Pyle PDMW400HD Manuel utilisateur

WIRELESS MICROPHONE

SYSTEM

INSTRUCTION

MANUAL

ONON

OFFOFF

ONON

OFFOFF

DATE: 30,07,2002

NO.

8Dimensions

Weight

Carrier Frequency Range

Power Source

Tone Osc.Frequency

RF Power Output

Spurious Emission

Tatol Harmonic Distortion

Current

ELECTRIC PARAMETER

350g(0.77 lb)

290mm/11.4"

UHF 790-865 Mhz

45dBc

DC 9V

30mA

10mW (TYPE)

32.768KHz

SPECIFICATION

INSTRUTION:

1. After operation the microphone must be switched off as well. Otherwise the batteries will soon be

exhausted. in order to avoid untune consumption of the inner battery: if pilot lamp of the wireless

microphone (1)remains lighted, it means that the battery has no more power: (2)the lamp must

flash only for the time of the switching -on; this indicates that the microphone works well.

When switches the power switch to "on" position, then the power indicator lights, indicate the

apparatus is on.

When switches the power switch to "off"position, then the power indicator lights, indicate the

apparatus is off.

2. INSTALL BATTERY:

PLS. make sure the positive/negative before you replacement batteries.

3. We congratulate you for the choice of this excellent professional apparatus microphone which

will give you outstanding results at the high fidelity. the microphone suit for school speech,

meeting speech, teachers and performer on the stage. to avoid of problem like wireless

microphone.

4. If you want to have a different frequency, set the receiver and transmitter power sw to off before

you do.

FEATURES:

"STAND-BY" funciton.

Steel net based to prevent from rolling.

OFF

GRILLE HOLDER

SWITCH COVER

SWITCH

POWER LED LIGHT

TUBE ANTENNA

TESTER: J.H.LIN

GRILLE HOLDER

SWITCH COVER

SWITCH

POWER LED LIGHT

TUBE

BATTERY INGORMATION:

NOTE: Make sure the power switch is in the "OFF" position when changing or installing new bat-

tery. Average life on an alkaline battery is 6-8 hours. Be sure to use good quality long life

9V alkaline battery only.

1. This microphone has a 3-level power switch design.

2. In using first turn on the receiver and then the transmitter.

3. New battery the power light is in "OFF".

The light is "ON". It indicates the ba needs to be replaced.

4. Remember to turn the switch "OFF".

When the microphone is not in use in order to save power. In "STAND

set the switch to the center.

ttery

-BY"

ANTENNA

CHCH

OFF

SPECIFICATION

TRANSMITTER PERFORMANCE SPECIFICATION:

Caution:

Any changes or modifications not expressly approved by the party responsible for compliance

could void the use's authority to operate the equipment.
