2U Adapter Bracket Set
Installation Instructions
Kit P/N: 2UKIT-101
Patent(s) Pending
Page 2
Kit Contents
Brackets:
(2) 059 – 2 Bend Bracket
(2) 100 – 2 Bend Bracket
(2) 290 – 2 Bend Bracket
(2) 200 – 4 Bend Bracket
(2) 270 – 4 Bend Bracket
(2) 350 – 4 Bend Bracket
Bracket Installation Instructions
Step 1. Determine your rack type: There are slight differences in the installation of this kit
into a “4Post Cabinet” rack versus a “Double 2Post” rack. Follow the instructions
based on your rack type.
Rack Mount Hardware Kit:
(12) 12-24 x 3/8” Screws
(8) 10-32 x 3/8” Screws
(8) 12-24 Square Nuts
(4) 12-24 Cage Nuts
4Post Cabinet Double 2Post
Step 2. Measure the “Mounting-Depth” for your rack from the front of the “Front-
Mounting-Surface” to the back of the “Back-Mounting-Surface” (see the
¿JXUHEHORZ
tsoP2elbuoDtenibaCtsoP4
Bracket Installation Instructions (continued)
Page 3
Step 3. /RFDWHWKHEHVW¿WIRU\RXU³0RXQWLQJ'HSWK´LQWKHWDEOHEHORZ This chart
determines which adapter brackets you will need and where they should be
PRXQWHG7KHNLWLQFOXGHVSDLURIGLIIHUHQWEUDFNHWVLGHQWL¿HGDV
100, 290, 200, 270, and 350.
Bracket 059 = 0.59” wide with 2-bends
Bracket 290 = 2.90” wide with 2-bends
Bracket 200 = 2.00” wide with 4-bends
Bracket 270 = 2.70” wide with 4-bends
Bracket 350 = 3.50” wide with 4-bends
Width code is stamped on most brackets.
4Post Rack Cabinets Only
Mounting Depth (in.) Front-Adapter Type Rear-Adapter Type
24 to 24 13/16 059 200+350 (ref App. B)
24 13/16 to 25 5/8 059 200+270 (ref App. B)
25 5/8 to 26 290 270+350 (ref App. B)
26 to 26 13/16 059 350
26 13/16 to 27 1/2 059 270
27 1/2 to 28 1/4 059 200
28 1/4 to 29 1/16 200 270
29 1/16 to 29 3/4 290 270
29 3/4 to 30 1/2 270 200
Double 2Posts Only
Rack-Depth (in.) Front-Adapter Type Rear-Adapter Type
24 to 24 13/16 059 200+350 (ref App. B)
24 13/16 to 25 13/16 059 200+270 (ref App. B)
26 to 26 13/16 059 350
26 13/16 to 27 1/2 059 270
27 1/2 to 28 1/2 059 200
28 13/16 to 29 3/4 059 (ref Appendix A) 350
29 3/4 to 30 1/2 059 (ref Appendix A) 270
These tables summarize the typical brackets for a given Mounting Depth.
Not all combinations are shown.
([SHULPHQWDWLRQLVUHFRPPHQGHGLIGLI¿FXOWLHVDULVH
Bracket Installation Instructions (continued)
Page 4
Step 4. Adapter Location on Rail: All adapters in this kit occupy “2U” of rack space.
Be sure all six holes in the adapter line up with holes in the rack rail.
2U
Page 5
Bracket Installation Instructions (continued)
Step 5. Install the brackets determined by Step 3.
Refer to Slide Installation Instructions on Page 6
Assembly Notes:
1. Repeat installation shown for both sides of rack.
2. Double rear spacers are required for Mounting-Depths of 24” to 26”. Refer to Appendix B.
3. Screws shown are for racks with threaded holes. If your rack has non-threaded holes, install the
screw from the front of the rack, and use a nut on the inside against the adapter bracket.
,ILQVWDOODWLRQGLI¿FXOWLHVDULVHVHHWKHDOWHUQDWHDWWDFKPHQWPHWKRGVKRZQLQ$SSHQGL[&
(2) Front Adapters Type 059, 100 or 290
Mount with (2) 12-24 Screws per Bracket
(2) 12-24 Screws
per Bracket
(1) Rear
Adapter
See Note 3 if holes
are not threaded
Mount
Depth
Page 6
Slide Installation Instructions
Installing the Dell Slides and Cable Management Arm per Dell instructions. Align the back
of the slide as shown below. Align the front of the slide so the Blue Button is in the top hole
of the bracket.
Appendix A - Double 2Post Front-Adapters
This step is only necessary for Double 2Post racks from 28 13/16” to 30 1/2”
Install the adapter on the back (rear) side of the front C-Channel post as shown below.
Attach using (2) 12-24 screws. Repeat for both front brackets.
Front C-Channel Post
Threaded Hole
Blue Button
Page 7
Appendix B - Dual Rear-Adapters
This step is only necessary for Mounting Depths from 24” to 26”
Attach the two brackets (indicated in step 2) together as shown below using (2) Cage Nuts
and (2) 12-24 screws. Be sure the longer bracket is at the rear.
Install the bracket pairs to the Rear Rack Rail as shown below using (2) 12-24 screws.
Repeat for the opposite side.
Appendix C - Alternate Front-Adapter Installation
Due to the variety of 19” rack designs, the standard installation may not work.
7KH¿JXUHEHORZVKRZVLQVWDOODWLRQRIWKHIURQWVSDFHUZLWKWKH³86KDSH´SRLQWLQJ
outward. Install using (2) 12-24 screws. Repeat for the opposite side.
If rack holes are not threaded, install screws through the rack, then through the adapter,
and into a nut (supplied).
Short Rear-Adapter
Long
Rear-Adapter
Rear Rack Rail
Front-Adapter installed with the
“C-Shape” pointing outwards
Front Rack Rail
Warranty Statement
Innovation First, Inc. warrants our products against defects in material and workmanship for a
period of one (1) year from the date of purchase. Innovation First, Inc. liability shall be limited to
repairing or replacing, at our option, any defective product.
