Radio Pulse MG2475-EVK Manuel utilisateur

www.radiopulse.co.kr

[MG2475-EVK]

Getting Started with EVK

(No.ASW1003)

V1.0

ASW1003 [MG2475-EVK] Getting Started

V1.0 Page:2/27

www.radiopulse.co.kr

REVISION HISTORY

Version

Date

Description

VER.1.0

2015.4.27

First Version Release

ASW1003 [MG2475-EVK] Getting Started

V1.0 Page:3/27

www.radiopulse.co.kr

CONTENTS

1. INTRODUCTION................................................................................................................................... 4

2. DEFINITIONS ........................................................................................................................................ 5

3. CP210X DRIVER INSTALLATION ....................................................................................................... 6

4. OVERVIEW OF EVB ............................................................................................................................. 8

5. CHECK COM PORT .............................................................................................................................. 9

6. FIRMWARE DOWNLOAD ................................................................................................................. 11

7. PER(PACKET ERROR RATE) .............................................................................................................. 12

7.1. DOWNLOAD SAMPLE APPLICATION’S FIRMWARE.................................................................................................. 13

7.2. INTERFACE TO TERMINAL PROGRAM ........................................................................................................................ 13

7.3. STARTUP AND PARAMETER SETUP ............................................................................................................................ 14

7.3.1.

TX-Station : Startup ..................................................................................................................................... 14

7.3.2.

RX-Station : Startup..................................................................................................................................... 15

7.3.3.

TX-Station & RX-Station : Set RF channel (Optional).................................................................. 15

7.3.4.

TX-Station & RX-Station : Set PAN Identifier.................................................................................. 16

7.3.5.

TX-Station & RX-Station : Set Data Rate (Optional) .................................................................... 16

7.3.6.

TX-Station & RX-Station : Set Transmit Power (Optional)......................................................... 16

7.3.7.

TX-Station : Set Options for Transmitting (Optional) .................................................................. 17

7.3.8.

TX-Station : Set Transmitting Parameters for PER (Optional) .................................................. 19

7.3.9.

TX-Station : Set Data Pattern Parameters for PER (Optional).................................................. 20

7.4. TRANSMISSION AND RECEPTION .............................................................................................................................. 21

7.4.1.

RX-Station : Start receiving ...................................................................................................................... 21

7.4.2.

TX-Station : Start transmitting and Result ........................................................................................ 21

7.4.3.

RX-Station : Result........................................................................................................................................ 22

7.4.4.

RX-Station : Exit From PER-RX mode.................................................................................................. 23

8. RF CHARACTERISTICS ...................................................................................................................... 24

8.1. CONTINUOUS WAVE (CW)........................................................................................................................................ 24

8.2. CONTINUOUS MODULATED SPECTRUM (CM) ....................................................................................................... 24

8.3. STOP CW OR CM....................................................................................................................................................... 24

9. ADDITIONAL FUNCTIONS ............................................................................................................... 25

9.1. HELP............................................................................................................................................................................... 25

9.2. TRANSMIT ONE PACKET ............................................................................................................................................. 25

9.3. ENERGY DETECTION(ED)............................................................................................................................................ 26

9.4. REGISTER READ &WRITE .......................................................................................................................................... 26

ASW1003 [MG2475-EVK] Getting Started

V1.0 Page:4/27

www.radiopulse.co.kr

1. INTRODUCTION

MG2475-EVK(Evaluation Kit) is the development kit based on MG2475 which is an SOC

chip including RF transceiver and 8051 micro controller, by RadioPulse.

This document explains how to start with MG2475-EVK.

Additionally, this document includes how to install CP210X driver, how to download the

firmware using RadioPulse Device Programmer and how to measure PER(Packet Error

Rate) of MG2475.

Therefore, a user can easily measure the performance and RF characteristics of MG2475.

ASW1003 [MG2475-EVK] Getting Started

V1.0 Page:5/27

www.radiopulse.co.kr

2. DEFINITIONS

EVB : Evaluation Board.

LM2475-EM : Evaluation Module of MG2475.

CP210X : USB-To-UART Converter

PER : Packet Error Rate

RSSI : Received Signal Strength Indicator. It specifies the strength of the received

packet.

ED : Energy Detection. It specifies the energy level of the current RF channel.

ASW1003 [MG2475-EVK] Getting Started

V1.0 Page:6/27

www.radiopulse.co.kr

3. CP210X DRIVER INSTALLATION

CP210x on EVB is USB-to-UART controller. The driver for CP210x should be installed first,

because it makes a PC to recognize the EVB.

The following is the installation steps.

(A) Execute CP210X_VCP_Win_XP_S2K3_Vista_7.exe to install CP210x VCP drivers.

(B) At the final step of installation, check “Launch the CP210x VCP Driver Installer”and

press “Finish”.

If it is not checked, it can be reinstalled later by executing

“C:\SiLabs\MCU\CP210x\Windows...Vista_7\CP210xVCPInstaller.exe”.

(D) If the driver is not installed, it can be installed manually when CP210x is connected to the

PC. The driver is located in “C:\Program Files\Silabs\MCU\CP210x”folder.

ASW1003 [MG2475-EVK] Getting Started

V1.0 Page:7/27

www.radiopulse.co.kr

NOTICE

For other OS, the driver is available from www.silabs.com

ASW1003 [MG2475-EVK] Getting Started

V1.0 Page:8/27

www.radiopulse.co.kr

4. OVERVIEW OF EVB

Figure 1. TOP view of MG2475-EVB

The main elements of EVB are as follows;

MG2470-EVB : Evaluation Board for MG2475

LM2475-EM : Evaluation Module for MG2475

Main Power SW: Power switch

Reset SW: Reset switch

ISP SW: ISP switch

USB0-UART0 : USB port for UART0.

USB1-UART1 : USB port for UART1. The firmware should be downloaded via this

port.

LM2475-EM

(ZigBee RF Module)

MG2470-EVB

(Evaluation Board)

(J4)

MAIN POWER SW

RESET SW

ISP SW

Battery Power

OFF

(J7)

USB1-UART1

(Download)

USB0 –UART0

ASW1003 [MG2475-EVK] Getting Started

V1.0 Page:9/27

www.radiopulse.co.kr

5. CHECK COM PORT

Connect MG2475-EVB to PC using “USB1-UART1”port of EVB. Set the power switch to

“USB_ON”. Then, The PC recognizes EVB as COM port. The number of COM port is

checked as follows.

(A) Right-click on “My Computer”icon and select “Properties”.

(B) Select “Hardware”tab.

ASW1003 [MG2475-EVK] Getting Started

V1.0 Page:10/27

www.radiopulse.co.kr

NOTICE

If two or more EVBs are connected to one PC and the CP210x’s IDs are same, all expected

ports are not displayed because the number of ports are same. Then, the CP210x’s ID

should be unique by using AN144SW application released by Silicon Labs, the maker of

CP210x. The application is available from www.silabs.com
