Pyle DISCOJAM2 PPSUFM1068BT Manuel utilisateur

www.PyleAudio.com

Safety Notes

Protect the unit from moisture or rain.

Keep the unit in a well ventilated environment and keep away from, direct sunlight to prevent unit from overheating.

Don't use volatile or dangerous chemical cleaners on the unit (like toluene, alcohol, gasoline etc.) Use gentle cleaners.

Do not open chassis! Extremely dangerous! Do not put your hands inside the chassis. If the device begins to malfunction do not

attempt to repair, unplug the unit and contact Pyle immediately.

Carefully handle, plug and unplug the power cable when handling. Hold the plug with a firm grip and when plugging or

unplugging from sockets.

Correct power must be used to operate this unit properly, do not use any other powering options, cords or methods.

Power On

The Speaker can be powered when connected to mains power.

1.Connect the power cable to the unit.

2.Connect the other end of power cable to mains power (your wall outlet).

3.Turn on the switch at the mains power point.

4.The unit will automatically power on when connected to mains power.

Using the Wired Microphone

You can connect the wired microphone to this unit using the MIC INPUT located on the top of control panel. You will

require an adapter if your wired microphone does not use a 1/4” plug.

NOTES: The unit features (2) 1/4'' Microphone Input Jacks

USB Flash / SD Card Playback

You can play music from USB stick or SD Card using the USB/SD slot on the PA speaker.

1. Insert your USB or SD card into the slot.

2. Once inserted the USB or SD card unit will automatically play.

3. You can use the PRE/NEXT/PLAY/PAUSE to control and play music.

NOTES: The speaker system can play the following audio file formats: MP3,The USB/SD Card no more than 32GB.

Operation may be slower when searching large memory files. It will need several seconds to respond when your

USB/SD Card full of contents.

www.PyleAudio.com

Bluetooth

Press the INPUT button which is located on top control panel. The Bluetooth is on when you hear two “tone”

indicator sound. Use your Bluetooth phone or other device to search for the PA speaker. It will displayed as 'BT

SPEAKER.'

Connect your devices with BT SPEAKER, it will pair with unit automatically. You will not need code and get connected

with unit. Play music on your phone or other device, sound will come from the speaker through the BLUETOOTH

wireless connection. You can use the VOLUME/BASS/TREBLE to adjust the sound level for BLUETOOTH, also you can

adjust the Bluetooth music sound through your own phone or other device.

Radio

Press INPUT just once, it is FM Radio.

Press PRE/NEXT to select the radio stations.

Ensure that you have an extended antenna located on the rear of the speaker. It will ensure the best possible radio

quality and signal strength.

At the first use of the radio, press NEXT button twice, it will auto search and store the radio stations.

System Features & Button Controls

Back Panel

1 DVD Input

2 Power Switch (Lights)

3 Power Switch (Main)

4 Speaker Output

5 FM Antenna

6 AC Out

7 Voltage Selector Switch

8 AC Power Supply

www.PyleAudio.com

System Features & Button Controls

Front Panel & System

1 EQ Switch

2 Bass Control

3 Treble Control

4 Volume Control

5 Line-in (Aux) Input

6 dB Display

7 Mic Input Jack

8 Mic Volume Control

9 Echo Control

10 SD Card Input

11 Previous Songs / Volume Down

12 Auto Scan for Radio Stations

13 Next Song / Volume Up

14 Input Selectors

15 Display Screen

16 USB Input

17 EQ Control

18 Speaker Handle

19 Metal Corner

20 Tweeters

21 Woofer Speaker

22 Vent Hole

23 Woofer Confinement

24 Speaker Feet
