WB350 Wall Bracket
Quest WB350 Bracket Mounting Instructions
The WB350 is an installation speaker wall/ ceiling mounting
bracket to suit the Quest QM350i loudspeakers.
Its construction and a correct installation allows for multiple
and safe applications and mountings of the speaker onto a
wall, hung from a ceiling or own.
This instruction manual and the device itself are designed
to provide the best use and versatility of Quest Engineering
loudspeaker associated with that product.
This equipment is to be installed by a qualified
professional, and linked to a safe point with a security
link. A security link must be able to take the weight of the
speaker box and bracket with a safety factor.
Quest Engineering cannot be held responsible for any
injury resulting of any misuse of speaker bracket or
installation.
WARNING
Fit WB350 bracket to wall Install bolt knobs to bracket and hold
in place with rubber washers
2
1
Main Frame
M8 x 50mm
Bolt Knob
M8 x 50mm
Bolt Knob
Rubber Washer
Rubber Washer
www.questengineering.com.au
WB350 Wall Bracket
Locate box into position within the
bracket and loosely fasten bolt knobs.
34
Fully tighten bolt knobs.
Orient box to desired angle.
Fix installer safety wire (not supplied) to the
attachment point.
5 6
ATTENTION: Confirm attachment of safety
wire which must be able to carry the weight
of the speaker box.
