Quoizel LDG8408K Instructions de montage

uoizel,Inc.

6CorporateParkway

GooseCreek,SC

29445

CustomerService

Phone631.273.2700

Fax631.231.7102

www.quoizel.com

WarningsandCautions

Turnoffelectricityatcircuitbreakerormainfuseboxbeforeinstallation.Consultalicensedelectricianifindoubt.

Theseinstructionsareprovidedforyoursafety.Itisveryimportantyoureadthemcompletelybeforeinstalling

thefixture.Westronglyrecommendthatalicensed,professionalelectricianperformtheinstallation.

Disconnectfixturefrompowersourcebeforereplacingbulbs.Makesurebulbsaregivensufficienttimetocool

beforeremoval.Donotsubjectglasspartstoanyshockwhileinoperationorshatteringmayresult.

ThankyouforpurchasingaQuoizelproduct.

Needassistancewithpartsorassembly?CallQuoizelcustomerserviceat1-631-273-2700

orvisituson-lineatwww.quoizel.com

AssemblyInstructionSheet#IS-LDG8408K

ForStyleLDG8408K

1of5

ToolsRequired:Flatheadscrewdriver,Phillipsscrewdriver,pliers,wirecutters,wire

strippers,electricaltape,safetyglasses.

EstimatedAssemblyTime:20-30minutes

Preparation:Identifyandinspectallpartsbeforebeginninginstallation.Checkpackage

contentlistanddiagramsbelowtobesureallpartsarepresent.Ifanypartsaremissing

ordamaged,donotattempttoassemble,install,oroperatethefixture.Contactcustomer

serviceforreplacementparts.

6CORPORATEPARKWAY

GOOSECREEKSC29445

wwwquoizelcom

2013uoizelInc. October2013

BulbRecommended: (1)MediumBase100WMaximum

Part Description Quantity

ACrossbar 1pc.

2pcs.

HexNut

LockWasher

PackageContents A

MountingScrew

1pc.

2pcs.

LockBall

FixtureBody

Shade 1pc.

LDG8408K

2of5

FINISH:MYSTICBLACK

GND

2.4mm

13Ga

UOIZEL R

10.5” 7.5”

7.5”Sq.

9”

6.5”Sq.

4”Dia.

4.5”

PARTNUMBER

NOTE:ALLDIMENSIONSAREROUNDEDUPTOTHENEAREST1/2"

REPLACEMENTPARTDESCRIPTION RE.

NO.

(1)100WMedium

BaseBulb

(NotSupplied)

G3731SH GLASSCLEARHAMMERED 1

ThankyouforpurchasingaQuoizelproduct.

Needassistancewithpartsorassembly?CallQuoizelcustomerserviceat1-631-273-2700

orvisituson-lineatwww.quoizel.com

3of5

AssemblyInstructionSheet#IS-LDG8408K

ForStyleLDG8408K

6CORPORATEPARKWAY

GOOSECREEKSC29445

wwwquoizelcom

2013uoizelInc. October2013

STEP2-AttachCrossbartoOutletBox

A.AttachtheCrossbar(A)toOutletBoxandsecureby

threadingOutletBoxScrews(notsupplied)intothe

MountingHolesontheOutletBox.Tightenuntilsnug.

Crossbar

Outlet

Box

OutletBox

Screw

Mounting

Hole

Figure2

STEP1-AttachMountingScrews,Lock

WashersandHexNutstoCrossbar

A.LineupasetofholesontheCrossbar(A)andHoleson

theBackplateoftheFixtureBody(F).

B.ThreadMountingScrews(B)intotheholesonthe

Crossbar(A),passLockWashers(C)andthreadHex

Nut(D)ontotheMountingScrews(B).Handtighten

untilsnug.

Figure1

Crossbar

Mounting

Screw LockWasher

HexNut

Backplate

Fixture

Body

ThankyouforpurchasingaQuoizelproduct.

Needassistancewithpartsorassembly?CallQuoizelcustomerserviceat1-631-273-2700

orvisituson-lineatwww.quoizel.com

4of5

AssemblyInstructionSheet#IS-LDG8408K

ForStyleLDG8408K

6CORPORATEPARKWAY

GOOSECREEKSC29445

wwwquoizelcom

2013uoizelInc. October2013

STEP3MakeWireConnections-

A.Usestandardwireconnectorstomakeallwire

connections.(Connectorsarenotincludedwithfixture.)

Stripandpreparewireendsaccordingtoinstructions

suppliedwithconnectors.

B.ConnectWhiteSupplyWirefromtheOutletBoxtoWhite

Wirefromfixture.

C.ConnectBlack(orRed)SupplyWirefromtheOutletBox

toBlackWirefromfixture.

D.ConnectGroundWirefromtheOutletBoxtoGround

Wirefromfixture.

E.Twistconnectorsuntilwiresaretightlyjoinedtogether.

F.Wrapeachconnectionwithapprovedelectricaltapeand

carefullystuffalltheconnectedwiresintotheOutletBox.

Figure4

Whitewirefromsupply Whitewirefromfixture

Blackwirefromsupply

(orRed)

Blackwirefromfixture

Groundwirefromsupply Groundwirefromfixture

Figure5

Figure3

Mounting

Screw

LockBall

Backplate

FixtureBody

STEP4-AttachFixtureBodytoMounting

Screw

A.PlacetheBackplateoftheFixtureBody(F)overthe

MountingScrews(B).Placecaulk(notsupplied)into

threadsofMountingBalls(E)andthreadthemontothe

MountingScrews(B).Handtightenuntilsnug.

ThankyouforpurchasingaQuoizelproduct.

Needassistancewithpartsorassembly?CallQuoizelcustomerserviceat1-631-273-2700

orvisituson-lineatwww.quoizel.com

5of5

AssemblyInstructionSheet#IS-LDG8408K

ForStyleLDG8408K

6CORPORATEPARKWAY

GOOSECREEKSC29445

wwwquoizelcom

2013uoizelInc. October2013

Figure7

Bulb

Socket

STEP6-InstallBulb

A.Thisfixtureusesstandardbulbwithamediumscrewbase.

Maximum100watts.

B.Insertbulbandscrewsnuglyintoplace.

STEP5-InstallShade

A.RemovetheSocketSpacerandtheSocketCollarfrom

theSocket.

B.PlaceShade(G)intoShadeHolderovertheSocket,

SecurebythreadtheSocketSpacerontotheSocket.

Handtightenuntilsung.

C.ThreadtheSocketCollarontotheSocketandhand

tightenuntilsnug.

Figure6

Shade

ShadeHolder

SocketSpacer

Socket

SocketCollar

STEP7ApplySiliconeSealer-

A.Makesureexteriorwallsurfaceandfixturebackplate

arefreeofdirtbeforeapplyingcaulk.Usingexterior

gradecaulk,caulkovertopofbackplateanddown

otherside.Donotcaulkbottomoffixturebackplateto

ensurepropermoisturedrainage.

Yourfixtureisnowassembledandreadytouse.

Enjoy! Exterior

GradeCaulk

Outdoor

Fixture

Backplate

ExteriorWallSurface

Figure8
