pursuitrak PROPT20 Manuel utilisateur
128-7914
1 of 20
-1-
Released 6-11-07.
OWNER’S MANUAL
MODEL PROPT20
TWO-WAY TELEMATICS MODULE
128-7914
2 of 20
-2-
Congratulations-------------------
on your purchase of your PursuiTrak GPS Vehicle Tracking,
Recovery, andConvenienceDevice.Thisdevice,whenproperly installed, will
allow youtosendcommandstoyourvehicleviathe InternetorTelephone.Itwill
alsoconfirmthereceiptofsentcommands;notifyyouwhenthere isanunautho-
rizedentryinto thevehicle; andwhen thereisunauthorized vehiclemovement.
Although the device has been installed in your vehicle , you must activate the
devicebycompleting theWirelessServicesApplicationandsigntheTerms and
Conditions agreement. Seaguard Electronics, LLC., is responsible for the ve-
hicletracking,theft recovery,andwirelessservicesutilizingthePursuiTrakunit.
128-7914
3 of 20
-3-
CONTENTS
Congratulations....................................................................... ..........2
SystemConfiguration.........................................................................4
AccountActivation..............................................................................6
Wireless andTheft Recovery Fees .....................................................7
UnderstandingCommandUseand Message Credits.........................8
AccountLogin ....................................................................................9
Tracking .............................................................................................10
Schedules..........................................................................................10
Commands Page...............................................................................12
SystemSettings............................................................................13
SystemMenu................................................................................13
VehicleHistory ...................................................................................15
VehicleCommand CenterTelephoneInterface ...................................16
LoginandMenu ............................................................................17
AutomatedAlert NotificationSystem ..................................................18
IfYourVehicleHasBeenStolen..........................................................19
128-7914
4 of 20
-4-
System Configuration
Your New Vehicle Tracking device may be installed as a stand alone unit or may be connected to a host
alarm, alarm remote start or other arming device. This manual describes all the commands available for the
system but all may not be available in your application. Please consult your installation center or installing
dealer for controls and options available to you. Reading this entire manual will provide you the most com-
plete and up to date information about your system.
When installed with a host device, locking the vehicle doors with the keychain transmitter will arm the vehicle
tracking device. Unlocking the vehicle doors with the keychain transmitter will disarm the vehicle tracking de-
vice. If the keychain transmitter is lost or otherwise rendered inoperative, you must disarm the system by
manual override as specified in the owner’s manual. While the system is armed and the doors are locked, the
unit will log its position periodically checking that the vehicle has not been moved beyond the controlled area.
Whilearmed, ifthe vehiclealarm istriggered,the systemwill senda doorviolationor vehiclealarm triggeralert.
128-7914
5 of 20
-5-
Ifthe vehicleisthen movedbeyond thecontrolledarea, relativetothe loggedposition, thesystemwill sendyou
a notification of unauthorized vehicle movement.
Your accountcanbe setfortelephone and/ore-mail notifications ifyou choose.Whenreceiving anyautomated
notification alert produced by the system, it will advise you of the specific event which has triggered the notifi-
cation massage. Upon receipt of the message, you may press one (1) to acknowledge the alert message or
two(2) torepeat it.Inthe eventthatupon inspectionyou determinethatthe vehiclehas beenremovedfrom the
area where it was parked, please contact (800) 705-8766 and select option (2) to ReportAStolen Vehicle.
WARNING: When the host alarm or keyless entry system is put into the Valet mode, the
PursuiTrak device is incapable of sending any notifications in the event of a door
violation or unauthorized vehicle movement. Be certain to exit the valet mode to
ensure that your vehicle is properly protected.
128-7914
6 of 20
-6-
Account Activation
Your Car Dealer or Retailer from where you purchased the system may have already activated your account.
Please check with them to confirm that this has been completed.
Ifyour accounthas notbeen activated, youmust activateyour accounttobegin usingyour servicesandensure
theft recovery coverage. To do this, the Wireless Service Application must be completed, and the Service
Terms and Conditions agreement signed. It then must be faxed to 619-839-3780. Seaguard Electronics, LLC
providesthe Vehicle WirelessandMonitoring Services.They canbereachedat (800)705-8766.TheI.M.E.I and
a Temporary Pass Code (TPC) are located on theActivation form provided with your unit and will be required to
register the device.
I.M.E.I.Number: ______________________________________________
TemporaryPassCode (TPC): _________________________________________________
DatePurchased:_____________
The wallet card attached to the mirror hangtag is used to record your password. This wallet card will include the
phone number to call when you want to send commands to the vehicle. Print your chosen password on the
card and store it in your wallet or purse for easy access and reference. Your vehicle is also accessible for
command control via the internet as directed on page 9 of this manual.
Note: IT IS THE CUSTOMER’S RESPONSIBILITY TO CONFIRM THAT THEIR UNIT IS
REGISTERED WITH SEAGUARD ELECTRONICS, LLC FOR WIRELESS SERVICE TO EN-
SURE VEHICLE THEFT RECOVERY COVERAGE.
128-7914
7 of 20
-7-
Wireless and Theft Recovery Service
Your systems operations are dependent upon the availability of a supported GSM Cellular Network.Avalid
Wireless Service Plan is required for your use of the services provided by the device, such as vehicle
tracking and vehicle command utilization. Seaguard Electronics, LLC can be reached at
1-800-705-8766.
Depending on the product and service level you purchased, “message credits” are billed to your account in
one of the following ways:
1. Credit Card
2. Electronic Check
3. Send check to Seaguard Electronics, LLC., P.O. Box 79546, Corona, California, 92877
Review more information by selecting the “Billing” page, then “Billing Method”
The wireless service application has a location for "Your account login". The default UserAccount information
is the First Initial of your first name and your complete last name. Your temporary password has six boxes that
may have been filled in by the dealer. If these boxes are left blank, the default password will be your 5 digit zip
code. Once the tracking device has been activated, you can change the password by logging into the web site
(www.pursuitrak.net) and clicking on "Account". You then type the new password in the box above the word
"Password ". Retype the new password a second time in the box above the word "Re-Enter" In order for the
change to be effective, the box at the bottom of the page "Save& Continue" must be clicked.
128-7914
8 of 20
-8-
Understanding Command Use and Message Credits
The sending of any vehicle command incurs the use of one (1) message credit. A message credit is de-
ducted from your account each time the system receives a response from your vehicle which indicates the
successful reception by the vehicle of the sent command.
Alarm commands are defined as:
• Locate vehicle
• Arm system/Lock doors/Geofence on
• Disarm system/Unlock doors/Geofence off
• Remote engine start
• Unlockonly
• StarterInterrupt
• Theft reset
In event that the vehicle fails to receive any sent command, the system does not deduct from your account.
Note: The remaining message credit balance on your account is displayed in the center navigation frame
on each of the system’s command menus under the column labeled “Credits”.
Vehicle commands are defined as:
a. Auto Report On/Off
b. SpeedAlert On/Off
c. Geo-fences On/Off
d. Low BatteryAlert On/Off
e. Trip Start, Trip End or Stationary Vehicle Mes-
sage
f. Any Alarm or other System related wireless
message sent or received.
128-7914
9 of 20
-9-
Account Login
To login to your account via the Internet, use these steps:
1. Type the URL www.Pursuitrak.net in the address line of your Internet browser.
2. Type your unique User Name (First Initial and Last Name) into the UserAccount login field.
3. Enter your unique Password into the Password field.
4. Click the MyAccount Login submit button.
5. If you have entered the correct UserAccount and Password information, you will be automatically
redirected to your vehicle home page.
Account: Account Information - Contact information, login password, time zone settings, home
phone number, are all found on this page. To make a change to any of these, after selec-
tion is made, the Save and Continue button located at the bottom of the page must be
clicked.
Billing: Accounting - displays the billing history for each selected vehicle.
Purchase Plans -
Billing Method - Credit card or Electronic check.
Vehicles: Edit Vehicle
Vehicle information - enter your vehicle description information here.
Notification information - enter your event notification information here.
Emergency numbers - enter your emergency contact numbers.
Service Plans:
Current service - displays current service plan.
Available service plans - displays list of available service plans to choose.
128-7914
10 of 20
-10-
Tracking
The following commands are available on the tracking page:
Note: Each time a wireless command is sent and acted upon by the vehicle such as LOCATE, REMOTE
ENGINE START,ARM, or DISARM, one (1) message credit will be withdrawn from yourAccount Bal-
ance.
•Locate - Clicking the icon will process a remote wireless command instruction to the installed unit. A
genericaerial viewphotowill appearstating “NowLocating(the vehicledescriptionyou supplied)Please
Standby”. The locating process may take up to 3 minutes. The image will then change to a map display
ing a car icon identifying the spot from which the vehicle has reported its position.
•Aerial View - Onceyou havelocated your vehicle,you canviewa virtualSatellite photoofthe locationof
your vehicle. (You will not be charged an additional message unit.) The map may additionally be panned
by holding down the left mouse button and “dragging” it to the desired position.
•Zoom - There are 7 map zoom levels from which to choose.
