Quantum DXi6701 Manuel de l'opérateur

READ THIS FIRST

THIS DOCUMENT PROVIDES

INSTALLATION INSTRUCTIONS FOR

YOUR DXi6701 OR DXi6702 SYSTEM.

IMPORTANT: READ THIS ENTIRE

INSTALLATION DOCUMENT BEFORE

YOU START TO UNPACK OR INSTALL

YOUR DXi6701 OR DXi6702 SYSTEM.

www.quantum.com

DXi6701/DXi6702

Contents

DXi6701 and DXi6702 Configurations... 2

Choosing a Location .............................. 3

Installation Requirements.................. 3

Rack Space Requirements .................. 3

Environmental Conditions ................. 3

Preparing for the Installation ................ 4

Necessary Tools .................................. 4

Taking ESD Precautions ...................... 4

Unpacking the DXi6701/DXi6702........... 5

DXi6701/DXi6702 Node Packaging .... 5

DXi6701/DXi6702 Expansion Module

Packaging........................................... 8

Installing the DXi6701 or DXi6702

System.................................................. 10

Locating the Mounting Position ...... 10

Installing the DXi6701 and DXi6702

Node................................................. 11

Installing the DXi6701 and DXi6702

Expansion Module ........................... 16

Cabling the DXi6701/DXi6702 ......... 20

Initial Configuration............................. 25

Accessing the DXi6701/DXi6702

Remote Management Interface ....... 25

Completing the Getting Started

Wizard .............................................. 28

Connecting the Ethernet Cables ...... 36

Creating a Typical Backup

Configuration................................... 38

DXi6701 and DXi6702

Installation and

Configuration Guide

This guide provides basic installation and configuration instructions for the

DXi6701 and DXi6702 systems (see Figure 1). For more information, see

the

Quantum DXi6000 User’s Guide

(PN 6-67199).

Note: Make sure to take the online training for the DXi6701 and

DXi6702 in order to make the best use of your product. The online

training is available at www.quantum.com/ServiceandSupport/

StorageCareLearning/Index.aspx

Figure 1 DXi6701/DXi6702 Components

Note: This

Installation and Configuration Guide

is for DXi6701 and

DXi6702 with DXi 2.3 Software.

DXi6701/DXi6702 Node

DXi6701/DXi6702 Expansion Module

2DXi6701 and DXi6702 Configurations

DXi6701/DXi6702 Installation and Configuration Guide

DXi6701 and DXi6702 Configurations

The DXi6701 and DXi6702 are available in the following configurations (see Table 1):

Table 1 DXi6701 and DXi6702

Configurations

Configuration Usable Capacity

Expansion

Modules with

1 TB Drive (Adds

8 TB Usable

Capacity)**

Expansion

Modules with

2 TB Drive (Adds

16 TB Usable

Capacity)**

Rack Space

Required

DXi6701

•1Node

• 2 or 4 RAID controller cards*

• 6 x 1 GbE Ethernet ports

• 4 x 8 Gb Fibre Channel ports

DXi6702

•1Node

• 2 or 4 RAID controller cards*

• 2 x 1 GbE Ethernet ports

• 2 x 10 GbE Ethernet ports (optical

or Twinax)

• 4 x 8 Gb Fibre Channel ports

8 TB – – 3U for node

2U for each

expansion

module

16 TB 1 –

24 TB 2 –

24 TB – 1

32 TB 3 –

32 TB 1 1

40 TB 4 –

40 TB – 2

48 TB 5 –

48 TB 1 2

56 TB 6 –

56 TB – 3

64 TB 7 –

64 TB 1 3

72 TB 8 –

72 TB – 4

80 TB 9 –

80 TB 1 4

* DXi6701 and DXi6702 configurations with 0 or 1 expansion modules include 2 RAID controller cards. All other configurations

include 4 RAID controller cards.

** Any combination of expansion modules (with 1 TB drives or 2 TB drives) may be ordered or used for field capacity upgrades as

long as the total capacity does not exceed 80 TB. The table does not list all possible combinations.

Choosing a Location 3

DXi6701/DXi6702

Choosing a Location

Quantum recommends installing the DXi6701/DXi6702 system in a controlled or

restricted area to prevent access by untrained personnel. In addition, Quantum

recommends that system installation be performed only by qualified IT personnel.

When choosing an installation site for the DXi6701/DXi6702 system, consider the

following requirements:

•Installation Requirements on page 3

•Rack Space Requirements on page 3

•Environmental Conditions on page 3

Installation

Requirements

Review the

DXi6701 and DXi6702 Site Planning Guide

(PN 6-67200) to ensure that your

site meets the installation requirements for the DXi6701/DXi6702. You can obtain

DXi6701 and DXi6702 product documentation at: http://www.quantum.com/

dxi6700docs

Rack Space

Requirements

Tab l e 2 contains the rack requirements for the DXi6701/DXi6702 components.

Table 2 Rack Requirements

Environmental

Conditions

The installation site must have the following environmental conditions:

• Humidity: 20% to 80% (non-condensing)

• Temperature: 50° to 95°F (10° to 35°C)

• Altitude: –100 to 10,000 ft. (–30 to 3048 m)

Model 6701/6702 Node Expansion Module

Height 3U, 5.2 in. (13.2 cm) 2U, 3.5in (8.9 cm)

Width (side to side) 17.2 in. (43.7 cm) 17.2 in. (43.7 cm)

Depth (front to

back)*

26.5 in. (67.3 cm) 26.5 in. (67.3 cm)

Weight (stand alone) 72 lbs. (32.7 kg) 52 lbs. (23.6 kg)

Air Clearance Open 4 in. (10.2 cm) behind unit for proper air flow

* Without the round-hole to square-hole adapter, the depth of the node or expansion

module is 25.5 in. (64.8 cm).

4Preparing for the Installation

DXi6701/DXi6702 Installation and Configuration Guide

These environmental conditions apply when the DXi6701/DXi6702 system is in

operation.

Note: For additional specifications, refer to the

DXi6000 User’s Guide

(PN 6-67199).

Preparing for the Installation

Before you begin the installation procedure in this section, make the following

preparations as described in this section:

•Necessary Tools on page 4

•Taking ESD Precautions on page 4

Necessary Tools Provide the following tools for unpacking and installing the DXi6701/DXi6702 system:

• #2 PHILLIPS screwdriver

• Notebook PC (for setting up initial system configuration)

Taking ESD Precautions Some components within the DXi6701/DXi6702 system contain static-sensitive parts. To

avoid damaging these parts while performing installation procedures, always observe

the following precautions:

• Keep the DXi6701/DXi6702 system turned off during all installation procedures.

• Keep static-sensitive parts in their original shipping containers until ready for

installation.

• Do not place static-sensitive parts on a metal surface. Place them inside their

protective shipping bag or on an antistatic mat.

• Wear anti-static wrist bands when unpacking and handling the units, and avoid

touching connectors and other components.

Note: Dry climates and cold-weather heating environments have lower relative

humidity and are more likely to produce static electricity.

Unpacking the DXi6701/DXi6702 5

DXi6701/DXi6702

Unpacking the DXi6701/DXi6702

By following these instructions, you help ensure that the system will continue to be

safeguarded after it arrives at the installation site.

Caution: Do NOT discard the packing materials after the system is unpacked. The

packaging materials must be used if the system is relocated.

WARNING: The DXi6701/DXi6702 node and expansion module weighs 72 lbs.

(32.7 kg) and 52 lbs. (23.6 kg) respectively. A minimum of two people are

required to lift either chassis.

DXi6701/DXi6702 Node

Packaging

The box containing the DXi6701/DXi6702 node contains the following items:

• DXi6701/DXi6702 node

• Rack mount rails

• Bezel shipping bag (contains the front bezel)

• Accessory kit, which includes the following:

• Doc Kit — All models:

• Quantum Products Regulatory Documentation CD

• Registration (Warranty) card

• Terms and Conditions Document

• OST License Certificate

• Base Node Kit — All models:

• Adapter kit, Rapid Rail (1)

• Cable, CAT6, RJ45, Non-Plenum, Blue Solid, 25 ft. (2)

• Conical Spring Washer, M5, Zinc plated (8)

• Screw, M4X6, FH, Phillips (4) (Only 2 screws are required for installation. The

remaining 2 screws are extra.)

• Screw FHPH 10FX.50 SSBK 100° (8)

• Screw, 10–32 X 3/4 in., Black (2)

• C13 to C14 power cord (2)

• North American power cord (2)

•BezelKeys

• Cable Kit QUAD 1GbE NIC — DXi6701:

• Cable, CAT6, RJ45, Non-Plenum, Blue Solid, 25 ft. (4)

6Unpacking the DXi6701/DXi6702

DXi6701/DXi6702 Installation and Configuration Guide

• Cable Kit Dual 10 GbE NIC — DXi6702 Optical:

• Cable, 10 GbE, 10 meter (2)

• Cable Kit Dual 10 GbE NIC — DXi6702 Twinax:

• Cable, 10 GbE, 5 meter (2)

• Cable Kit DUAL FC HBA :

• Cable, 10 GB, 6 meter (2)

• Loose Items:

•Nodebezel

• Installation Guide

• Drive Slot Serial Number Map

Carefully unpack and remove the components from the packing materials (see Figure 1).

Unpacking the DXi6701/DXi6702 7

DXi6701/DXi6702

Figure 1 Unpacking the

DXi6701/DXi6702 Node

Foam

Box

Rack mount rails

Front bezel

Accessory kit

Bezel shipping bag

Foam

8Unpacking the DXi6701/DXi6702

DXi6701/DXi6702 Installation and Configuration Guide

DXi6701/DXi6702

Expansion Module

Packaging

The box containing the DXi6701/DXi6702 expansion module contains the following

items:

• DXi6701/DXi6702 expansion module

• Rack mount rails

• Bezel shipping bag (contains the front bezel)

• Accessory kit, which includes the following:

• Base Expansion Module Kit – All Models:

• Adapter Kit, Rapid Rail (1)

• Screw, M4X6, FH, Phillips (4)

• Screw, 10–32 X 3/4 in., Black (2)

• Conical Spring Washer, M5, Zinc Plated (8)

• Screw FHPH 10FX.50 SSBK 100° (8)

• C13 to C14 power cord (2)

• North American power cord (2)

• SAS interconnect cable

• Storage Capacity License Certificate

• Loose Items:

• Expansion module bezel

• Drive Slot Serial Number Map

Carefully unpack and remove the components from the packing materials (see Figure 2).
