Raritan Dominion KX Manuel utilisateur

Digital KVM Switch …

KVM Control Via Web Browser

KKVVMMOOvveerrIIPPWWhheennYYoouuNNeeeeddIIttMMoosstt

Dominion KX is an enterprise-class, secure, digital KVM appliance that

combines analog switching with one of the industry’s highest-performing

KVM Over IP (remote access) technology. At the rack, Dominion KX

provides BIOS-level control of up to 32 servers and other IT devices from

a single keyboard, monitor, and mouse. But unlike most other KVM

solutions, Dominion KX features integrated remote access capabilities,

providing the same BIOS-level control of your servers from anywhere in

the world, via Web browser.

Engineered to deliver on all IT fronts, Dominion KX combines limitless

access with bulletproof security, integrated hard power control, simple

manageability, and the highest quality video available in the market.

And, it’s all in a 1U form factor that may be deployed individually or

integrated with any of Raritan’s enterprise-wide solutions including

CommandCenter™.

AArrcchhiitteeccttuurree

Dominion KX consists of two components: the digital KVM switch and

Computer Interface Modules (CIMs).

"Each CIM connects to the KVM ports of an individual server and

delivers ‘keep-alive’ keyboard/mouse emulation ensuring that servers

never hang. Plus, CIMs convert video signals for transmission over

UTP (Cat5/5e/6) cabling.

"The Dominion KX switch connects to each CIM and provides

KVM Over IP capabilities for remote access, as well as a local

access port for controlling servers at the rack.

"Remote users easily access Dominion KX from any networked workstation

via a standard Web browser.

"A true data center appliance, Dominion KX provides its entire feature

set out-of-the-box: 128-bit SSL encryption, remote power control, dual

failover Ethernet, LDAP, RADIUS, and Active Directory integration.

DDoommiinniioonnKKXXSSeerriieess

Enterprise-class digital

KVM switch with integrated local

and secure remote access

DDoommiinniioonnKKXX111166

16 KVM ports

1 user at the rack

1 remote user over the network

DDoommiinniioonnKKXX221166

16 KVM ports

1 user at the rack

2 remote users over the network

DDoommiinniioonnKKXX223322

32 KVM ports

1 user at the rack

2 remote users over the network

DDoommiinniioonnTM KKXX

www.raritan.com

Flexible, CConvenient, aand RReliable

"Anytime, Anywhere – obtain BIOS-level access

and hard power control of any server in your

data center(s) via any networked workstation

"Convenient browser-based access eliminates

headache of installing client software

"Easy Installation - Plug and Play appliance, up

and running in minutes

"Platform Independent - CIMs available for PS/2,

Sun and USB

"Consolidates multiple KVM switches as a single

integrated KVM network

"No reliance on any Windows®servers or IIS

Lowers CCosts aand IIncreases PProductivity

"Reduces expensive down-time by providing

network-independent access in emergencies

"Minimizes expensive and inconvenient travel

to remote locations

"Eliminates need for multiple keyboards, monitors

and mice - saving space and money

Secure

"SSL 128-bit RSA public key, 128-bit private key

encryption

"All data - including video transmissions is

encrypted

Combines convenient access with bulletproof security

CCaatt55CCaabbllee

DDoommiinniioonnKKXX

WWiinnddoowwss

LLiinnuuxx

SSUUNN

UUNNIIXX

NNoovveellll

LLeeggaaccyy

LAN

PSTN

CCoommppuutteerrIInntteerrffaacceeMMoodduullee((CCIIMM))

EExxtteerrnnaallMMooddeemm

((ooppttiioonnaall))

MMooddeemmAAcccceessss

RReemmoottee((NNeettwwoorrkk))AAcccceessss

LLooccaallA

Acccceessss

((ooppttiioonnaallppeerrrraacckk))

IInntthheeddiiaaggrraammbbeellooww,,DDoommiinniioonnKKXXpprroovviiddeess::

³Secure local access at the rack

³Secure remote IP-based network access from

any location within or outside of the data center

³Remote access via modem from any location at

anytime even if the network is down

Enables higher uptime and improved productivity

"Centralized authentication with LDAP,

RADIUS, or Active Directory support

"Local and remote access logged and

authenticated

"Use of only one configurable TCP port

to preserve strict firewall settings

"Customized user security profiles

Easy ttoSScale

"Leverage LAN infrastructure with only

one cable drop per rack

"Add, relocate and hot-swap components

without disruption as your data center grows

"Deploy individually or integrate with any

of Raritan’s enterprise-wide data center

solutions, including CommandCenter

Features

"1U rack-mountable form factor

"Local user port for rack access

"Integrated User Interface for remote

power control

"UTP (Cat5/5e/6) cabling

"Highest port density in the industry

"Plug and Play installation

"Multi-platform CIMs for PS/2, Sun and

USB devices

"Dual failover Ethernet

"Flash firmware upgrades

"Integrated Web-based access and

management

Raritan Computer, Inc., founded in 1985, is a leading provider of KVM (keyboard/video/mouse) and remote management solutions for access and

control of servers and other network devices. With 18 consecutive years of profitable growth and technical innovation, Raritan makes products that

are used to control millions of servers at more than 50.000 network data centers, computer test labs, and multi-workstation environments around

the world. From the small business to the enterprise, Raritan’s complete line of compatible and scalable KVM and remote connectivity products offers

IT professionals the most reliable, flexible, and secure out of band solutions to manage data center equipment, while improving operational productivity.

When you’re ready to take control,

do it with Raritan’s Dominion KX.

Call +31-10-2844040

or visit www.raritan.com

Highest QQuality KKVM OOver IIP

"Intuitive Graphical User Interface (GUI)

"High color (15-bit+) palette support

"Adaptive video settings for different bandwidth situations

"Lowest bandwidth utilization

"Fastest, tightest ‘mouse synchronization’ in the industry

"Single sign-on and single interface for one consolidated view

of all devices

Anytime, AAnywhere AAccess aand CControl

Specs

Raritan is a registered trademark of Raritan Computer, Inc. Dominion is a trademark of Raritan Computer, Inc. Windows is a registered trademark of Microsoft Corporation. Sun is a registered trademark of Sun Microsystems, Inc.

Raritan Computer Europe B.V. The Netherlands +31-10-2844040

[email protected] www.raritan.com

CIM MModel Description Dimensions ((WxDxH) Weight

DDCCIIMM-PPSS22CIM for PS/2 33mm x 76mm x 15mm 0.09 kg

DDCCIIMM-SSUUNNCIM for SUN 33mm x 76mm x 15mm 0.09 kg

DDCCIIMM-UUSSBBCIM for USB 33mm x 76mm x 15mm 0.09 kg

DDCCIIMM-SSUUSSBBCIM for SUN USB 33mm x 76mm x 15mm 0.09 kg

Specifications FFor AAll DDominion KKX Models

FFoorrmmFFaaccttoorr1U full width, rack mountable (brackets included)

OOppeerraattiinnggTTeemmppeerraattuurree

HHuummiiddiittyy

0º - 40ºC

20% - 85% RH

RReemmootteeCCoonnnneeccttiioonn

Network

Modem Port

Protocols

Dual Failover 10/100 Ethernet (RJ45)

DB9(F) DTE

TCP/IP, HTTP, HTTPS, UDP, RADIUS, LDAP(S), SNTP, DHCP, PAP, CHAP

LLooccaallAAcccceessssPPoorrtt

Video

Keyboard/Mouse

HD15(F) VGA

Mini-DIN6(F) PS/2; or USB A (F)

SSccrreeeennRReessoolluuttiioonnss

PC text mode

PC graphic mode

Sun®video mode

720x400

640x480, 800x600, 1024x768, 1152x864, 1280x1024

1024x768, 1152x900, 1280x1024

WWaarrrraannttyyTwo Years.. In addition, Raritan offers two years Extended Warranty.

Dominion KKXMModel Description Dimensions ((WxDxH) Weight Power

KKXX11116616 server ports, 1 remote user,

1 local port for use at the rack

439mm x 290mm x 44mm 3.9kg 100V/240V 50/60Hz 0.6A

KKXX22116616 server ports, 2 remote users,

1 local port for use at the rack

439mm x 290mm x 44mm 3.9kg 100V/240V 50/60Hz 0.6A

KKXX22332232 server ports, 2 remote users,

1 local port for use at the rack

439mm x 290mm x 44mm 4.1kg 100V/240V 50/60Hz 0.6A

Computer IInterface MModules ((CIMs)
