Pyronix HOMECONTROLHUB Manuel utilisateur

HOMECONTROLHUB

USER GUIDE

Document: RMKT090579-01

ii iii

HOMECONTROLHUB USER GUIDE HOMECONTROLHUB USER GUIDE

CONTENTS

Initial Set Up 4

PyronixCloud log in and Enforcer connection 4

Hik-Connect or ProControl+ log in 6

Main Screen Overview 8

Settings 11

Customise Dashboard 11

Keypad style 11

Live view camera 11

Quick actions 12

Quick Action Slot Options 13

Cameras 14

Encryption Authorisation 14

Ofﬂine Devices 14

Reordering Cameras (Drag and Drop) 14

Camera Full Screen Overview 15

Smart Homes 16

Smart Devices 16

Scenes 18

Automation 20

Smart Device Application Capabilities Chart 22

Notes 23

LightCamera

Smart Security Light Camera

SmartPlug

Plug in to the Potential

Verify alarms and take action on demand

with a remotely activated siren and two-

way talk, paired with powerful ﬂoodlights

and full-HD video.

Upgrade your home to a Smart Home

with the SmartPlug. Take control of various

plug in appliances and instantly manage

them through the App interface, creating

powerful scenes and automations.

Also available in black

• Instant control via tablet app• Built-in siren, 100dB

• 13A load• Two-way talk

• Reduce your carbon footprint• Night Vision, up to 60ft/18m

• Create scenarios via the tablet app• Motion Detection

• Connects to 2.4GHz Wi-Fi network• Dual Lights, 2500 Im

• View via tablet app

Ask your installation company for more details.

4 5

HOMECONTROLHUB USER GUIDE HOMECONTROLHUB USER GUIDE

INITIAL SET UP

PYRONIXCLOUD LOG IN AND ENFORCER CONNECTION

STEP 1

Download HomeControlHUB to a compatible tablet. Please check the Google Play

Store for a list of compatible devices.

• Select the ‘continue’ button.

STEP 2

HomeControlHUB now needs to be connected to the End User’s PyronixCloud

account.

• Enter your PyronixCloud email address and password.

• Read and accept the T&Cs

• Click ‘Sign In’.

STEP 3

HomeControlHUB will request access to the devices location. This will allow it to

search for the control panel.

• Select ‘allow’.

www.pyronixcloud.com

STEP 4

HomeControlHUB now needs to be connected to the Enforcer.

• Select ‘Set Up an Alarm System Control Panel’.

STEP 5

HomeControlHUB needs one ﬁnal security check before connecting to the panel.

• Enter the app password.

• Select ‘continue’.

6 7

HOMECONTROLHUB USER GUIDE HOMECONTROLHUB USER GUIDE

HIKCONNECT OR PROCONTROL+ LOG IN

Visual surveillance products can be linked through a Hik-Connect account which supports both the ProControl+ and Hik-Connect apps.

STEP 1

To add new or existing Hik-Connect cameras, tap the camera tab on the left side of

the main screen.

STEP 2

Select ‘Link to Hik-Connect’ to be transferred to a webpage to log into or create a

Hik-Connect account.

STEP 3

Enter the email address or phone number and the password of the existing Hik-

Connect account. Select ‘Authorized Login By Hik-Connect’

(E.g. 4407798123456)

www.pyronix.com/uk/procontrol/

If you do not have an account, scroll to the bottom and select ‘Register Hik-Connect’

to create one.

STEP 4

Any cameras that have been added to this account will now appear on the cameras

home screen.

Please note: Cameras with encrypted video streams require entry of a veriﬁcation code set in the camera when

installed.

8 9

HOMECONTROLHUB USER GUIDE HOMECONTROLHUB USER GUIDE

MAIN SCREEN OVERVIEW

Dashboard

The dashboard tab allows the user to

control the system, view a selected camera

and trigger quick actions.

Keypad

Imitates a physical keypad allowing full

programming whilst displaying the LCD

screens and scrolling through the menu.

Cameras

View live camera streams and saved

media from the cameras.

Smart home

Automate devices to activate at certain

times or when a panel event is triggered,

create scenes that activate at the touch of

a button, or switch devices on and off.

Settings

Allows for the customisation of the

dashboard including changing the visual

appearance of the dashboard, editing the

quick actions available and selecting the

quick view camera.

Company logo

If uploaded to the cloud account, the

security installation company logo will be

displayed here.

Camera quick view

A camera can be selected as a quick

view on the dashboard. This will be a live

stream from the chosen camera.

Quick actions

Conﬁgured quick actions can be selected

so that they can be triggered directly from

the dashboard.

10 11

HOMECONTROLHUB USER GUIDE HOMECONTROLHUB USER GUIDE

SETTINGS

CUSTOMISE DASHBOARD

Keypad style

STEP 1

Tap the cog symbol in the top right

corner.

STEP 2

Select ‘Customise Dashboard’.

STEP 3

Swipe up/down to scroll through the

available styles that appear on the left.

STEP 4

Tap to preview the keypad styles.

STEP 5

When a style has been selected, tap

‘save changes’ in the bottom right.

STEP 6

The keypad style has now been

changed.

Choices

Black White Ivory Navy blue Red Modern black style Modern blue style Modern white style

Live view camera

STEP 1

Tap the cog symbol in the top right

corner.

STEP 2

Select ‘Customise Dashboard’.

STEP 3

Tap ‘Change Camera’.

STEP 4

Select the camera to add to the

dashboard.

STEP 5

Tap ‘Save Changes’.

STEP 6

The camera will now appear on the

dashboard.

12 13

HOMECONTROLHUB USER GUIDE HOMECONTROLHUB USER GUIDE

Quick actions

STEP 1

Tap the cog symbol in the top right

corner.

STEP 2

Select ‘Customise Dashboard’.

STEP 3

Tap the toggle switch next to ‘Enable

Quick Actions’.

STEP 4

The quick action slots are visible to the

right. Tap to assign an action.

STEP 5

Tap the quick action category to reveal

the available actions.

STEP 6

Select the action to link to the slot and

tap ‘Save Changes’.

STEP 7

If required, repeat steps 4, 5 and 6 for

the other quick action slots.

STEP 8

Select ‘Save Changes’.

STEP 9

Swipe up/down to scroll through the

assign quick actions on the right.

QUICK ACTION SLOT OPTIONS

Smart devices

Smart devices such as SmartPlugs that have been learnt to HomeControlHUB. Unless conﬁgured

in a scene or automation, these are generally toggled on and off.

See ‘Smart Devices’ on page 16 for more information.

Scenes

Scenes are a sequence of events that are manually triggered by the user. They can include a

single or multiple smart devices and delays between the actions of the smart devices if necessary.

See ‘Scenes’ on page 18 for more information.

Installer deﬁned

Simple sets that are switched on in the panel.

Outputs

Pre-programmed actions of the security system intended to instruct another device to operate.

Typically these are physical outputs that are connected to an ancillary device such as a light, a set

of lights or an electric gate.

14 15

HOMECONTROLHUB USER GUIDE HOMECONTROLHUB USER GUIDE

CAMERAS

ENCRYPTION AUTHORISATION

If the camera on the Hik-Connect or ProControl has an encrypted video stream, it requires entry of

a veriﬁcation code conﬁgured in the camera when installed.

A camera requiring a veriﬁcation code will appear blank

with a red padlock. Tap the red padlock to enter the

veriﬁcation code.

The veriﬁcation code was created when installing the

camera. This needs entering here and tap ‘Decrypt’.

OFFLINE DEVICES

If there is an issue with a camera stream,

HomeControlHUB will display that the ‘Device is ofﬂine’.

If this message is displayed, the ﬁrst things to check/try

are:

• The camera and the network router has power

• Re-connecting the camera to the Wi-Fi

• Check if settings have changing the wireless network

and the router

REORDERING CAMERAS (DRAG AND DROP)

Press and hold on the stream that is to be moved until the

blue camera icon appears.

Drag the stream to the position the new position and then

release.

CAMERA FULL SCREEN OVERVIEW

Please note: The below functions may differ or not be accessible depending the camera

capabilities.

Mute

Press to toggle

between audio

and mute .

Stream quality

Switches the stream quality from

high deﬁnition (HD) to standard

deﬁnition (SD) and back .

Zoom

Move the slider up to zoom in

and down to zoom back out.

Once zoomed in, the screen

can be panned by swiping.

Pan

Tap the arrows to rotate/pan

the camera in that direction.

Record feed

Tap to start recording video

of the live stream. Tap again

to stop recording. This will

then be saved to the tablet.

Take screenshot

Tap to take a still image of the

current view. This will then be

saved to the tablet.

16 17

HOMECONTROLHUB USER GUIDE HOMECONTROLHUB USER GUIDE

SMART HOMES

SMART DEVICES

STEP 1

Tap the Smart Home tab on the left side

of the main screen.

STEP 2

Tap ‘Add New Smart Device’.

STEP 3

Following the on-display instructions,

place the smart device in ‘Discovery

Mode’ and press ‘Continue’.

STEP 4

Enter the Wi-Fi credentials of the network

that the smart device is to connect to and

press ‘Conﬁrm’.

STEP 5

HomeControlHUB will now scan for

smart devices in ‘Discovery Mode’.

STEP 6

Once the device in ‘Discovery Mode’,

has been found, HomeControlHUB will

install it.

STEP 7

The smart device can now be given a

name so it is easier to identify.

STEP 8

Tap ‘Done’.

STEP 9

The device appears under the ‘Smart

Devices’ column and can be toggled on

or off by tapping the device name.

18 19

HOMECONTROLHUB USER GUIDE HOMECONTROLHUB USER GUIDE

SCENES

Program a scene to initiate a series of tasks when triggered by the user, for example, switching the living room lamp on and the fan off simultaneously, or even with a delay between the two smart devices. Once

initiated, it will progress until it has completed the full sequence.

STEP 1

Tap the Smart Home tab on the left side

of the main screen.

STEP 2

Tap ‘Create New Scene’.

STEP 3

Conﬁgure the ﬁrst task of the sequence, it

can be a device action or a delay.

Run a Device

To conﬁgure a device, select ‘Run the

device’, a smart device from the drop

down menu and the function to run.

STEP 4

Select ‘Add another task’.

STEP 5

Conﬁgure the second task of the

sequence. It can be a device action or

a delay.

DELAY

To conﬁgure a delay, select ‘Select

delay’ and enter the time delay period

using the drop down boxes.

STEP 6

Repeat steps 3, 4 and 5 to add more

tasks to the sequence.

STEP 7

Tap ‘Enter a name’ and label the

scene so it can be identiﬁed on

HomeControlHUB.

STEP 8

Select a colour for the scene. This will

determine the colour of the scene in the

list. Tap ‘ﬁnish to complete.

STEP 9

The scene is now added under the

‘Scenes’ column and the sequence can

be initiated by tapping the scene.

ACTIVATE THE SCENE

As the tasks in the scene are carried out,

the smart devices can be seen switching

on or off in the ‘Smart Devices’ column.

Table des matières

Autres manuels Pyronix Système de sécurité

Pyronix

Pyronix Deltabell E Manuel utilisateur

Pyronix

Pyronix Paragon Super Manuel utilisateur

Pyronix

Pyronix Wireless Alarm system Manuel utilisateur

Pyronix

Pyronix Matrix 6/816 Manuel utilisateur

Pyronix

Pyronix STERLING 10 Manuel utilisateur

Pyronix

Pyronix PCX 256 Manuel utilisateur

Pyronix

Pyronix PCX 256 Manuel du propriétaire

Pyronix

Pyronix XD15TT Manuel utilisateur

Pyronix

Pyronix EURO 46 V10 Manuel utilisateur

Pyronix

Pyronix OCTAGON II Manuel utilisateur

Pyronix

Pyronix PCX 256 Manuel utilisateur

Pyronix

Pyronix EURO 46 V10 Manuel utilisateur

Pyronix

Pyronix Paragon E Instructions d'installation

Pyronix

Pyronix ENFORCER Series Manuel du propriétaire

Pyronix

Pyronix Enforcer 32WE Manuel utilisateur

Pyronix

Pyronix PCX 256 Manuel utilisateur

Pyronix

Pyronix Enforcer Guide de configuration

Pyronix

Pyronix ENFORCER V11 Manuel de service

Pyronix

Pyronix PCX 78 Manuel utilisateur

Pyronix

Pyronix Matrix 424 Manuel utilisateur

Pyronix

Pyronix Enforcer 32WE Manuel utilisateur

Pyronix

Pyronix ENFORCER RINS1706-1 Manuel de service

Pyronix

Pyronix V2 TEL Manuel utilisateur

Pyronix

Pyronix Enforcer V10 Manuel utilisateur

Manuels Système de sécurité populaires d'autres marques

Inner Range

Inner Range Concept 2000 Manuel utilisateur

Climax

Climax Mobile Lite R32 Instructions de montage

CADDX

CADDX NX-6 Manuel utilisateur

FBII

FBII XL-31 Series Manuel utilisateur

Johnson Controls

Johnson Controls PENN Connected PC10 Manuel utilisateur

Aeotec

Aeotec Siren Gen5 Manuel utilisateur

Blaupunkt

Blaupunkt SA 2700 Manuel utilisateur

IDEAL

IDEAL Accenta Manuel du propriétaire

AJAX

AJAX DoubleButton Manuel utilisateur

Swann

Swann SW-P-MC2 Manuel utilisateur

Ecolink

Ecolink Siren+Chime Manuel utilisateur

Digital Monitoring Products

Digital Monitoring Products XR150 Manuel utilisateur

EDM

EDM Solution 6+6 Wireless-AE Manuel utilisateur

Highway Safety Group

Highway Safety Group EA401 Manuel utilisateur

Siren

Siren LED GSM Manuel utilisateur

Detection Systems

Detection Systems 7090i Instructions de montage

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manuel utilisateur

Siemens

Siemens FDM273 Manuel utilisateur
