ProofCam PC 106 Manuel utilisateur
FoV
PC 106 HD
Dash Cam
Designed and tested by experts
INSTRUCTION MANUAL
滚滚长江东逝水
3.0
120
Congratulations on
choosing the PC 106
Forward Facing HD
Dash Cam.
Please read these
instructions carefully
before use.
Contents
Product Features P01
Unpacking P01
Identification of Controls P02
Preparing for Use P03
Installing the Dash Cam P04
Connecting to Power P04
Powering the Dash Cam On / Off P05
Set the Date / Time P06
Mode Selection P06
Using the Dash Cam P06
Recording Screen P07
Emergency File Protection P07
Motion Detection P09
G-sensor Collision
Recording Protection P09
Audio On /Off P09
Menu Options P10
Menu Settings Mode P11
Taking Picture P13
Still Capture P13
P14
Playback Menu Options P15
Battery Warning and
Installation Notes
P16
Caution P17
Warranty P17
Specification P18
Playing Back Videos and Photos
Product Features
›HD Dash Cam
›1 Megapixel CMOS Sensor
›3.0” TFT Display
›120˚ Wide Angle Lens
›Support up to 32GB Class10 Micro SD Memory Card
›G-sensor Collision Recording Protection
›Motion Detection
›Seamless Loop Recording
Unpacking
Unpack the contents of the box and ensure the following components
are present.
›PC 106 Dash Cam
›Micro SD Card
›In Car Charger
›Suction Pad
›Quick Start Guide
›Windows Sticker
01
PC 106 HD Dash Cam
Identification of Controls
Controls:
1.
USB Port for power adaptor
2.
Lens
3.
LCD
4.
SD card slot
5.
Up button
6. Menu button
7.
OK button8.
Mode button9.
Lock button10.
Power button11.
Microphone
12.
Reset button
www.proofcam.com
02
1
2
3
12 13
4
5
6
7
8
9
10
11
Down button
13.
Preparing for Use
Battery Indicator and Charging
Inserting the SD Card (included)
Follow the direction indicated on the dash cam to insert the Micro SD card,
a click sound is heard indicating the Micro SD card is in position.
To remove the Micro SD card, push to eject the Micro SD card out of the slot.
NOTE:
1. Do not remove or insert the Micro SD card when the dash cam is turned on.
This may damage the Micro SD card.
2. Please use a minimum Class 10 or higher rating Micro SD card, maximum
up to 32GB.
3. Please format the micro SD card before the initial use.
4. When removing the Micro SD card, be careful that the card may spring out
and get lost. The Micro SD card slot has this spring-out feature for easy
removal of the card.
Micro SD Card slot
03
PC 106 HD Dash Cam
5. Dash Cam pre-installed a 8GB Class 10 Micro SD card, which has six months
warranty. The warranty date is deemed to be from the date you received your
dash cam.
6. Please format the micro SD card at least once a month to make sure it is
operating and recording properly.
Installing the Dash Cam
1.
Push the suction pad into the slot on the top of the dash cam, make sure the
suction pad is securely locked in place.
2.
Remove the protective film from the suction cup, with the suction-cup laying
flat, position the suction-cap on the windshield, and then press down the
clamp to suction pad the holder to the windshield. Make sure the base is
securely locked in place.
3.
Loosen the knob to swivel the dash cam vertically. Lock the knob, to confirm
that the dash cam is securely locked in place.
4.
Rotate the dash cam 360° to have proper view if required.
Connecting to Power
Use only the supplied in car charger for activating the dash cam and charging
the built-in battery.
1.
Connect one end of car charger to USB port on the dash cam.
2.
Plug the other end of the car charger to the in car power socket of your
vehicle. Once the vehicle engine is started, the dash cam automatically
turns on.
www.proofcam.com
04
Note:
1.
2.
Some vehicles have an in car power supply that remains on, even if the
engine is turned off. If this is the case, you will need to manually turn the
dash cam on and off, using the power button, when you enter and leave
the vehicle.
Any excess cable can normally be tucked into the ceiling of the vehicle.
We have a video to advise on how best to fit the PC 106 which is available
at www.proofcam.com and visit “ Dash Cam Resources”. You can also
search “How to fit an PC 106” on YouTube.
Powering the Dash Cam On / Off
Auto Power On / Off
Once the vehicle engine is started, the dash cam automatically turns on and
starts recording (must have SD Card installed). After the car engine is stopped,
the dash cam will automatically save the last recorded file and shut down.
Note:
Manual Power On / Off
3 seconds to power the dash cam on and off.
Reset the Dash cam
In case the dash cam fails to function normally due to unknown causes, press
the Reset button with sharp pin, then wait for restarting the dash cam. Sometimes
it is also necessary to format the Micro SD Card, which can be performed from
the menu settings.
05
PC 106 HD Dash Cam
Manual Power On / Off and Reset
If your vehicle in car power remains on after the car engine has been turned
off, you may need to remove the car charger, or turn the PC 106 off using
the power button. This is because if the in car power remains on, the
PC 106 will not know that the engine has turned off.
Long press the Power button
Power button
Reset button
Set the Date / Time
To set the correct date and time, press MENU button
to enter the menu setting,
then press and buttons to select Date/Time setting, press OK button to
set it, then press and buttons to adjust the value, press OK button to
switch to next setting, after finished all the settings, press OK button to return
to menu setting, press MENU button to exit menu setting. To start recording
press OK button once.
Mode Selection
The default setting is Video Mode, press MODE button to switch to Still Capture
Mode, then press MODE button to switch to Playback Mode.
Using the Dash Cam
Recording Videos
Before starting to record, please ensure that the Micro SD card (included) is
inserted. If you are using the dash cam for the first time, please format the
Micro SD card at first in the dash cam. Please press OK button to start
recording, the video recording time in red font changes on the screen.
The recorded files are saved to the Micro SD card. To stop recording, press
OK button again. With the car charger connected the dash cam will automatically
turn on and start recording when the car engine starts. When the engine stops,
the dash cam will automatically save the last file and turn off.
www.proofcam.com
06
Note -if your vehicle in car power remains on after the car engine has been
turned off, you may need to remove the power lead, or turn the PC 106
off using the power button. This is because if the in car power remains
on, the PC 106 will not know that the engine has been turned off.
Emergency File Protection
Important:
The PC 106 records in segments onto the Micro SD card. The default segment
duration is 3 minutes, which can be changed from the menu settings. For
example, 1 hour of recording would generate 20 x 3 minute segments.
During recording, press KEY button
to protect current video, thelock icon
appears on the screen, if you press the KEY button before the last 5 seconds
of this video’s segment, the current video will be protected; if you pressKEY button
during the last 5 seconds of this video’s segment, both the current and the next
video segments will be protected and cannot be replaced. For example, if set 3
minutes as segment, press button before 2 minutes and 55 seconds of this
video, the current video will be protected; press button during 2 minutes 55
seconds to 3 minutes, the current and the next video will be protected.
Remove the protection for the video:
Recording Screen
07
PC 106 HD Dash Cam
The protective video can be seen the lock icon in dash cam playback mode,
and the file name will be changed to “SOS-XXXXX” in dash cam and computer.
Press OK button to stop recording, then press MODE button twice switch to
Playback Mode, choose the protection video and then press MENU button to
enter Playback menu, press UP and DOWN buttons to select “Unlock One” or
“Unlock All”, press OK button to confirm unlock current video or all the protected
videos, the lock icon will disappear from the screen and the file name will be
changed to “REC-XXXXX”, the video will not be protected and can be replaced
if the Micro SD card is full.
KEY
KEY
