RayTalk RA-490 Manuel utilisateur

RA-490

any means, for any purpose without prior written permission.

Protected by patent.

Disclaimer

We shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or

consequential damages resulting from furnishing this material, or the performance or use of this

product. We reserve the right to change the product specification without notice. Information in this

document may change without notice.

Trademarks

Microsoft Win98, Windows 2000 and WinXP are registered trademarks of Microsoft Corporation.

General:All other brand and product names mentioned herein may be registered trademarks of their

respective owners. Customers should ensure that their use of this product does not infringe upon any

patent rights. Trademarks mentioned in this publication are used for identification purposes only and

are properties of their respective companies.

Table of Contents

1. Introduction...................................................................................................................................... 6

1-1 Package Contents ......................................................................................................................... 6

1-2 Features ........................................................................................................................................ 7

1-3 Precautions.................................................................................................................................... 7

1-4 Outlook .......................................................................................................................................... 8

1-4-1 Top Panel .......................................................................................................................... 8

1-4-2 Rear Panel ........................................................................................................................10

1-5 Technical Specifications.................................................................................................................11

1-5-1 Hardware Specifications....................................................................................................11

1-5-2 Software Specifications ...................................................................................................12

2. Installation...................................................................................................................................... 14

2-1 Wall-mounting.............................................................................................................................. 14

2-2 Connecting the Antennas ............................................................................................................ 15

2-3 Installation Requirements ............................................................................................................ 15

2-4 Getting Start................................................................................................................................. 17

2-5 How expanding your Account Generator Printer’s distance ........................................................ 18

2-6 POE Application........................................................................................................................... 19

3. Configuring the Wireless Subscriber Gateway .......................................................................... 20

3-1 Setting Wizard ............................................................................................................................. 20

3-2 Advanced Setup .......................................................................................................................... 44

3-2-1 System ............................................................................................................................ 45

3-2-2 WAN/LAN ........................................................................................................................ 49

3-2-3 Server.............................................................................................................................. 55

3-2-4 Authentication ................................................................................................................. 57

3-2-5 RADIUS Authentication ................................................................................................... 59

3-2-6 Billing............................................................................................................................... 62

3-2-7 Accounting ...................................................................................................................... 68

3-2-8 Credit Card...................................................................................................................... 81

3-2-9 Keypad ............................................................................................................................ 88

3-2-10 Customization ................................................................................................................. 96

3-2-11 Pass Through................................................................................................................ 122

3-2-12 Filtering ......................................................................................................................... 124

3-2-13 Share............................................................................................................................. 126

3-2-14 Portal Page.................................................................................................................... 127

3-2-15 Advertisement ............................................................................................................... 128

3-2-16 Walled Garden .............................................................................................................. 129

3-2-17 DDNS ............................................................................................................................ 131

3-2-18 LAN Devices ................................................................................................................. 133

3-2-19 Syslog ........................................................................................................................... 135

3-2-20 Session Trace ............................................................................................................... 142

3-2-21 SNMP............................................................................................................................ 143

3-2-22 Wireless ........................................................................................................................ 145

3-3 System Status............................................................................................................................ 149

3-3-1 System .......................................................................................................................... 150

3-3-2 Account List................................................................................................................... 152

3-3-3 Account Log .................................................................................................................. 153

3-3-4 Current User.................................................................................................................. 155

3-3-5 DHCP Client.................................................................................................................. 155

3-3-6 Session List................................................................................................................... 155

3-3-7 LAN Devices ................................................................................................................. 156

3-4 System Tools ............................................................................................................................. 156

3-4-1 Configuration................................................................................................................. 157

3-4-2 Firmware Upgrade .........................................................................................................158

3-4-3 System Account ............................................................................................................160

3-4-4 SSL Certificate .............................................................................................................. 164

3-4-5 Ping Command ..............................................................................................................165

3-4-6 Restart........................................................................................................................... 165

3-4-7 Logout ........................................................................................................................... 165

3-5 FAQ & Glossary......................................................................................................................... 166

3-5-1 Frequently Asked Questions ......................................................................................... 166

3-5-2 Glossary of Terms ......................................................................................................... 167

Appendix A. RJ-45 Connector Description ........................................................................................ 168

1. Introduction

The RA-490 Wireless Subscriber Gateway is a compact intelligent gateway integrated with a four-port

port-based VLAN switch. It provides Plug’ Play Internet access, advanced security and network

management.

The RA-490 Wireless Subscriber Gateway is designed for service providers, system integrator or

hotspot venue operator without backend-RADIUS-Server to have integrated solution for rapid

deployment, which can start hotspot service quickly and easily and enhance service performance.

The Wireless Subscriber Gateway is an ideal solution for hotel lobbies, coffee bars, airport lounges,

conference facilities and other sites that commonly host business travelers, and offers instant

high-speed Internet connections. With its IP Plug and Play technology, it accepts any client

configuration login, when client open browser the Wireless Subscriber Gateway immediately

recognizes new end-user and redirects their browser to customized Web pages. There’s no need for

end-user to change any of their default network (Static IP), e-mail (SMTP Server behind firewall), or

browser settings (HTTP Proxy) or load any special software to access hotspot service. It’s completely

Plug’ Play with any browser.

1-1 Package Contents

Please inspect your package. The following items should be included:

One RA-490 Wireless Subscriber Gateway

!Two antennas

!One AC Power Adapter for Wireless Subscriber Gateway

!One CD containing User’s Manual and MIB file

!Two screws for wall-mount

!One UTP Ethernet/Fast Ethernet cable (Cat.5 Twisted-pair)

One Account Generator Printer

!One AC Power Adapter for mini account generator printer

!One RJ-11 to DB9 male connector cable

!One Account Generator Printer User’s Guide

If any of the above items are damaged or missing, please contact your dealer immediately.

1-2 Features

!Wireless data rates up to 54Mbps

!Supports 100 Simultaneous Users

!IP Plug and Play (iPnP)

!Comprehensive security

64/128-bit WEP encryption

WPA encryption

IP/URL filtering

!Intelligent Management

!Built-in AAA (Authentication/Accounting/Authorization) and Billing mechanism

Note: The "PnP" Function only can be used with TCP/IP-based Network.

1-3 Precautions

!Never remove or open the cover. You may suffer serious injury if you touch these parts.

!Never install the system in the wet locations.

!Use only the original fitting AC power adapter otherwise there is a danger of severe electrical shock.

!Avoid exposing the Wireless Subscriber Gateway to direct sunlight or another heat source.

!Choose a well-ventilated area to position your Wireless Subscriber Gateway.

1-4 Outlook

Figure 1-1 RA-490 Wireless Subscriber Gateway Outlook

1-4-1 Top Panel

The top panel of the Wireless Subscriber Gateway is shown below.

Figure 1-2 RA-490 Wireless Subscriber Gateway Top Panel

Figure 1-3 LEDs

LEDs Indication

LED State Description

Off The Wireless Subscriber Gateway is not receiving electrical power.PWR

Green The Wireless Subscriber Gateway is receiving electrical power.

Off The Wireless Subscriber Gateway status is defective.

Green The Wireless Subscriber Gateway status is complete.

SYS

Green (Blinking) During firmware upgrades, this system LED will blink.

Off Port has not established any network connection.

Green A port has established a valid 10/100Mbps network connection.

WAN

Green (Blinking) 10/100Mbps traffic is traversing the port.

Off Port has not established any network connection.

Green A port has established a valid 10/100Mbps network connection.

LAN-1~

LAN-4

Green (Blinking) 10/100Mbps traffic is traversing the port.

Off The Wireless is not ready.

Green The Wireless Subscriber Gateway has established a valid wireless

connection.

WLAN

Green (Blinking) The Wireless connection is active.

1-4-2 Rear Panel

The rear panel of the Wireless Subscriber Gateway is shown below.

Figure 1-4 RA-490 Wireless Subscriber Gateway Rear Panel

1. Printer: Used to connect the Account Generator Printer.

2. LAN (1-4):

The rear panel supports four auto-sensing RJ-45 ports and all ports can be auto-switched to MDI-II

connections. The LAN ports used for linking hosts or other network devices. The individual port can be

either connected to 100BaseTX networks or 10BaseT networks. When connecting to a 100BaseTX

network, the ports operate at 100Mbps in half-duplex mode or 200Mbps in full-duplex mode. When

connecting to a 10BaseT network, the ports operate at 10Mbps in half-duplex mode or 20Mbps in

full-duplex mode.

3. WAN: One Ethernet port used for linking xDSL or Cable Modem.

4. Reset Button:

The Wireless Subscriber Gateway has a reset button at the rear panel of the device. Use this function

to reset the system back to factory defaults.

5. Power Jack: Used to connect the external power supply with the Wireless Subscriber Gateway.
