When the protection function operates, the driver switches off stepper
motor coils, red signal ERROR flashes on, GREEN LED STEP/ENB goes
out and error optocoupler is circuited/opened.
Collector (С) and emitter (Е) of error optocoupler is displayed to
connector DB-9M type according to fig.1. SW9 switch-over(Function)
inverts circuit/opening of error optocoupler.
The driver restores its work after alarm cause removal and switching
off/on powel supply.
When there is STEP signal, STEP/ENB blinks. When ENABLE signal is
supplied, STEP/ENB goes out, when no ENABLE signal - STEP/ENB
flashes.
The driver has inbuilt STEP frequency generator – a convenient
function for a test driver start-up without access to PC or any other
external generator of STEP frequency. Generator frequency is regulated
by FREQ potentiometer.
When turned on SW10, the driver can be operated by DIR/ENABLE
signals and change stepper motor step division.
The driver allows to divide electronically physical stepper motor step -
2, 4, 8, 16 and 32.
Thus positioning accuracy is higher. Step division mode is called
microstep division. This mode allows to reduce stepper motor
resonances at low revs.
It is recommended to use PLD880 driver in step division 1:8, 1:16 or
1:32.
In these modes stepper motor rotates as smooth as possible, low-
frequency vibrations are minimal and an automatic compensator of
midfrequency stepper motor resonance works its best.
Switching of step division mode is performed via DIP-switches SW6,
SW7, SW8. Step division choice must be performed only when driver
supply is OFF.
