your product’s serial number
can be found here.
FOR GAMER S. BY GAMERS.™
3
GETTING STARTED
CHARGING YOUR RAZER RZ01-0299
Plug the USB cable from your computer’s USB port to your Razer RZ01-0299.
This connection also acts as the WIRED MODE for your device.
For best results, please fully charge your Razer RZ01-0299 before using it for the first time. A depleted
battery will be fully charged in approximately 4 hours. If the Razer RZ01-0299 has not been used for
an extended period, you may need to recharge it before use.
The Razer RZ01-0299 requires a USB connection that can supply sufficient power to charge the
battery. The battery charging process of the Razer RZ01-0299 may be affected if connected to a non-
powered USB hub or non-powered USB ports found on certain keyboards and other peripherals.
When in doubt, it’s preferable to connect the Razer RZ01-0299 directly to the USB port of your
computer.
CHARGING INDICATOR
While plugged in, the Razer RZ01-0299 ’s status indicator will display its current battery level (as
shown below).
Battery level Color Effect
<25% Red Breathing
26-50% Orange Breathing
FOR GAMER S. BY GAMERS.™
4
51-75% Yellow Breathing
76-99% Green Breathing
100% Green Static
LOW POWER INDICATOR
The Razer RZ01-0299 ’s status indicator will blink red twice in repeated intervals to indicate that the
battery’s power is less than 5%. This lighting sequence will repeat until the battery is drained or the
mouse is connected to the PC via the charging cable.
You can also check the Razer RZ01-0299’s battery level by moving the slider switch from power off to
either Bluetooth or 2.4Ghz mode. The status indicator will light up in the color according to the
mouse’s current power level (as shown below).
Battery level Color
<25% Red
26-50% Orange
51-75% Yellow
76-100% Green
FOR GAMER S. BY GAMERS.™
5
CONNECTING THE RAZER RZ01-0299 VIA 2.4 GHz MODE
1. Remove the compartment cover of the Razer RZ01-0299 and pull out the wireless USB dongle.
2. Close the compartment cover and connect the wireless USB dongle to the USB port of your
computer.
3. Switch the slider to 2.4 GHz mode. The pairing indicator will start blinking rapidly.
FOR GAMER S. BY GAMERS.™
6
4. Wait until the mouse automatically pairs with the wireless USB dongle. When paired, the
pairing indicator will change to static white for 3 seconds before turning off.
Pairing Paired
Keep the pairing devices within close proximity of each other for a faster and more stable
connection.
Congratulations, your Razer RZ01-0299 is now ready to use in 2.4 GHz mode.
CONNECTING THE RAZER RZ01-0299 VIA BLUETOOTH MODE
1. Switch the slider to Bluetooth mode ( ).
2. Select a slot for your Bluetooth device by tapping the pair/switch button. You can pair up to 3
Bluetooth devices on your Razer RZ01-0299.
Slot Color
1 (Default) Blue
2 Green
FOR GAMER S. BY GAMERS.™
7
3 Yellow
3. Press and hold the pair/switch button for 3 seconds. The pairing indicator will blink twice in
repeated intervals to show that the device is in pairing mode.
Pairing
4. Activate Bluetooth on your device and search for “Razer RZ01-0299” from the list of devices
found.
5. Wait until both devices are paired. When paired, the pairing indicator will change to static for
3 seconds before turning off.
Paired
Keep the pairing devices within close proximity of each other for faster and more stable
connection.
FOR GAMER S. BY GAMERS.™
8
Once both devices have been paired, your Razer RZ01-0299 will automatically reconnect to the device
whenever it is in Bluetooth mode and the device is within range.
Download the Razer Synapse installer from razer.com/synapse or find out more about your
brand-new mouse at support.razer.com
FOR GAMER S. BY GAMERS.™
9
SAFETY AND MAINTENANCE
SAFETY GUIDELINES
In order to achieve maximum safety while using your Razer RZ01-0299, we suggest that you adopt the
following guidelines:
Should you have trouble operating the device properly and troubleshooting does not work, unplug
the device and contact the Razer hotline or go to support.razer.com for assistance.
Do not take apart the device (doing so will void your warranty) and do not attempt to operate it
under abnormal current loads.
Keep the device away from liquid, humidity or moisture. Operate the device only within the specific
temperature range of 0°C (32°F) to 40°C (104°F). Should the temperature exceed this range, unplug
and/or switch off the device in order to let the temperature stabilize to an optimal level.
COMFORT
Research has shown that long periods of repetitive motion, improper positioning of your computer
peripherals, incorrect body position, and poor habits may be associated with physical discomfort and
injury to nerves, tendons, and muscles. Below are some guidelines to avoid injury and ensure
optimum comfort while using your Razer RZ01-0299.
Position your keyboard and monitor directly in front of you with your mouse next to it. Place
your elbows next to your side, not too far away and your keyboard within easy reach.
Adjust the height of your chair and table so that the keyboard and mouse are at or below
elbow-height.
Keep your feet well supported, posture straight and your shoulders relaxed.
During gameplay, relax your wrist and keep it straight. If you do the same tasks with your
hands repeatedly, try not to bend, extend or twist your hands for long periods.
Do not rest your wrists on hard surfaces for long periods. Use a wrist rest to support your wrist
while gaming.
Customize the keys on your keyboard to suit your style of gaming in order to minimize
repetitive or awkward motions while gaming.
Do not sit in the same position all day. Get up, step away from your desk and do exercises to
stretch your arms, shoulders, neck and legs.
