Pyle Pro PCA4 Manuel utilisateur

www.pyleaudio.com

PCA4

2x120W Max Stereo Power Amplifier

with AUX CD/MP3 Input

1 - Pyle Pro PCA4 Manual

FEATURES AND CONTROLS

Pyle Pro PCA4 Manual - 2

gives you the power and versatility you need in a professional sound system.

Its wide frequency response make it suitable for amplifying music or vocal

program material.

The front located 3.5mm jack allows you to connect the input of various of

MP3 devices conveniently.

Your new Pyle Pro PCA4 Stereo Power Amplifier

3 - Pyle Pro PCA4 Manual

FEATURES AND CONTROLS

(1) Blue LED Output Level Display

(2) Power On/Off and LED Indicator

Main power switch, the indicator lights when the amplifier is turned on.

(3) CD/MP3 3.5mm AUX Input Jack (FRONT)

Lets you easily connect the computerized MP3 Device (player) sources, such as

PC (CD ROM), Laptop, Walkman, iPod, and Cell Phone.

(4) MASTER Volume Control

Lets you control the overall volume level.

(5) BASS and TREBLE Controls

Allows you to boost or attenuate bass and treble for the desired sound.

(6) LINE RCA Input

Lets you connect most high level audio sources such as CD player, tape deck,

tuner, camcorder, or VCR. It is compatible with the computerized devices (MP3)

via 3.5mm to RCA Converter.

(7) Push Type Speaker Terminal

Lets you easily connect speaker wires directly to the amplifier. The speaker

impedance can be ranged from 4 to 8 Ohms for the general stereo output.

The total speaker impedance must be at least 4-Ohm per channel at stereo mode.

(8) 110/220 Voltage Selector

This amplifier has selectable input voltage from 110V/60Hz (the standard

in USA and CANADA) to 220V/50Hz (for EUROPEAN operation). Please make

sure the switch is in the proper position before operating, otherwise,

the severe damage will be incurred and not covered by the warranty.

(9) Replaceable Power Fuse

The amplifier uses a fuse for protection against surges and short circuit.

If the amplifier suddenly turns off and will not turn on, check the fuse

and if necessary replace it with a 1.5-amp, 250-volt, fast-acting, 5x20mm

fuse (not supplied).

CONNECTION DIAGRAM

Pyle Pro PCA4 Manual - 4

Specifications are typical; individual units might vary.

Specifications are subject to change and improvement without notice.

Specifications

5 - Pyle Pro PCA4 Manual

Output Power, 2 channels driven

4-Ohm, 1 kHz, 1% THD .............................................................................. 20Wx2

4-Ohm, 1 kHz, 10% THD ............................................................................. 32Wx2

Max Power ................................................................................................. 120Wx2

Total Harmonic Distortion, 1 kHz Rated Power ................................................ 0.3%

Input Sensitivity, 1 kHz, 4-Ohm Rated Power

LINE ..................................................

..........................................................

220mV

CD ............................................................................................................... 220mV

Frequency Response ............................................................

...............

20Hz-20kHz

Signal to Noise Ratio, 1 kHz, 4-Ohm Rated Power

LINE ..................................................................

.............................................

75dB

CD .................................................................................................................. 75dB

Tone Controls

BASS ............................................................................................. +/-10dB, 100Hz

TREBLE ......................................................................................... +/-10dB, 10kHz

Power Requirement ................................................. 120V AC 60Hz/230V AC 50Hz

Power Fuse ......................................................... 1.5 A, 250V fast-acting, 5x20mm

Dimensions, inches (mm) WxHxD ..................... 8.27 x 2.72 x 5.39 (210 x 69 x 137)

Weight, lbs (kg) ........................................................................................ 5.32(2.42)

Pyle Pro PCA4 Manual - 6

PYLE PRO AMPLIFIER

Your Pyle Pro Amplifier is an example of superior design and craftsmanship.

The following suggestions will help you care for your amplifier so you can

enjoy years of use:

Keep the amplifier dry. If it gets wet, wipe immediately.

Use the amplifier only in well-ventilated installations.

Handle the amplifier gently and carefully - do nto drop!

Keep the amplifier away from dust adn dirt.

Wipe occasionally with a damp cloth to keep it looking new.

Do not use harsh chemicals, solvents or detergents!

7 - Pyle Pro PCA4 Manual
