Pyle Pro Waisband Amplifier PWMA30 Manuel utilisateur

SYSTEM INCLUDES

1. Main unit

2. Headset MIC

3. User's manual

4. Belt

5. 3.5/3.5mm audio cable

SPECIFICATIONS

1. When using rechargeable batteries, you can

connect power adaptor(optional) to DC in jack

of the amplifier to charge the battery.

3. When connecting power adapter, do not use

normal non-rechargeable batteries.

4. If you are not going to use the machine for a

long time, please take out the batteries to

avoid possible damage to the main unit by

battery leakage.

Power adaptor can also supply power to

amplifier while charging the battery.

Thank you for choosing our waistband amplifier

which will bring you inconceivable, endless of

comfort and convenience in your future work

and life.

This waistband amplifier is perfect to be used in

indoor and outdoor activities such as small

meetings, parties, teaching, karaoke, sales

propagandas and auctions etc.

NOTE

USER'S MANUAL

PWMA30

Waistband Amplifier

X 1

www.pyleaudio.com

1. Max. Power 5W

2. Total harmonic distortion 5% Max

3. Frequency response 100Hz-10KHz

+/- 3db

4. Operation temperature -10 ~45

5. Power voltage DC 9V

6. Output impedance 4

11223344556677

TONE LOW BATTERY MIC IN AUDIO IN RECHARGE DC-9V POWER VOLUMETONE LOW BATTERY MIC IN AUDIO IN RECHARGE DC-9V POWER VOLUME

WaistBand AmplifierWaistBand Amplifier

PARTS DESCRIPTION

1. Tone control

2. Power/low battery indicator

3. MIC input jack

4. Audio input jack

5. Recharging indicator

6. DC input jack

7. Power switch/volume control

8. Headset MIC

1. Open the battery cover, install 6 pcs 1.5V AA

batteries or 1.2V rechargeable batteries with

same specification as per correct polarity.

Then close the battery cover.

2. Put the amplifier on waist. Adjust the attached

belt to suitable length. Then clip and fasten it

on the back side.

3. Insert the 3.5mm plug of headset MIC to

3.5mm MIC in jack of amplifier.

4. Wear the headset MIC around your head.

Keep MIC head close to your mouth.

7. AUDIO IN jack can be connected to portable

radio, CD,VCD, MP3 and other audio

equipment.

8. If the low battery indicator turns red, this

indicates battery power is low. Please change

new batteries or connect power adapter to

charge them if rechargeable batteries are

used.

. Rotate the power switch clockwise. Power

indicator will light green. Further rotate the

switch to increase the volume to suitable

level.

6. Adjust the tone control to get perfect sound

quality.

OPERATION
