PureLink HOF1 Manuel utilisateur

HOF1 Owner’s Manual

Modular Fiber Optic 4K HDMI Extender

PURELINK

535 E CRECENT AVE

RAMSEY, NJ, 07446

Tel: 201.488.3232

Fax: 201.621.6118

E MAIL : sales@purelinkav.com

www.purelinkav.com

For technical support, contact:

support@purelinkav.com

Package Contents

Please make sure all of the following items are included in the package:

1) 1 x HOF1 Fiber Optic Transmitter Module

2) 1 x HOF1 Fiber Optic Receiver Module

3) 2 x IR Cables (Tx and Rx)

4) 2 x DC 5V Power Supply Unit

5) 2 x Phoenix connectors (for RS232)

6) 4 x Mounting ears

PureLink by Dtrovision

General Specification

HOF1 is a 4K HDMI extension system over pure fiber optic cable for long distance up to

3,300 ft (1,000 m).

Compact & durable design and low power consumption makes it an ideal solution for

connection for high definition video/audio signal of digital displays such as LCD/Plasma

displays and projectors.

This pure fiber optic connection enables electrical noise free and EMI free that is ideal

for long distance extension of high definition HDMI signals with embedded audio.

Model

HOF1

Input Signal

HDMI

Output Signal

HDMI

Supporting Display

Resolutions

PC: VGA ~ WUXGA

(up to 1920 x 1200 @60Hz)

HDTV: 480i ~ 1080p,

Up to Ultra HD 4K

4096 x 2160 @24/25/30Hz (RGB/YCbCr 4:4:4 8 bits,

YCbCr 4:2:2 8/10/12 bits)

4096 x 2160 @50/60Hz (YCbCr 4:2:0 8 bits)

Max. Distance

3,300 ft (1,000 m) over single mode fiber

1,000 ft (300 m) over multi mode fiber

ESD Protection

± 8kV (air-gap discharge)

Human Body Model

± 4kV (contact discharge)

Connector Type

DC Power Jack

HDMI 19 Pin Female

Single LC Receptacles

IR ports

3 pin Phoenix connectors

Conformations

HDMI version 1.4b

DVI version 1.0

HDCP 2.2

Power Rating

DC +5V , 1A

Power Consumption

Tx : 2.2W Max

Rx : 2.0W Max

Dimension (WxDxH)

3.9’’x 2.6”x 1”/ 100x65x25.6 (mm)

Weight

Transmitter: 0.4 Lbs(0.21Kg) / Receiver: 0.4 Lbs(0.21Kg)

PureLink by Dtrovision

Operation and Reliability Specification

1. Operating Environment

Temperature : 50F ~ 104F (10℃~ 40℃)

Humidity : 10% ~ 80%

Altitude : 3,000m Max.

2. Transit Environment

Temperature : -13F ~ 140F (-25℃~ 60℃)

Humidity : 5% ~ 95%

Altitude : 15,000m Max.

3. Storage Environment

Temperature : -4F ~ -49F (-20℃~ 45℃)

Humidity : 5% ~ 95%

Altitude : 3,000m Max.

4. Reliability

MTBF: 90% at over 50,000 hours aging test

In compliance with LCD Monitor reliability test standard

PureLink by Dtrovision

Main Features

1. Ultra HD/4K support with HDCP v2.2 compliance

2. UHD video, audio and control(IR & RS232) transmission over single fiber

3. Zero loss & Zero noise delivery of digital video and audio signal using optical conv

ersion technology, HOF1 delivers U/HD signals over fiber optic cables without los

s or digital interference maintaining the clarity and colors. Noise cancellation and

error correction logic enhances HDMI video and audio signals over long distance

4. Built-in signal repeater to support longer distance between the source and the H

OF1 transmitter & HOF1 receiver and the display. This Signal Repeater logic supp

orts up to 30ft copper based HDMI cables.

* distance may vary depending on the cable quality. 30ft distance is based on

PureLink branded HDMI cable

5. Full 3D compatibility (up to 1080p)

6. Compact and Robust Module Design

7. Long Distance (Up to 3,300ft (1,000m) at Ultra HD/4K or lower signal) over

single fiber optic cable

8. Real time EDID

Enhances reliability and compatibility with various displays

9. HDMI version 1.4b Support

10. Supports HD audio formats: LPCM2/5.1/7.1 CH, Dolby Digital, DTS, Dolby, TrueH

D, DTS-HD master audio and more

11. Locking power supply units

PureLink by Dtrovision

Installation and Connection Instructions

1. Turn off both the video source and the display before connecting any cables.

2. Connect HDMI cable between the source and HOF1 transmitter AND between th

e HOF1 receiver and the display.

3. Connect LC terminated fiber optic cables according to the picture below;

4. Connect the power supply unit to both HOF1 transmitter and receiver units.

5. Turn on Display

6. Turn on Video Source

PureLink by Dtrovision

HOF1 Transmitter and Receiver Specification

Transmitter Module

Connection Ports;

HDMI In: HDMI Input

DC 5V: power connector

Power: power LED indicator

RS232: 3 pins phoenix connector

Optical : Fiber status LED indicator

HDMI : HDMI status LED indicator

Optical Out: Optical output receptacle

IR Tx : IR Transmitter port

IR Rx IR Receiver port

PureLink by Dtrovision

Receiver Module

Connection Ports;

HDMI Out: HDMI Output

DC 5V: power connector

Power: power LED indicator

RS232: 3 pins phoenix connector

Optical : Fiber status LED indicator

HDMI : HDMI status LED indicator

Optical In: Optical input receptacle

IR Tx : IR Transmitter port

IR Rx IR Receiver port

IR cable pint out

PureLink by Dtrovision

Application Example

PureLink by Dtrovision

Warranty

Manufacturer’s Warranty (3-Years)

PureLink warrants this HOF1 fiber optic extender to be free from defects in workmanship and

materials, under normal use and service, for a period of three (3) year from the date of

purchase from PureLink or its authorized resellers.

If the product does not operate as warranted during the applicable warranty period, PureLink

shall, at its option and expense, execute one of the following as necessary:

1. Repair the defective product or part

2. Deliver to customer and equivalent product or part to replace the defective item

3. Refund to customer the purchase price paid for the defective product

All products that are replaced become the property of PureLink. Replacement products may

be new or reconditioned. Repaired or replacement products or parts come with a 90-day

warranty or the remainder of the warranty period. Dtrovision shall not be responsible for any

software, firmware, information, or memory data loss of contained in, stored on, or integrated

with any products returned to Dtrovision for repair under warranty.

3.1 Customer Service

Any customer service inquiries can be submitted electronically through the Q&A form on our

website ( www.purelinkav.com ).

For immediate assistance please contact us at (201) 488-3232 to reach our customer care or

tech support team.
