Proline CNC65WH2 Manuel utilisateur
BUILT-IN OVEN
FOUR ENCASTRABLE
INBOUWOVEN
CNC65WH2 / CNC65BK2
Table of Contents
WARNINGS…………………………………………………………………………....3
IMPORTANT SAFETY INSTRUCTIONS……………………………………….6
DESCRIPTION OF THE OVEN…………………………………………………...7
Control panel…………………………………………………………………...7
Oven accessories………………………………………………………… …... 8
INSTALLATION………………………………………………………………….…....9
ELECTRICAL CONNECTION………………………………………………….….10
OPERATION…………………………………………………………………………..10
Setting the Clock………………………………………………………..…..10
Cooking……………………………………………………………………..…..11
Setting the Timer……………………………………………………..…….13
Child Safety Lock function…………………………………………..….13
Energy Saving Function……………………………………………..……14
CLEANING AND MAINTENANCE…………………………………………....15
TECHNICAL DATA SHEET……………………………………………………....18
EN-2
DISPOSAL………………………………………………......................……....20
Cooking Time Reservation Function...………………………..……14
• Place the tray and wire rack at the same level on both sides, make sure they are in a
horizontal and stable position.
• Regarding the detailed instructions for the safe use of the appliance,the precautions
during user maintenance and bulb replacement, refer to the sections “Operation” and
“CLEANING and Maintenance”.
• The appliance must not be installed behind a decorative door in order to avoid overheating.
WARNINGS
If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in order
to avoid a hazard.
WARNING: The appliance and its accessible
parts become hot during use. Care should be
taken to avoid touching heating elements.
Children less than 8 years of age shall be
kept away unless continuously supervised.
This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning use of
the appliance in a safe way and understand
the hazards involved. Children shall not play
with the appliance. Cleaning and user
maintenance shall not be made by children
without supervision.
EN-3
This appliance is intended to be used in
household and similar
applications such as:
- staff kitchen areas in shops, offices and other
working environments;
- farm houses;
- by clients in hotels, motels and other residential
type environments;
- bed and breakfast type environments.
During use the appliance becomes hot. Care
should be taken to avoid touching heating
elements inside the oven.
WARNING: Accessible parts may become hot
during use.Young children should be kept
away.
Do not use harsh abrasive cleaners or sharp
metal scrapers to clean the oven door glass
since they can scratch the surface which may
result in shattering of the glass.
A steam cleaner is not to be used.
WARNING: Ensure that the appliance is
switched off before replacing the lamp to
avoid the possibility of electric shock.
The appliance is not intended to be operated
by means of an external timer or separate
remote-control system.
The means for disconnection must be
incorporated in the fixed wiring in
accordance with the wiring rules.
The appliance shall be installed in
accordance with national wiring regulations
NF C 15-100.
EN-4
The temperature of accessible surfaces may
be high when the appliance is operating.
After each cooking cycle, the cooling fan will
continue to run for a while to ensure quick
cooling and safe operation of the oven.
The door should preferably be closed in all
cooking modes.
Do not hang any cloth or garment to the
handle of the oven.
Do not line the oven’s cavity with aluminium
foil for easier cleaning: The oven may
overheat and the enamel coating of the
cavity may be damaged.
Regarding the instructions for the all
necessary spaces with dimensions, the
method of fixing and how the appliance is to
be fixed to its support, refer to the section
“INSTALLATION”.
EN-5
IMPORTANT SAFETY INSTRUCTIONS
The oven must be properly installed and grounded by a qualified
technician. We
will not be responsible for any damage that
might be caused by failure to comply
with these instructions.
Do not wear loose or hanging garments when using the oven.
They could ignite if they touch a hot heating element and this
may lead to the risk of burning yourself.
Do not store flammable materials on or near the oven. This may
cause a fire hazard.
Maintenance and repair work must be made only by authorized
service technicians.
It is dangerous to alter or modify the specifications of the
appliance in any way.
Do not try to lift or move the appliance by pulling the door
handle.
While the oven door is open, do not let children climb on the
door or sit on it.
Always use oven gloves to remove and replace food in the oven.
Make sure the control knobs are always in off position when the
appliance is not used.
EN-6
DESCRIPTION OF THE OVEN
Control panel
The oven is designed with two push-pull control knobs. These
knobs can be completely pushed inside the control panel when you
do not operate the oven.
Function control knob
Thermostat control knob
Timer button
Clock time button
Start button
Pause/stop button
EN-7
Oven accessories
Wire shelf:
for dishes and items for roasting and
grilling
Pan:
for cooking large quantities of food
such as moist cakes, pastries, frozen
food etc. or for collecting fat/spillage
and meat juices
Shelf support rail (2):
The shelf support rails on the left and
right sides inside the oven can be
removed for cleaning. Wire shelf and
pan can be rested in the desired
position between two runners.
Push the wire shelf / pan between the
guide bars of the shelf support rails in the
oven, and push it to the end.
In case the wire shelf and the pan are
inserted together, lay the wire shelf over
the pan.
EN-8
INSTALLATION
The diagram below determines the correct dimensions to install
the oven in a cabinet. This oven can also be installed as an under
counter oven.
Securing the oven to the counter
1. Fit the oven into the counter recess.
2. Open the oven door.
3. Secure the oven to the counter with
two holders (A) which fit the holes in
the oven frame and fit the two screws
(B).
WARNING: In order to ensure adequate
ventilation, ensure that there
are air inlets and outlets for
ventilating the interior of the
counter adequately.
EN-9
575
595
560
600 850
50
80
250
100
570
600
560
mm
595mm
mm
mm
mm
mm
mm
mm
mm
mm
mm
mm mm
