Quantum DLT-V4 Manuel utilisateur

Document 81-81529-01, A01, December 2005 1

Quantum SuperLoader 3

User’s Guide Addendum

DLT-V4 Tape Drive

General Information 3

Overview 3

SuperLoader 3 DLT-V4.............................................................................................4

Physical Specifications 4

Autoloader Performance Specifications 4

Environmental Specifications 5

Autoloader Power Specifications 6

Autoloader Vibration Specifications 6

Autoloader Shock Specifications 7

Tape Drive Specifications 7

DLT-V4 Drive Specifications....................................................................................7

Media Capacity ..........................................................................................................7

Media Specifications .................................................................................................8

Quantum SuperLoader 3 User’s Guide Addendum

Document 81-81529-01, A01

December 2005

Made in the USA.

Quantum Corporation provides this publication “as is” without warranty of any kind, either express or implied, including but not limited

to the implied warranties of merchantability or fitness for a particular purpose. Quantum Corporation may revise this publication from

time to time without notice.

Your right to copy this document is limited by copyright law. Making copies or adaptations without prior written authorization of

Quantum Corporation is prohibited by law and constitutes a punishable violation of the law.

TRADEMARK STATEMENT

Quantum, the Quantum logo, and SuperLoader are trademarks of Quantum Corporation, registered in the U.S.A. and other countries.

DLTtape and Super DLTtape are registered trademarks of Quantum Corporation. Products mentioned herein are for identification

purposes only and may be trademarks or registered trademarks of their respective companies.

Quantum SuperLoader 3 User’s Guide Addendum

Document 81-81529-01, A01

December 2005

General Information 3

General Information 0

This addendum is a supplement to the Quantum SuperLoader 3 User’s Guide. It

addresses the specifications and additional instructions that may be required

for the Quantum SuperLoader 3 autoloader with the Quantum DLT-V4 tape

drive.

For all other information, please refer to the Quantum SuperLoader 3 User’s

Guide.

Overview 0

Data backup is essential to protect irreplaceable information. Backing up data

to magnetic tape is an easy, cost-efficient method used by many small and

medium businesses. However, most enterprises have so much data that a

single backup tape is not enough; the information has to be spread across

numerous tapes. To avoid constantly changing tapes manually, many tape

backup systems include a Quantum SuperLoader 3 autoloader.

Each autoloader is a robot that includes a tape drive and one or two

magazines for tape cartridges. The user's application can automatically load

and unload tape cartridges as required for data backup or data retrieval.

Quantum SuperLoader 3 autoloaders provide a compact, high capacity, but

low cost method for simple, unattended data backup.

The Quantum SuperLoader 3 contains a Quantum DLT-V4 tape drive, a

Quantum LTO-2 half-height tape drive, a Quantum LTO-3 tape drive, a

Quantum VS160 tape drive, or a Quantum SDLT600 tape drive, and one or

two magazines containing up to eight cartridges each. A single cartridge can

be inserted directly via a password-protected mailslot. From the mailslot, the

cartridge can be inserted into the tape drive provided there is no cartridge

already in the drive, or you can load the cartridge into a magazine slot

provided there is no cartridge already in the slot.

The front panel on the autoloader includes a liquid crystal display (LCD)

screen and four function keys. A scrolling menu on the LCD screen allows

you to obtain information from the autoloader and enter commands. The

front panel also includes two light emitting diodes (LEDs) indicating the

autoloader's ready status and error status.

The Quantum SuperLoader 3 connects to your host server via a SCSI

connection allowing the host to send data and commands automatically. You

can also connect to the autoloader using an Ethernet connection to perform

administrative functions and download system updates.

Quantum SuperLoader 3 User’s Guide Addendum

Document 81-81529-01, A01

December 2005

4 Physical Specifications

SuperLoader 3 DLT-V4 0The autoloader is SCSI-3 compatible and operates as a single SCSI ID/two

LUN data storage device. The Quantum SuperLoader 3 DLT-V4 autoloader is

equipped with a Quantum DLT-V4 tape drive and contains up to sixteen DLT

VS1 data cartridges when utilizing two magazines, providing a compressed

capacity of 5.1 Terabytes and a sustained data transfer rate of 36 GB per hour

(native) or as high as 72 GB per hour compressed (assuming 2:1 compression).

The autoloader is compatible with the most popular operating systems and

environments supporting a Ultra 160 SCSI-3 LVD interface but requires direct

support from the operating system or a compatible backup application to take

full advantage of its many features.

Physical Specifications 0

Autoloader Performance Specifications 0

Rack Mount

Height 8.9 cm (3.5 in.)

Width 45 cm (17.7 in.)

Length 75.46 cm (29.71 in.)

Package Weight

(without media)

22.7 kg (50 lb.)

Footprint 0.32 square meters (3.4 square feet)

Maximum data

transfer rate

DLT-V4 Drive

Native: 36 GB/hr.

Compressed: 72 GB/hr. (assuming 2:1

compression ratio)

Drive Type 1 Quantum DLT-V4 drive

MCBF 400,000 cycles

Quantum SuperLoader 3 User’s Guide Addendum

Document 81-81529-01, A01

December 2005

Environmental Specifications 5

Environmental Specifications 0

Typical cycle time All Drive Types

< 40 seconds. One cycle consists of moving a

cartridge from the tape drive to a magazine slot,

selecting another magazine slot, and then

moving the cartridge back to the tape drive. It

does not include the time that the tape drive

takes to unload or load/calibrate.

Average load time to

BOT (after placing

cartridge in drive)

VS1 = < 70 seconds

Average unload time

(from BOT)

VS1 = 22 seconds (from BOT, no brush), 61

seconds (from BOT, brush)

Temperature Range (Dry Bulb)

Operating +10º to +35ºC

Nonoperating - 40ºC to +65ºC

Temperature Variation

Operating 10ºC per hour

Nonoperating 20ºC per hour

Humidity

Operating 20% to 80% noncondensing

Nonoperating 10% to 90% noncondensing

Gradient 10% per hour without condensation

Wet Bulb

Operating 26ºC max

Nonoperating 29ºC max

Altitude

Operating -153 m to 3048 m

Nonoperating -153 m to 12192 m

Quantum SuperLoader 3 User’s Guide Addendum

Document 81-81529-01, A01

December 2005

6 Autoloader Power Specifications

Autoloader Power Specifications 0

Autoloader Vibration Specifications 0

Line voltage All Drive Types

60 Hz system: 90–265 VAC;

50 Hz system: 90–265 VAC

Line frequency All Drive Types

47–63 Hz

AC Input current All Drive Types

60 Hz system: 4.0 A (RMS) for 115 VAC

50 Hz system: 2.0 A (RMS) for 230 VAC

Power consumption All Drive Types

60 Hz = 75 W; 50 Hz = 80 W

Operating

Swept Sine Vibration 5–500 Hz, 0.25 G, 0.254 mm (0.01 in.) to smooth

crossover,

1 8ve/min, (X, Y, Z) axes

Random Vibration 0.25 Grms, 5–500 Hz (X, Y, Z) axes

Non-Operating

Swept Sine Vibration 5–500 Hz, 0.75 G, 0.52 mm (0.02 in.) to smooth

crossover,

1 8ve/min, (X, Y, Z) axes

Random Vibration 1.06 Grms, 5–500 Hz (X, Y, Z) axes

Quantum SuperLoader 3 User’s Guide Addendum

Document 81-81529-01, A01

December 2005

Autoloader Shock Specifications 7

Autoloader Shock Specifications 0

Tape Drive Specifications 0

DLT-V4 Drive Specifications 0

Media Capacity 0

Operating 3 G, 5 ms half-sine, 3 pulses (+/-) per axis,

X, Y, Z

Non-Operating 20 G, 8 ms half-sine, 3 shocks (+/-) per

axis, X, Y, Z

Description Quantum DLT-V4

Read/write transfer rate:

maximum sustained (DLTtape VS1

media)

Noncompressed mode: 36 GB/hr.

Compressed (2:1 typical): 72 GB/hr.

Burst transfer rate 160 MB/s

Average access time 68 seconds (from BOT)

Loading time to BOT (for

previously written tape)

70 seconds (maximum)

Unloading time from BOT 22 seconds (no brush)

61 seconds (brush)

MCBF > 400,000 cycles at 100% duty cycle

Interface type Ultra 160 SCSI-3 LVD

Media Type Capacity

DLTtape VS1 storage capacity 5,120 GB (compressed) with 16 cartridges

Quantum SuperLoader 3 User’s Guide Addendum

Document 81-81529-01, A01

December 2005

8 Tape Drive Specifications

Media Specifications 0

Characteristic DLTtape VS1

DLTtape VS1 formatted capacity 160 GB (noncompressed)

320 GB (2:1 typical compression)

Basic description Metal particle

Tape length 562.9 m (1,847 ft.)

Cartridge dimensions 10.41 x 10.41 x 2.54 cm

(4.1 x 4.1 x 1.0 in)

Read compatibility DLT-V4, DLT VS160, DLT VS80/DLT1

Write compatibility DLT-V4

Shelf life > 30 years with < 10% loss in

demagnetization @ 20°C, 40% RH

(noncondensing)

Cartridge life 1,000,000 passes (any point on the tape

passing the recording head in either

direction)

DLT VS1 Cleaning cartridge 20 uses
