Protech ProX-1695 Manuel utilisateur

USER’S

MANUAL

DualSocket370Processor

EmbeddedCard

W/ VGA / Dual LAN

ProX-1695

ProX-1695 Dual Socket 370 CPU Card

With VGA/Dual LAN

OPERATION MANUAL

This operation manual is meant to assist both Embedded Computer

manufacturers and end users in installing and setting up the system. The

information contained in this document is subject to change without any

notice.

This manual is copyrighted August 15, 2001. You may not reproduce or

transmit in any form or by any means, electronic, or mechanical,

including photocopying and recording.

ACKNOWLEDGEMENTS

All trademarks and registered trademarks mentioned herein are the property

of their respective owners.

Contents

TABLE OF CONTENTS

CHAPTER 1 INTRODUCTION

1-1 About This Manual ....................................................... 1-2

1-2 System Specification ..................................................... 1-3

1-3 Safety Precautions ......................................................... 1-6

CHAPTER 2 HARDWARE CONFIGURATION

2-1 Jumper & Connector Quick Reference Table ................ 2-2

2-2 Component Locations ................................................... 2-3

2-3 How to Set the Jumpers ................................................. 2-4

2-4 COM Port Connector ...........…..................................... 2-6

2-5 RS232/422/485 (COM2) Selection ............................... 2-7

2-6 Solid-State Disk Socket ..................................………... 2-8

2-7 SSD Memory Mapping Selection .................................. 2-9

2-8 Keyboard or PS/2 Mouse Connector .....................….... 2-10

2-9 Keyboard or PS/2 Mouse Selection .......................….... 2-10

2-10 External Keyboard Connector ....................................... 2-11

2-11 Reset Connector ............................................................ 2-11

2-12 Hard Disk Drive LED Connector .................................. 2-11

2-13 CPU Fan Connector ...................................................... 2-12

2-14 External Speaker Connector .......................................... 2-12

2-15 VGA CRT Connector .................................................... 2-13

2-16 Hard Disk Drive Connector ........................................... 2-14

2-17 Floppy Disk Drive Connector ....................................... 2-16

2-18 DFP Connector ……….................................................. 2-17

2-19 LVDS Connector ……………………………………... 2-18

2-20 Printer Connector .......................................................... 2-19

2-21 Power LED & Keylock Connector ................................ 2-19

2-22 Green Function Connector ............................................ 2-20

2-23 Universal Serial Bus Connector .................................... 2-20

2-24 IRDA Connector ……………………………………… 2-21

2-25 Reset/NMI/Clear Watchdog …..……………………… 2-21

2-26 LAN Connector ............................................................. 2-22

2-27 Memory Installation ...................................................... 2-24

2-28 PPCI Connector ………………………………………. 2-25

Contents

2-29 CPU Type Selection ………………………………… 2-26

CHAPTER 3 SOFTWARE UTILITIES

3-1 Introduction …………................................................... 3-2

3-2 VGA Driver Utility …………………………………… 3-2

3-3 Flash BIOS Update ....................................................... 3-3

3-4 LAN Driver Utility …................................................... 3-5

3-5 Watchdog Timer Configuration .................................... 3-6

CHAPTER 4 GREEN PC FUNCTION

4-1 Power Saving Block Diagram ....................................... 4-2

4-2 CPU Doze Mode ........................................................... 4-2

4-3 System Standby Mode ................................................... 4-2

4-4 System Suspend Mode .................................................. 4-3

CHAPTER 5 AWARD BIOS SETUP

5-1 Introduction ................................................................... 5-2

5-2 Entering Setup ............................................................... 5-3

5-3 The Standard CMOS Setup ………............................... 5-4

5-4 The BIOS Features Setup .............................................. 5-8

5-5 Chipset Features Setup .................................................. 5-12

5-6 Power Management Setup ............................................. 5-16

5-7 PNP/PCI Configuration ................................................. 5-19

5-8 Load BIOS Defaults ...................................................... 5-21

5-9 Load Setup Defaults ...................................................... 5-21

5-10 Integrated Peripherals .................................................... 5-22

5-11 Password Setting ........................................................... 5-24

5-12 IDE HDD Auto Detection ............................................. 5-26

5-13 Save & Exit Setup ......................................................... 5-27

APPENDIX A EXPANSION BUS

ISA Bus Pin Assignment .......................................................... A-2

PCI Bus Pin Assignment .......................................................... A-3

Contents

APPENDIX B TECHNICAL SUMMARY

Block Diagram .......................................................................... B-2

Interrupt Map ............................................................................ B-3

RTC & CMOS RAM Map ........................................................ B-4

Timer & DMA Channels Map .................................................. B-5

I/O & Memory Map ................................................................. B-6

APPENDIX C TROUBLE SHOOTING

Trouble Shooting for Error Messages ...................................... C-2

Trouble Shooting for POST Codes ........................................... C-4

Page:1-1

INTRODUCTION

This chapter gives you the information for Prox-1695. It also

outlines the System specification.

Section includes:

zAbout This Manual

zSystem Specifications

zSafety precautions

Experienced users can skip to chapter 2 on page 2-1

for Quick Start.

CHAPTER

Chapter 1 Introduction

Page: 1-2 Prox-1695 USER

′

S MANUAL

1-1. ABOUT THIS MANUAL

Thank you for purchasing our Prox-1695 Socket 370 Embedded Card with

VGA / LAN, which is fully PC / AT compatible. Prox-1695 provides faster

processing speed, greater expandability and can handle more task than before.

This manual is designed to assist you how to install and set up the system. It

contains five chapters. The user can apply this manual for configuration

according to the following chapters :

Chapter 1 Introduction

This chapter introduces you to the background of this manual, and the

specification for this system. Final part of this chapter will indicate you how to

avoid damaging this Embedded Card.

Chapter 2 Hardware Configuration

This chapter outlines the component locations and their functions. In the end

of this chapter, you will learn how to set jumper and how to configure this card

to meet your own needs.

Chapter 3 Software Utilities

This chapter contains helpful information for proper installations of the VGA

utility, LAN utility and Flash BIOS. It also describes the Watchdog timer

configuration.

Chapter 4 Green PC Function

This chapter explains the Green PC functions concisely.

Chapter 5 Award BIOS Setup

This chapter indicates you how to set up the BIOS configurations.

Appendix A Expansion Bus

This Appendix introduces you the expansion bus for ISA Bus, and PCI Bus.

Appendix B Technical Summary

This section gives you the information about the Technical maps.

Appendix C Trouble Shooting

This section outlines the error messages and offers you the methods to solve

the problems.

Chapter 1 Introduction

Prox-1695 USER

′

S MANUAL Page: 1-3

1-2. SYSTEM SPECIFICATION

zCPU :

Intel® Celeron™ processors in 370-pin socket.

300A/333/366/400/433/466/500/533/566/600/667/700/733 MHz.

Dual Intel® Pentium® III processors in 370-pin socket.

500E/550E/600E/650/700/750/800/850 MHz.

Auto detect voltage regulator.

zMEMORY :

Up to 768MB SDRAM

Three 168-pin DIMMs socket on board.

zCACHE :

Depended on CPU (128/256KB Cache).

zREAL-TIME CLOCK / CALENDAR :

CMOS data back up from BIOS set or BIOS default.

Dallas DS 12887 Real Time Clock.

zBIOS :

Award Flash BIOS for plug & play function.

Easy update 256KB flash EEPROM.

Support Green Function.

Support S/IO Setup.

zKEYBOARD/MOUSE CONNECTOR :

Mini DIN connector for Keyboard or PS/2 Mouse by jumper selection.

One 5-pin External keyboard connector.

zUNIVERSAL SERIAL BUS :

Universal Serial Bus Connector on board, supports up to 2 USB ports.

zBUS SUPPORT :

External ISA/PCI BUS; PICMG Spec.

Internal PCI Bus for IDE, PPCI, & LAN.

Internal AGP Bus for VGA.

Chapter 1 Introduction

Page: 1-4 Prox-1695 USER

′

S MANUAL

zDISPLAY :

Support SVGA for CRT, LVDS, & Panel Link.

Support 32bits PCI Local Bus.

VGA BIOS combines in 256KB flash ROM together with system BIOS.

Support 15-pin connector 1600 x 1200 (64K color) resolutions on Monitor.

Integrated 8MB of SGRAM for graphic/video frame memory.

Panel Display can support PanelLink and LVDS.

Support simultaneous display of CRT & LCD panel.

zWATCHDOG :

I / O port 0443H to Enable watchdog.

I / O port 0441H to Disable watchdog.

Time-out timing select 0 / 8 / 16 / 24 / 32 / 40 / 48 / 56 / 64 / 72 / 80 / 88 / 96 /

104 / 112 / 120 sec +/- 25%.

zIDE INTERFACE :

Two IDE ports, Support up to four Enhanced IDE devices.

zFLOPPY DISK DRIVER INTERFACE :

Support up to two Floppy Disk Drives, 3.5" and 5.25" (360K / 720K / 1.2M /

1.44M / 2.88M / LS-120).

zDISK-ON-CHIPS SOCKET :

Supports up to 144MB.

zLAN INTERFACE :

Intel 82559 Fast Ethernet.

Dual LAN, support for 10BaseT/100 BaseTx PCI Bus.

Two RJ-45 Jack on board.

zSERIAL PORT :

Two high speed 16550 Compatible UARTs with Send / Receive 16 Byte

FIFOs. COM1 for RS232; COM2 for RS232/422/485.

MIDI Compatible.

Programmable Baud Rate Generator.

Chapter 1 Introduction

Prox-1695 USER

′

S MANUAL Page: 1-5

zPARALLEL PORT :

SPP, ECP, EPP Function.

Bi-directional parallel port.

zGREEN FUNCTION :

Software supported by BIOS setup.

Hardware supported by switch control.

zHARDWARE MONITORING FUNCTION :

Monitor Voltage, CPU Temperature and Cooling Fan.

zLED INDICATOR :

System power.

Hard Disk access.

LAN LED indicator.

zBUS SPEED :

ISA Bus 8MHz

PCI Bus 33MHz

PPCI Bus 33MHz

USB 12Mbit/sec

zDMA CONTROLLER :

82C37 x 2

zDMA CHANNELS :

zINTERRUPT CONTROLLERS :

82C59 x 2

zINTERRUPT LEVELS :

zOPERATING TEMPERATURE :

0 to 60°C.

Table des matières

Autres manuels protech Matériel informatique

protech

protech BE-0986 Manuel utilisateur

protech

protech SE-8300 Manuel utilisateur

protech

protech BE-0961 Manuel utilisateur

protech

protech SA-5082 Manuel utilisateur

protech

protech Prox SE-8124 Manuel utilisateur

protech

protech BM-0982 Manuel utilisateur

protech

protech BM-0972 Manuel utilisateur

protech

protech Celeron EB-471LF M1 Manuel utilisateur

protech

protech ProX-1688 Manuel utilisateur

protech

protech PC-550 Manuel utilisateur

protech

protech ProX-1710 Manuel utilisateur

protech

protech ProX-1635LF Manuel utilisateur

protech

protech BE-0996 Manuel utilisateur

protech

protech PC-560-G5 Manuel utilisateur

protech

protech ProX-1260 Manuel utilisateur

protech

protech ProX-1520 M1 Manuel utilisateur

protech

protech Prox SG-S152 Manuel utilisateur

protech

protech ProX-1580 Manuel utilisateur

protech

protech PC-420 Manuel utilisateur

protech

protech ProX-1550 Manuel utilisateur

protech

protech ProX-1680 Manuel utilisateur

protech

protech ProX-1215 Manuel utilisateur

protech

protech prox BE-U236 Manuel utilisateur

protech

protech PCI-531LF Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur

protech ProX-1695 Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques
