PROAIM VI-252-00 Manuel utilisateur

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that

is listed below.

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

Airwave Vibraon Isolator Arm (VI-252-00)

Ass e mb l y M a n u a l

Proaim Airwave Vibraon Isolator Arm Isolator

Ronin Mounng Plate

Flight Case

 Loosen Pole Clamps via knobs. Insert a pole

into clamps and ghten them properly.

 Aach Isolator onto the nose bracket of

Airwave Arm with help of bolts. Then ghten

these bolts with allen key.

Airwave Arm Setup

NOTE: Nose Bracket can be adjusted on two

levels, top and boom, as shown in image.

NOTE: Nose Plate can also be mounted in the

opposite direcon.

 Loosen springs to decrease the weighing

capacity & ghten them to increase the

weighing capacity.

Spring Adjustment

NOTE: Load Capacity can be easily adjusted by adjusng springs. Adjust both springs equally.

 With arm at levelled posion or slightly

above the horizontal posion, push down

the front of arm. It moves 3 to 4 mes

before reaching normal posion.

NOTE: It is very important to check the movement of arm.

 In order to smoothen Spring Tension evenly,

turn the adjustment knob. If the arm is too

so and moves up & down many mes, turn

it towards direcon of H (Hard). If the arm is

rigid turn it towards the direcon of S (So).

 In order to mount Ronin setup without

Isolator, aach Ronin Plate onto the Nose as

shown in image.

 Ronin can be easily aached onto Isolator

with 1/4”-20 and 3/8”-16 threads. Then lock

the Ronin plate.

Aaching the Ronin

Ronin Interface

YOUR PROAIM AIRWAVE VIBRATION ISOLATOR ARM

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon

and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

utmost support and care unl you use our product.
