ProMinent DULCOMETER DMT Series Manuel utilisateur

ProMinent®

Part no. 987426 ProMinent Dosiertechnik GmbH ·69123 Heidelberg ·Germany BA DM 163 03/08 GB

Please read the operating instructions through completely before

commissioning this equipment! Do not discard!

The operator shall be liable for any damage caused by installation or operating errors!

Operating Instructions

DULCOMETER®DMT

On-site measurement transducer

Measured variables pH/redox/temperature

Please enter the identity code of the device here.

DMTa ___ ___ ___ ___ ___ ___ ___ ___ ___ ___ ___ ___

BA_DM_163_03_08_GB.p65 26.03.2008, 10:20 Uhr1

ProMinent®

Page 2

Publishing details:

Operating Instructions

DULCOMETER®DMT on-site measurement transducer

Measured variables pH/redox/temperature

Address:

ProMinent Dosiertechnik GmbH

Im Schuhmachergewann 5-11

69123 Heidelberg

Germany

Telephone: +49 6221 842-0

Fax: +49 6221 842-419

[email protected]

www.prominent.com

Subject to technical alterations.

Publishing details

BA_DM_163_03_08_GB.p65 26.03.2008, 10:20 Uhr2

ProMinent®Page 3

Table of contents

Device identification/identity code: measured variable pH .......................... 5

Device identification/identity code: measured variable redox ..................... 6

Device identification/identity code: measured variable temperature .......... 7

1General instructions for use ............................................................ 8

2Safety .................................................................................................. 9

2.1 Correct use ............................................................................ 9

2.2 Safety guidelines ................................................................... 9

3Storage and transport ...................................................................... 9

4Assembly and installation ................................................................ 10

4.1 Assembly (mechanical) ......................................................... 10

4.1.1 Wall mounting ........................................................................ 10

4.1.2 Pipe mounting ........................................................................ 11

4.1.3 Panel mounting ...................................................................... 12

4.2 Installation (electrical) ........................................................... 13

4.2.1 Wall mounting ........................................................................ 14

4.2.2 Pipe mounting ........................................................................ 15

4.2.3 Panel mounting ...................................................................... 15

4.2.4 Connecting coaxial cable ...................................................... 16

4.2.5 Connecting terminals ............................................................. 16

5Device overview and control elements .......................................... 17

6Function description ......................................................................... 18

6.1 General .................................................................................. 18

6.2 Key functions ......................................................................... 19

6.3 Operating menu, schematic .................................................. 19

6.4 Negotiating operating menu ................................................. 20

6.4.1 Calibration menu (pH only) .................................................... 21

6.4.2 Info display ............................................................................ 21

6.4.3 Menu options ......................................................................... 21

6.4.4 Negotiating the menu options ............................................... 21

7DMT settings ...................................................................................... 22

7.1 Measured variables pH and redox ........................................ 23

BA_DM_163_03_08_GB.p65 26.03.2008, 10:20 Uhr3

ProMinent®

Page 4

Table of contents

7.1.1 Menu overview: measured variable pH ................................ 23

7.1.2 Menu overview: measured variable redox ............................ 24

7.1.3 Parameter settings (pH only) ................................................ 25

7.1.4 Checking the ORP probe (redox only) .................................. 25

7.1.5 Parameters: Temperature ...................................................... 26

7.1.6 Parameter output .................................................................. 28

7.1.7 General settings .................................................................... 31

7.2 Measured variable temperature ............................................ 33

7.2.1 Menu overview measured variable, temperature ................. 33

7.2.2 Parameters temperature ....................................................... 34

7.2.3 Parameter output .................................................................. 34

7.2.4 General settings .................................................................... 36

8Operating the DMT ............................................................................ 38

8.1 Permanent display ................................................................ 38

8.1.1 Probe condition information (pH only) ................................... 38

8.1.2 Brightness of LC display ........................................................ 39

8.2 Calibrating the pH meter ....................................................... 39

8.2.1 Automatic buffer detection .................................................... 39

8.2.2 The calibration process ......................................................... 40

9Troubleshooting ................................................................................. 44

9.1 Error messages during operation ......................................... 44

9.2 Error messages while calibrating the pH meter ................... 45

10 Maintenance and repair .................................................................... 46

11 Disposal .............................................................................................. 46

12 Technical data .................................................................................... 47

13 Spare parts and accessories ........................................................... 48

Appendix ............................................................................................. 49

Conformity declarationdeclaration ...................................................... 49

Terminal connection plan pH/redox/temperature ................................ 50

Wiring example - two wire system ....................................................... 51

PROFIBUS®circuit board terminal connection ................................... 52

Index .................................................................................................... 53

BA_DM_163_03_08_GB.p65 26.03.2008, 10:20 Uhr4

ProMinent®Page 5

Device identification/identity code: measured variable pH

Please enter the identity code for your device here.

DMTa 0 P 1 0 0

DMTa DULCOMETER®DMT series measurement transducer

Mounting type

Wwall/pipe mounted

Scontrol panel mounted (not PROFIBUS®-DMT)

Version

0with ProMinent logo

Electrical connection

94-20 mA (two wire) current loop, 24 V DC (16...40 V DC)

5PROFIBUS®-DP, 24 V DC (16...30 V DC)

Communication interface

0none

4PROFIBUS®-DP

Measured variable

PpH

Rredox (ORP)

Ttemperature

Correction variable

1temperature (PT 1000/PT 100)

Enclosure rating

0standard

Adjustable general settings:

Language

DGerman

EEnglish

FFrench

PPolish

SSpanish

IItalian

Automatic buffer detection

0ProMinent buffer set

DDIN 19226 buffer set

Vautomatic buffer adjustment

Temperature measurement

0automatic

(PT 1000 or PT 100)

1manual

2automatic or manual

9none

Output

0measured variable

(fault: 23 mA, calibration: 23 mA)

1manually adjustable

current value

2measured variable or manual

(fault: 23 mA, calibration: 23 mA)

3measured variable or manual

(fault: 23 mA, calibration: HOLD)

44mA constant current

Other settings

0standard

BA_DM_163_03_08_GB.p65 26.03.2008, 10:20 Uhr5

ProMinent®

Page 6

Device identification/identity code: measured variable redox

Please enter the identity code for your device here.

DMTa 0 R 1 0 0 0

DMTa DULCOMETER®DMT series measurement transducer

Mounting type

Wwall/pipe mounted

Scontrol panel mounted (not PROFIBUS®-DMT)

Version

0with ProMinent logo

Electrical connection

94-20 mA (two wire) current loop, 24 V DC (16...40 V DC)

5PROFIBUS®-DP, 24 V DC (16...30 V DC)

Communication interface

0none

4PROFIBUS®-DP

Measured variable

Rredox

PpH

Ttemperature

Correction variable

1temperature (PT 1000/PT 100) - measurement only

Enclosure rating

0standard

Adjustable general settings:

Language

DGerman

EEnglish

FFrench

PPolish

SSpanish

IItalian

Probe type

0standard

Temperature measurement

0automatic

(PT 1000 or PT 100)

9none

Output

0measured variable

(fault: 23 mA, calibration: 23 mA)

1manually adjustable

current value

2measured variable or manual

(fault: 23 mA, calibration: 23 mA)

3measured variable or manual

(fault: 23 mA, calibration: HOLD)

44mA constant current

Other settings

0standard

BA_DM_163_03_08_GB.p65 26.03.2008, 10:20 Uhr6

ProMinent®Page 7

Please enter the identity code for your device here.

DMTa 0 T 0 0 0 0 0

DMTa DULCOMETER®DMT series measurement transducer

Mounting type

Wwall/pipe mounted

Scontrol panel mounted (not PROFIBUS®-DMT)

Version

0with ProMinent logo

Electrical connection

94-20 mA (two wire) current loop, 24 V DC (16...40 V DC)

5PROFIBUS®-DP, 24 V DC (16...30 V DC)

Communication interface

0none

4PROFIBUS®-DP

Measured variable

PpH

Rredox (ORP)

Ttemperature

Correction variable

0none

Enclosure rating

0standard

Adjustable general settings:

Language

DGerman

EEnglish

FFrench

PPolish

SSpanish

IItalian

Probe type

0PT 100 or PT 1000

Temperature detection

0Probe (PT 1000 or PT 100)

Output current

0Output: measured variable

(fault: 23 mA, calibration: 23 mA)

1Output adjustable

2measured variable or adjustable

(fault: 23 mA, calibration: 23 mA)

3measured variable + manual + HOLD

(fault: 23 mA, calibration: HOLD)

4Output current = 4 mA

Other settings

0standard

Device identification/identity code: measured variable temperature

BA_DM_163_03_08_GB.p65 26.03.2008, 10:20 Uhr7

ProMinent®

Page 8

1General instructions for use

Please read through these instructions for use carefully. They will enable you

to make the best possible use of this operating instructions manual.

The following sections are highlighted in the text:

•Enumerated points

왘Instructions

Working instructions

NOTE

Guidelines are intended to make your work easier.

and safety instructions:

CAUTION

Describes a potentially dangerous situation.

Non-observance can lead to personal injury or damage

to property.

IMPORTANT

Describes a potentially dangerous situation.

Non-observance can lead to damage to property.

General instructions for use

BA_DM_163_03_08_GB.p65 26.03.2008, 10:20 Uhr8

ProMinent®Page 9

2Safety

2.1 Correct use

The DMT on-site measurement transducer is designed exclusively for the

•measurement of pH value resp. redox potential

•measurement of temperature

•display of measured variables

•production of an output signal

It is prohibited to use the device for any other applications or to modify it

in any way!

The device must not be used outdoors without added protection (housing,

weatherproof cover).

2.2 Safety guidelines

CAUTION

•The device must not be used in a possible explosion

area.

•The DMT must be operated by trained and authorised

personnel.

IMPORTANT

•The system must be suitably equipped and configured to

prevent overdosing of hazardous materials due to probe

failure.

•The DMT has no on/off switch. It starts to function as soon

as it is connected to a power supply.

3Storage and transport

Store and transport the DMT in the original packaging.

IMPORTANT

•Protect the DMT from damp and the effects of chemicals

even when packed.

Ambient conditions for storage and transport:

Temperature: -20 °C to 70 °C

Humidity: max. 95 % relative humidity,

non condensing

Safety / Storage and transport

BA_DM_163_03_08_GB.p65 26.03.2008, 10:20 Uhr9

ProMinent®

Page 10

4Assembly and installation

IMPORTANT

•The DMT is fully resistant to normal environments control

rooms.

•The DMT must not be placed where it can come into

contact with rain or direct sunlight!

Use a protective housing or weatherproof cover if in use

out of doors.

4.1 Assembly (mechanical)

The DMT can be wall, pipe or panel mounted (not for PROFIBUS®-DMT).

4.1.1 Wall mounting

Mounting materials (included in delivery):

1 x wall/pipe bracket

2 x 5x45 mm round headed screws

2 x 5.3 washers

2 x wall plugs Ø 8 mm, plastic

1 x rubber insert

1 x locking screw (PT)

Wall mounting, please follow the steps below:

왘Remove wall/pipe bracket from DMT:

pull the two snap fasteners outwards and push upwards (fig. 1, ➀).

Swing the wall/pipe bracket away from the DMT and pull downwards

(fig. 1, ➁).

왘Mark two drill holes diagonally opposite one another using the mounting

bracket as a template.

왘Drill the holes: Ø 8 mm, depth = 50 mm.

왘Screw the wall/pipe bracket in place inserting the washers (fig. 2).

왘If the DMT is also to be secured with a screw, pierce the screw hole in the

back of the housing (housing must be open) and attach a rubber insert

(fig. 2, ➀) to the bracket.

왘Hang the DMT onto the top of the bracket (fig. 3, ➀) and push down

gently against the bracket (fig. 3, ➁), then push upwards until you hear

aclick (fig. 3, ➂).

왘Tighten the locking screw to secure more firmly (housing is open).

Assembly and installation

BA_DM_163_03_08_GB.p65 26.03.2008, 10:20 Uhr10

Autres manuels pour DULCOMETER DMT Series

Table des matières

Autres manuels ProMinent Instrument de mesure

ProMinent

ProMinent DULCOMETER D1C Manuel utilisateur

ProMinent

ProMinent DULCOMETER D1C Manuel utilisateur

ProMinent

ProMinent DulcoFlow DFMa Manuel utilisateur

ProMinent

ProMinent LF 1 FE Manuel utilisateur

ProMinent

ProMinent DulcoFlow DFMa series Manuel utilisateur

ProMinent

ProMinent DULCOMETER D1C Manuel utilisateur

ProMinent

ProMinent DULCOTEST CDP 1 Manuel utilisateur

ProMinent

ProMinent DULCOTEST DT1B Manuel utilisateur

ProMinent

ProMinent DULCOTEST CGE 2-mA-10 ppm Manuel utilisateur

ProMinent

ProMinent Flow Control 3 Manuel utilisateur

ProMinent

ProMinent Portamess 911 pH Manuel utilisateur

ProMinent

ProMinent DULCOTEST DT4B Manuel utilisateur

ProMinent

ProMinent TUC 5 Manuel utilisateur

ProMinent

ProMinent DULCODOS Hydrazin Manuel utilisateur

ProMinent

ProMinent DULCODOS Pool Comfort Manuel utilisateur

ProMinent

ProMinent Portamess 911 Conductivity Manuel utilisateur

ProMinent

ProMinent Ammonia Manuel utilisateur

ProMinent

ProMinent DULCOMETER D1C Manuel utilisateur

ProMinent

ProMinent DULCOMETER D1C A D Series Manuel utilisateur

ProMinent

ProMinent DULCOMETER Manuel

ProMinent

ProMinent DULCOTEST PAA 1-mA-200 ppm Manuel utilisateur

ProMinent

ProMinent DULCOMARIN 3 Compact Manuel

ProMinent

ProMinent DULCOMETER D1C Manuel utilisateur

ProMinent

ProMinent DULCOMETER D2C Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
