RADWAG AS X2 PLUS Guide de l'utilisateur

Start up Guide

Analytical

and Precision Balances

Analitycal Balances:

• AS X2 PLUS

Precision Balances:

• PS X2

• PS X2.M

• WLC X2

IMMB-04-02-11-21-EN

To view a complete User Manual go to the website or scan QR code:

radwag.com/en/manuals/6972

1. CONTENT

Model: AS X2 PLUS (d = 0.01 mg)

Models: AS X2 PLUS (d = 0.1 mg)

Balance

×1

Balance

×1

Weighing pan

×1

Weighing pan

×1

Draft shield

×1

Draft shield

×1

Centring ring

×1

Bottom insert

×1

Bottom insert

×1

Power adapter*

×1

Power adapter*

×1

Models: WLC X2 (d = 0.1 mg)

Balance

×1

Weighing pan

×1

Draft shield

×1

Bottom insert

×1

Power adapter*

×1

Models: PS X2 (d = 1 mg) | WLC X2 (d = 1 mg)

Balance

×1

Weighing pan

×1

Draft shield

×1

Grounding foot

×1

Foot

×3

Power adapter*

×1

*The plug type may vary by country.

Models: PS 3000.X2

Balance

×1

Weighing pan

×1

Draft shield

×1

Grounding foot

×1

Foot

×3

Power adapter*

×1

fabric dust

cover

×1

PS X2.M

Balance

×1

Weighing pan

×1

Draft shield

×1

Power adapter*

×1

Models: WLC X2 (d = 10 mg)

Balance

×1

Weighing pan

×1

Grounding foot

×1

Foot

×3

Power adapter*

×1

2. UNPACKING

1 2 3

Keep the packaging should a

warranty claim or service be required.

TOP

*The plug type may vary by country.

3. RECOMMENDATIONS AND WARNINGS

4. ACTIVITIES TO BE DONE PRIOR TO OPERATION

+40 °C

+104°F

+10 °C

+50 °F

Operate the device in a room where the temperature ranges between 10–40 °C

(50–104 °F) and where the relative humidity is below 80%.

Place the balance on a solid surface to ensure stability. To obtain stable and

repeatable weighing results, an anti-vibration table is recommended.

Place the balance away from heat

sources. Avoid exposing the balance

to the sunlight.

Avoid air drafts and air movements

at the workstation.

Avoid exposing the balance to amag-

netic ﬁeld. Do not weigh magnetic

substances.

Make sure that the balance is placed

on an even surface.

Do not place the balance in a hazard-

ous area. Do not weigh explosive

materials.

Do not place the balance on an

unstable ground exposed to shocks

and vibrations.

Keep the transport

lock should a warranty

claim or service be

required.

4.1. Transport lock removal

Models: AS X2 (d = 0.01 mg) | AS X2 (d = 0.1 mg)

1 2

Keep the transport

lock should a warranty

claim or service be

required.

4.2. Grounding spring check

Models: AS X2 (d = 0.01 mg) | AS X2 (d = 0.1 mg) | WLC X2 (d = 0.1 mg)

Models: PS X2.M | WLC X2 (d = 1 mg)

Models: PS X2.M | WLC X2 (d = 1 mg) | WLC X2 (d = 10 mg)

1 2

Check whether the grounding

spring takes its intended

location.

Make sure that the grounding

spring juts slightly out

of the hole.

Check whether the grounding

spring takes its intended

location.

Make sure that the grounding

spring juts slightly out

of the hole.

5. COMPONENTS ASSEMBLY

1 2 3 4

AS X2 (d = 0.01 mg)

Grounding foot

Install

the grounding

foot in a freely

selected

opening.

Install

the grounding

foot in a freely

selected

opening.

Models: AS X2 (d = 0.1 mg) |WLC X2 (d = 0.1 mg)

Models: PS X2 (d = 1 mg) | WLC X2 (d = 1 mg)

Models: WLC X2 (d = 10 mg)

PS X2.M

1 2 3

Install

the grounding

foot in a freely

selected

opening.

Models: PS 3000.X2

6. PREPARING FOR WORK

6.1. Temperature stabilisation

6.3. Levelling

Prior to switching the device on, let

it reach room temperature (estimated

stabilisation time: up to 8 hours).

Connect the power adapter

to DC connector.

Connect the power

adapter to the mains.

up to 8 h

1 2 3

6.2. Switching the balance on

To switch the device on,

press ON / OFF key.

Press leveling icon. Check the balance level state. The arows shows

how to move the balance foots to level the balance.

To level the balance turn its feet, keep turning

the feet until the level indicator takes central position.

Correct leveling screen. Press button

to end the operation.

USB 1 USB 2

7. PANEL AND SCREEN

7.1. Panel keys

7.2. Home screen

Proximity sensor Proximity sensor

Switching ON/OFFHome screen

Displaying

previous screen

Editable tool bar

with quick access keys

Editable information ﬁelds

(labels, text ﬁelds and buttons)

Conﬁrming an operation

or printing a report

Working modes list List of current working

mode functions

Taring

Weighing result window

Status bar

Parameters Adjustment Header

printout

Footer

printout

Tare Units Products

database

Operators

database

Databases

Zeroing

Autolevel*

*only in PLUS balances

8. BASIC OPERATIONS

8.1.1. Adjustment (for models with an internal adjustment only)

0.00000

Tare:

0.00000 g

User:

Gross:

0.00000 g

Product:

Weighing

Internal adjustment

Adjustment

Please wait...

1 2

Press “Adjustment” button. Wait for the process completion.

8.1.2. Adjustment (for models with an external adjustment only)

Balance model Mass standard

WLC 0.6.X2 500 g

WLC 2.X2 2 000 g

WLC 6.X2 5 000 g

WLC 10.X2 10 000 g

WLC 1/10.X2 10 000 g

WLC 20.X2 20 000 g

WLC 21.X2 20 000 g

The adjustment mass standard does not come with

the balance. Prior to adjustment prepare the right

mass standard. You are recommended to use mass

standard of class F1 or F2. View the table and

select the mass standard you need.

External adjustment is carried out using an external mass

standard of the right accuracy and weight value, which value

depends on balance type and capacity.

1 2

Press “Adjustment” button.

Wait for completion of the start mass

determination process.

Make sure that the weighing pan is empty

and press button to conﬁrm.

Load the weighing pan with mass standard

and press button to conﬁrm.

3 4
