Pyle PPHP122SM Manuel utilisateur

Questions? Issues?

We are here to help!

Phone: (1) 718-535-1800

Email: suppor[email protected]

Wireless BTStreaming PASpeaker

and Microphone System

PPHP122SM - PPHP152SM

Portable Karaoke Speaker with Wired Mic,

Built-in LED Party Lights, FM Radio,

MP3/USB/Micro SD Readers, Speaker Stand

12’’ Subwoofer, 800 Watt MAX 15’’ Subwoofer, 1200 Watt MAX

www.PyleUSA.com2 3www.PyleUSA.com

WARNING

Illegal operation may cause personal injury, which could be fatal and may cause

damage to property.

1. DO NOT place objects on top of the device, as objects may

scratch the device.

2. DO NOT expose the device to dirty or dusty environments.

3. DO NOT insert any foreign objects into the device.

4. DO NOT expose the device to strong magnetic or electrical ﬁeld.

5. DO NOT use the device in the rain

6. Please check with your Local Authority or retailer for proper

disposaI of electronic products.

7. DO NOT disassemble the device. Only a certiﬁed service

technician should perform repair.

8. The device has apertures to disperse heat. DO NOT block the

device ventilation, the device may become hot and malfunction

as a result.

CONTROL BOARD FUNCTIONS

1. USB Control board

2. USB and MICRO SD Memory Card input jack

3. Master volume control knob

4. 3.5MM AUX input jack

5. Power switch for LED light

6. Power ON/OFF switch

7. Echo volume control knob

8. Microphone volume control knob

9. Charge LED indicator, red color for charging mode and blue color for fully charged.

10. DC 9V input jack

11. 6.5MM microphone input jack

LED POWER

DC 9V

ON ONOFF OFF

REC MODE

REP

www.PyleUSA.com4 5www.PyleUSA.com

REMOTE CONTROL FUNCTIONS

1. Standby button

2. Choose input AUX/FM/BT/USB signal

3. Mute button

4. Play/Stop button on MP3 mode,

scan function on FM mode.

5. Next song on USB/Micro SD card,

next channel on FM mode.

6. Previous song on USB/Micro SD card,

last channel on FM mode

7. EQ eﬀect on MP3 mode

8. Increase speaker volume

9. Choose song number directly

on MP3 mode

10. Stop button

11. Decrease music volume

12. Repeat song on USB/Micro SD memory card

TROUBLESHOOTING

PPHP122SM - PPHP152SM

Wireless BT Streaming PA Speaker and Microphone System

Portable Karaoke Speaker with Wired Mic, Built-in LED Party Lights,

FM Radio, MP3/USB/Micro SD Readers, Speaker Stand

Features:

• Portable PA Speaker System

• High-Powered Loudspeaker Design

• Wired Microphone for Home Karaoke Style Fun

• Wireless BT Music Streaming Ability

• Multi-Color Flashing LED Party Lights

• FM Radio with Digital LCD Display

• Built-in Rechargeable Battery

• Ported Enclosure for Extended Bass

• Full Range Stereo Sound Reproduction

• Sleek & Stylish Speaker Cabinet Housing

• Connect & Stream Audio from External Devices

• MP3 Audio File Playback

• USB Flash Memory Reader

• Micro SD Memory Card Reader

MODEL PPHP122SM PPHP152SM

Power Output 800 Watt MAX 1200 Watt MAX

Sound System 12’’ Subwoofer,

1’’Tweeter

15’’ Subwoofer,

1’’Tweeter

Total Speaker Size

(L x W x H)

13.5’’ x 11.6’’ x 21.3’’

-inches

16.9’’ x 14.2’’ x 26.3’’

-inches

Speaker Stand Height 3.2’ ft. 3.7’ ft.

1. The audio format in the U disc is

incorrect.

2. Improper operation has caused

a process disorder.

3. USB disc is disconnected.

1. Convert audio format into Mp3

format.

2. Reboot the machine.

3. Insert USB disc properly.

MP3

does not

play

Fault Possible Cause Solution

No sound

Distortion

of sound

Karaoke

does not

work

1. No input sound source.

2. Volume is too low.

1. Volume too high.

2. Speaker may be damaged

1. Microphone plug is not fully

inserted.

2. Microphone switch is not on.

3. Microphone volume knob is at

the lowest position.

1. Use a better music signal.

2. Adjust volume.

1. Turn down the volume.

2. If speaker is damaged, repair

or replace it.

1. Plug microphone properly into

the socket.

2. Turn on microphone switch.

3. Adjust microphone volume

properly.

www.PyleUSA.com6 7www.PyleUSA.com

• Aux (3.5mm) Input Jack

• 1/4’’ (6.5mm) Microphone Input

• Low Battery Level LED Indicator Light

• Rugged & Durable Molded Cabinet Design

• Convenient Rolling Wheels & Extending Carry Handle

• Used for Public Gatherings, Crowd Control, Karaoke Vocals, Stage Performances

• For Indoor/Outdoor Use

Wireless BT Streaming:

• Built-in BT for Wireless Music Streaming

• Simple & Hassle-Free Pairing

• Works with All of Today’s Latest Devices

• Smartphones, Tablets, Laptops, Computers, etc.

• Wireless BT Version: 5.0

• Wireless BT Network Name: ‘PYLEUSA’

• Wireless Range: Up to 32’ ft.

What's in the Box:

• PA Speaker System

• Speaker Stand

• Wired Microphone

• Remote Control

• Power Adapter

Technical Specs:

• Wired Mic Cable Length: 9.8’ ft.

• Speaker Stand Height: 3.2’ ft.

• Impedance: 4 Ohm

• Frequency Response: 55-20kHz

• S/N Ratio: 60dB +/-3dB

• SPL: 94dB (1W/M)

• T.H.D.: <1%

• USB Interface Type: 2.0

• Digital Audio File Support: MP3

• Maximum USB Flash Support: 32GB

• Mic Nominal Current Drain: < 100mAh

• Construction Material: Polypropylene (PP)

• Battery Life: Up to 2+ Hours

• Battery Operated Remote: (1) x CR-2025 Button Cell, Included

• PA Speaker Battery Type: 7.4V Li-ion - 1800mAh

• Speaker Power Supply: 120/240V, Adapter (9V)

This product can expose you to a chemical or group of chemicals, which may include

“Lead and lead compounds” which is known in the state of California to cause cancer, birth

defects, or other reproductive harm. For more info, go to https://www.p65warnings.ca.gov/.
