RAB Lightcloud ST19 Manuel utilisateur

1(844) LIGHTCLOUD

1(844) 544-4825

WE’RE HERE TO HELP:

Welcome

LCBST19-6-E26-9TW-F-C-SS

ST19 Tunable White Filament

Lightcloud

Hello

Catalog Number:

LCBST19-6-E26-9TW-F-C-SS

Model Number:

LCBST19-6-E26-9TW-F-C-SS

Construction:

Lamp Base: E26

Electrical:

6W, 800lm

120Vac

60Hz

Lightcloud Blue is a Bluetooth mesh wireless lighting

control system that allows you to control RAB’s various

compatible devices. With RAB’s patent-pending Rapid

Provisioning technology, devices can be quickly and

easily commissioned for residential and large commercial

applications using the Lightcloud Blue mobile app. Each

device in a system can communicate with any other

device, eliminating the need for a Gateway or Hub and

maximizing the control system’s reach.

Product Features

Wireless control from your mobile device

On/oﬀ and dimming

Tunable White 2200K-4500K

Create custom scenes

Activity Mode

Sensor compatible

SmartShift™ automated circadian schedule

Schedules and automations

Direct Connect LED, No Gateway or Hub required

• Not suitable for use with dimmers and sensors

unless speciﬁcally designed for RAB Lightcloud

Blue Lamps.

• Risk of electric shock.

• Do not use where directly exposed to water.

• Not intended for use with emergency exit ﬁxtures

or emergency lights.

• Only install in operating environments between

-4°F and 113°F (-20°C to 45°C).

•

Only use the control provided with or speciﬁed by

these instructions to control this lamp. This lamp

will not operate properly when connected to a

standard (incandescent) dimmer or dimming control.

Safety Information

•

CAUTION - RISK OF ELECTRIC SHOCK. Do not use if

outer lamp envelope is damaged or broken.

Installing your Lightcloud Blue Lamp

Lightcloud Blue APP

<=60 ft.

DRYWALL

OR SIMILAR

Add an additional

Lightcloud Blue Device

to extend network range

around corners

BRICK, CONCRETE,

OR METAL WALL

Find a suitable location

Turn oﬀ power

OFF

WARNING

• Place the wall switch in the oﬀ position.

• Lightcloud Blue devices should be positioned within

60 ft. of each other.

• Building materials such as brick, concrete and steel

construction may require additional Lightcloud Blue

devices to extend around an obstruction.

• Turn oﬀ the main power at the breaker

panel or remove the fuse from the fuse box.

Installing your Lightcloud Blue Lamp

(cont’d)

Connect device to power

Power on the lamp to enter pairing

mode. While pairing, the lamp will

ﬂash on/oﬀ 5x and then dim and

ﬂash on/oﬀ 3x to indicate that it

has been paired as an Ungrouped

Device in the Lightcloud Blue app.

For ﬁrst time use, the lamp will be

ready to pair to the Lightcloud Blue app

Controlling your Lightcloud

Blue Device

Conﬁrm your device is powered on.

Download the Lightcloud Blue app from the Apple®

App Store or Google® Play store.

Tap the "add device" icon in the app to

start connecting devices.

Follow the remaining steps in the app. Create areas,

groups, and scenes to organize and control your devices.

You're all set!

Launch the App and create an account.

To restore your Lightcloud Blue ST19 Filament Tunable White

lamp to factory settings, use the following methods.

Setting Device to Pairing Mode

Method 2: Manual

Method 1: Delete from App

Open the app and access the device settings for the paired

device. Be sure that the lamp is online and select "Delete".

Power the lamp oﬀ and on 5 times consecutively. Do not

allow less than 1 second and more than 3 seconds to elapse

between switching. The lamp will ﬂash 3 times, then reset to

100% brightness at default CCT.

Functionality

All conﬁguration of Lightcloud Blue products may be

performed using the Lightcloud Blue app.

WE’RE HERE TO HELP:

1 (844) LIGHTCLOUD

1 (844) 544-4825

[email protected]

Emergency default

If communication is lost, the Lightcloud Blue lamps may fall

back to a speciﬁc state, such as turning the Lightcloud Blue

lamps on.

FCC Information:

This device complies with Part 15 of the FCC Rules. Operation is subject

to the following two conditions: 1. This device may not cause harmful

interference, and 2. This device must accept any interference received,

including interference that may cause undesired operation.

Note: This device has been tested and found to comply with the limits

for Class B digital devices pursuant to Part 15 Subpart B, of the FCC rules.

These limits are designed to provide reasonable protection against

harmful interference in a residential environment. This equipment

generates, uses, and can radiate radio frequency energy, and if not

installed and used in accordance with the instruction manual, may cause

harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment oﬀ and

on, the user is encouraged to try and correct the interference by one or

more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit diﬀerent from that

to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

To comply with the FCC’s RF exposure limits for general population /

uncontrolled exposure, this transmitter must be installed to provide a

separation distance of at least 20 cm from all persons and must not be

co-located or operating in conjunction with any other antenna or

transmitter. The manufacturer is not responsible for any radio or TV

interference caused by unauthorized modiﬁcations to this equipment.

Such modiﬁcations could void the user’s authority to operate the

equipment.

CAUTION: Changes or modiﬁcations to this equipment not expressly

approved by RAB Lighting may void the user’s authority to operate this

equipment.

1(844) LIGHTCLOUD

1(844) 544-4825

Lightcloud

Lightcloud Blue is a Bluetooth mesh wireless lighting

control system that allows you to control RAB’s various

compatible devices. With RAB’s patent-pending Rapid

Provisioning technology, devices can be quickly and

easily commissioned for residential and large commercial

applications using the Lightcloud Blue mobile app.

Each device in a system can communicate with any other

device, eliminating the need for a Gateway or Hub and

maximizing the control system’s reach.

Learn more at www.rablighting.com

Made in China

Pat. rablighting.com/ip
