Remote Office Management …

KVM and Serial access in one box

The Dominion KSX difference

Dominion KSX is the first hardware-based, integrated solution to

provide remote KVM access, serial device management and power

control in a single unit. With Dominion KSX, it's as if you are

physically present at the branch office. Unlike remote control

software solutions, Dominion KSX provides:

"One consolidated view of all IT equipment deployed at branch

office locations

"A single, platform-independent solution offering centralized,

integrated and secure control

"Network-independent access via a built-in modem for emergency

access even when the network is down

"BIOS-level control of KVM equipment and console-level control

of serial devices

Secure, remote, out-of-band access and power control

of up to 16 servers and other network devices over IP

Raritan's Dominion KSX is designed specifically to make the

management of your IT infrastructure at branch locations easier,

faster, safer and more cost-effective. This innovative device combines

secure console-level access and cold-start power control of everything

in your server closets. This means from anywhere you access the Web,

you can directly access, troubleshoot and even reboot all of your remote

equipment including:

"Domain Servers "Serial IT Equipment

"Security Interfaces "File/Print Servers

"Switches "Application Servers

"Headless Servers "Routers

"Load Balancers "Network Appliances

"Firewalls "Environmental Control

Dominion KSX Series

An unprecedented combination

of remote KVM and Serial

access in one box.

Dominion KSX 440

4 Serial Ports and 4 KVM Ports

Dominion KSX 880

8 Serial Ports and 8 KVM Ports

DominionTM KSX

www.raritan.com

Simplicity

Smart engineering translates into ease of use with:

"A single consolidated view of all servers and

other IT devices from one screen — via a web

browser; no additional software is required

"A single sign-on and single interface providing

easy access to servers and other network devices

"A built-in modem for essential emergency access

in the event of a network outage

"Point and click or command-line control of

devices

"Secure, centralized monitoring and notification

"Easy ‘Plug and Play’ installation and operation

"Convenient flash upgrades

Performance

Dominion KSX includes the features you need

for superior performance:

"High performance over low bandwidth

connections including modem, wireless,

cable, DSL and fractional T/1

"A video compression algorithm and powerful

frame-grabber technology to ensure the fastest

possible transmission of high quality video

"Tight mouse synchronization that reduces

latency, the tedious wait for key strokes and mouse-

movements to catch up with your commands

"Built-in serial port buffering to provide views of

recent console history, assisting in debugging

and, ultimately, reducing downtime

Security

Dominion KSX provides bulletproof security via:

"SSL 128-bit RSA public key, 128-bit private

key encryption

"User authentication with RADIUS support

"Use of only one additional network port to

preserve strict firewall settings

"Customizable user profiles

"User event logging

"Ability to deactivate modem and/or browser access

Anytime, anywhere access and control.

Sun Server

Windows or Linux Servers

Intrusion Alarm/HVAC

Router/Switch

PBX

PSTN

TCP/IP

Headless Server,

POS Server

Power Strip Category 5, 5e or 6 UTP cables

RJ11

Coaxial cable (CCPTxx)

Secure console level management and cold start power.

ROI

Dominion KSX pays for itself quickly by:

"Reducing costly administration of on-call

labor and outsourced service providers

"Slashing expensive down time by providing

network-independent access in emergencies

"Eliminating expensive and inconvenient

travel to remote locations

"Leveraging the centralized expertise of

IT managers, regardless of their locations

"Replacing multiple software solutions with

one single hardware solution — increasing

efficiency and saving valuable IT staff time

Features

"Built-in modem

"Dedicated power control port

"‘Plug and Play’ — no software required

"Local port for rack access

"1U Rack mountable

"Multi-platform PS/2, Sun and USB servers

"64k buffering per serial port

"SSL 128-bit encryption

"KVM console ports — choose from 4 or 8

"Serial Ports — choose from 4 or 8

Raritan Computer, Inc., founded in 1985, is the leading provider of KVM (keyboard/video/mouse) and remote management solutions for access and

control of servers and other network devices. With 18 consecutive years of profitable growth and technical innovation, Raritan makes products that

are used to control millions of servers at more than 35.000 network data centers, computer test labs, and multi-workstation environments around

the world. From the small business to the enterprise, Raritan’s complete line of compatible and scalable KVM and remote connectivity products offers

IT professionals the most reliable, flexible, and secure out of band solutions to manage data center equipment, while improving operational productivity.

When you’re ready to take control,

do it with Raritan’s Dominion KSX.

Call +31-10-2844040

or visit www.raritan.com.

A single sign-on and single interface provides one consolidated view

of all servers and IT devices at each remote office:

"No additional software is required

"Simple point and click management

"Single, fail-safe solution

One Consolidated View

Specs

Dominion KSX 880

Form Factor 1U, full width, rack mountable

Dimensions 44mm (H) x 440mm (W) x 540mm (D)

Weight 11kg

Power 110/240V auto-switching; 50-60 Hz

KVM Ports 8

Serial Ports 8

Admin Port PS/2 Keyboard; VGA Video

Environmental Requirements

Operating Temperature 0°C to 40°C

Remote Connection

Network 10/100 Ethernet (RJ45)

Modem Integrated 56K V.90 (RJ11 port)

Protocols TCP/IP, UDP, RADIUS, SNMP, SNTP

DHCP, PAP, CHAP, HTTP, HTTPS

Screen Resolutions

PC text mode 720x400

PC graphic modes 640x480, 800x600, 1024x768,

1152x864, 1280x1024

Sun®video modes 1024x768, 1152x900, 1280x1024

Warranty

Standard Two Years

Dominion KSX 440

Form Factor 1U, full width, rack mountable

Dimensions 44mm (H) x 440mm (W) x 540mm (D)

Weight 11kg

Power 110/240V auto-switching; 50-60 Hz

KVM Ports 4

Serial Ports 4

Admin Port PS/2 Keyboard; VGA Video

Environmental Requirements

Operating Temperature 0°C to 40°C

Remote Connection

Network 10/100 Ethernet (RJ45)

Modem Integrated 56K V.90 (RJ11 port)

Protocols TCP/IP, UDP, RADIUS, SNMP, SNTP

DHCP, PAP, CHAP, HTTP, HTTPS

Screen Resolutions

PC text mode 720x400

PC graphic modes 640x480, 800x600, 1024x768,

1152x864, 1280x1024

Sun®video modes 1024x768, 1152x900, 1280x1024

Warranty

Standard Two Years

Raritan is a registered trademark of Raritan Computer, Inc. Dominion is a trademark of Raritan Computer, Inc. Sun is a registered trademark of Sun Microsystems, Inc.

KSX (front view)

KSX 880 (rear view)

Ethernet Access

Dedicated

Power Control

Integrated Modem

Built-In 4 or 8 Serial Ports Built-In 4 or 8 KVM Ports

Admin Port

Raritan Computer Europe B.V. The Netherlands +31-(0)10-2844040

[email protected] www.raritan.com
