Protech Systems PPC-7915F Manuel utilisateur

Manual ver Q1

Jumper Setting

Specification

PPC-7915F/ PPC-7917F/ PPC-7919F

PPC-7915F

Quick

Reference

Guide

Compliant

PPC-7917F

PPC-7919F

PPC-7915F/ PPC-7917F/ PPC-7919F

System

CPU Type Intel® ATOM N270 (1.6GHz)

Chipset Intel® 945GSE + ICH7M (FSB: 533MHz)

Memory Support 1 x 200pin DDRII SO-DIMM, Support DDR II 533 SDRAM up to 2GB

Front Bezel Stainless Steel

IP65/NEMA4 Yes

Power Supply DC 24Vin 100W power supply (optional power adaptor)

Dimension (WxHxD) PPC-7915F: 403 x 303 x 84 mm (15.87” x 11.93” x 3.31”)

PPC-7917F: 452 x 366 x 89 mm (17.8” x 14.4” x 3.5”)

PPC-7919F: 497 x 420 x 91.5 mm (19.65” x 16.5” x 3.6”)

System Weight PPC-7915F: 6.6 kg PPC-7917F: 8.8 kg PPC-7919F: 10.8 kg

VESA Mounting Support 75 /100 mm VESA braket (optional)

Certificate CE/FCC

I/O Ports

USB 4 x USB2.0

KB/Mouse 2 x PS/2 port

Audio Line-in/ Line-out/ Mic-in

Parallel Port 1 x parallel port (SPP/EPP/ECP)

Serial Port 4 x COM port (All COM ports support +5V or +12V),

COM2 for RS232/422/485 selectable

Digital I/O 8 in/ 8 out (share with Parallel port)

LAN 2 x LAN (10/100/1000 Mbps)

VGA 1 x VGA

Drive Bay 1 x 2.5" SATA HDD, 1 x IDE CF slot on board, 1 x slim SATA CD-ROM

Display

LCD PPC-7915F: 15” LCD Panel XGA 1024 x 768

PPC-7917F: 17” LCD Panel SXGA 1280 x 1024

PPC-7919F: 19” LCD Panel SXGA 1280 x 1024

Touch Screen 5W Analog resistive (USB interface)

Environment

Temperature Operation Temperature 0~40 °C(32~104 °F),

Storage Temperature -20~60 °C(-4~140 °F)

Humidity Operation Humidity 20~90%

(M/B for PROX-B585LF-G1A)

BZ1

JP5

JP3

JPANEL1

CPU_FAN1

199

200

DIM1

44 42

35 32

25 22

512

AUDIO1

JRJ45USB1

210

1112 1314

JRJ45USB2

210

1112 1314

COM2 VGA1

JPRNT1

6956

10 11

KB_MS1

1234

JP_COM1

JP7

JP_COM2

JP15

JP8

DIO_C1

JP9

COM1

COM3

COM4

JP10

910

JP11

JP14

IRDA1

SATA2

SATA1

JUSB1

JUSB2

JP6

JP13

JP4

JP12

JATX_PWR1

510

Battery

SPI_DJP1

FAN1

JP_LV2

JP_LV1

INV1

INV2

LVDS1

30 2

LVDS2

30 2

Intel

Atom N270

Intel

945GSE

Intel

ICH7M

PCI1

3.3V

LVDS1 Voltage

Selection

3.3V

LVDS2 Voltage

Selection

ATX

AT/ ATX Power Selection

Master

Slave

CF Master/Slave

Selection

Speaker

Power

LED

HD LED

Reset

Button

Power

Button

12V

COM4 Voltage

Selection

12V

COM3 Voltage

Selection

Auto

Software

Control

For 485 DIR

Control Selection

12V

COM2 Voltage

Selection

12V

COM1 Voltage

Selection

Reset

NMI

Reset/NMI Watchdog

Selection

Normal

Clear

CMOS

Clear CMOS Data

Selection

JP12

JP13

JP6 JP6

JP12

JP13

(default)

(default) (default)

(default)

(default) (default)

(default)

RS232

910

RS422

910

RS485

910

RS232/422/485 (COM2)

Selection

(default)

3.3V

IR Voltage

Selection

(default)

COM2

COM2 / IR

Selection

(default)

JP3

(M/B for PROX-B585LF-G1A)

SystemView

System View Wall Mount

Wall Mount

Fanless and Low Power 15”/ 17”/ 19” ATOM Platform Panel PC

PPC-7915F/PPC-7917F/PPC-7919F

Safety & Notification

Unit: mm

PPC-7915F Cut-Out Dimension:

375.4 x 270

The following messages are reminders for safety on how to protech your systems from damages and to extend a long life of the system.

1. Check the Cable Voltage

* Make sure the range of operating voltage that is between AC 100V and AC 240V. Otherwise, the system could be damaged.

2. Environmental Conditions

* Place your PPC-7915F/PPC-7917F/PPC-7919F on a sturdy, level surface. Be sure to allow enough space to have easy access around the system.

* Avoid extremely hot or cold place to install the system.

* Avoid exposure to sunlight for a long period of time or in a airtight space. Also, avoid the system from any heating device or use PPC-7915F/PPC-7917F/PPC-7919F

when it's been left outdoors in a cold winter day.

* Bear in mind that the operating ambient temperature is from 0 C up to +40 C .

* Avoid moving the system rapidly from a hot place to a cold place and vice versa. Because condensation may come from inside of the system.

* Place PPC-7915F/PPC-7917F/PPC-7919F in strong vibrations may cause hard disk failure.

* Do not place the system too close to any radio active device. Radio-active device may cause signal intereference.

3. Handling

* Avoid putting heavy objects on top of the system.

* Do not turn the system upside down. This may cause the floppy drive and hard drive to mal-function.

* Do not remove the diskette from the floppy drive while the light is still on. The floppy drive can be damaged if you do so.

* If wate or other liquid spills into this product, unplug the power cord immediately.

4. Good Care

* When the outside of the case is stained, remove the stain with neutral washing agent with a dry cloth.

* Never use strong agents such as benzene and thinner to clean the system.

* If heavy stains are present, moisten a cloth with diluted neutral washing agent or with alcohol and then wipe thoroughly with a dry cloth.

65 65

192.75 192.75

49.25 49.25

142.75 142.75

375.4

270

12- 4.5

Wall

Unit: mm

PPC-7917F Cut-Out Dimension:

413 x 317

300

100

442

367

100100

454

377

Wall

Unit: mm

PPC-7919F Cut-Out Dimension:

442 x 367

IP65 Certificate for SGS

323.2

413

419.2

317

280

9090

Wall

PPC-7915F:307.1/ PPC-7917F: 338/ PPC-7919F: 376.4

PPC-7915F:231.1/

PPC-7917F: 270.4/

PPC-7919F: 301.15

PPC-7915F:303.0/ PPC-7917F: 366/ PPC-7919F: 420

PPC-7915F:402.8/ PPC-7917F: 452/ PPC-7919F: 497

Wall

(M/B for PROX-B585LF-G1A)
