Drive Wireless Follow Focus

(FF-WRLS-DR)

I N S T R UC T I O N M A NU AL

No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any

means, electronic, mechanical, photocopying, recording, or otherwise, except as may be expressly permitted by

the applicable copyright statutes or in writing by the Publisher.

PROAIM DRIVE WIRELESS FOLLOW FOCUS 2

INTRODUCTION

Proaim presents its exclusive wireless Follow Focus that allows you to set up a wireless lens

control system on your camera equipped with a geared lens and either 15mm or 19mm support

rods. It assists the camera operators in adjusng the focus or focal distance (zoom) of the camera

shoong remotely. The Wireless Follow Focus can be used along with matching camera control

gear like DSLR rigs, sliders, Steadycam kits, cranes/ jibs / dolly, Easy Rigs etc. The high torque

motor and a fast reacon speed allows to keep your subject in focus no maer how it moves.

The High grade controller features four memory buons to record dierent focusing points that

can be used repeatedly and also can be randomly switched and combined wilfully.

CONTENTS OF SHIPPING BOX:

IN THE BOX

Please inspect the contents of your shipped package to ensure you have received all that is

pictured and listed below.

Controller

Quick lock

Buon Quick lock Buon

with Servo motor

9V baery charger 2 x baery

Follow focus

gear ring

2x universal black

plug

Screw driver

2 x Drive gear

2x Anteena

Baery charger

Receptor

PROAIM DRIVE WIRELESS FOLLOW FOCUS 3

ASSEMBLING OF PROAIM DRIVE WIRELESS FOLLOW FOCUS

Controller power switch & receiver power

switch:

 Controller power light is on for 2 seconds,

then o; red power light and green signal

light of the receiver are always on.

NOTE: To set frequency, press FREQ buon

the light starts to cycle through colors. Stop

on preferred color. Repeat for each unit,

matching the colors. Verify DATA light is solid

green.

Frequency: 433-434 MHz (US 900MHz)

Memory keys use methods:

 Adjust the focus wheel or dial to the

desired focus point and press the

memory buon 1 for 3 seconds; if the

indicator light on the buon is on and red

signal is blink for a while, it indicates the

success of this focus memory the move to

the next focus memory. At the same

me, press memory key 2,3 and 4, to

respecvely record the focus.

Applicable occasions:

 Wireless follow focus can completely zoom widely in steadicam movement lens and the or-

bital moon lens.

Note:

 It may be insensive in operaon, because the baery voltage is too low. Please replace the

baery mely.

 Infrared shuers are divided into canon and Nikon. Tell the customer service sta about your

camera model when purchase.

 Insert the Anteena onto the Controller and Receptor.

PROAIM DRIVE WIRELESS FOLLOW FOCUS 4

The dial funcon:

 When adjust the desired focus the focus

posion can be recorded manually by

engraving lines.

Infrared wireless shuer funcon:

 Only suitable for canon and Nikon

cameras.

Playback speed adjustment key :

 Uses the memory buon to switch the

focus and adjust speed. Adjusng the

speed knob can change the speed of the

motor (with the memory eect, dierent

shoong eects can be achieved and

speed can be changed during zoom).

Install the camera and follow focus ring:

 Mount the camera to head and install the focus ring on the lens focus ring.

PROAIM DRIVE WIRELESS FOLLOW FOCUS 5

The receptor and quick lock buon

installaon

 Aach the quick lock buon with

receptor with the help of screws and

ghten the screws with the help of

screw driver.

 Install receptor and quick lock buon : loosen the knob of quick lock buon and mount it onto

the 15mm rods.

Note : Infrared emission lights of the receiver should be aligned infrared receiver side of the SLR

cameras, or the infrared shuer does not work.

 Loosen the side knob of quick lock buon with motor and mount it on 15mm rods. Now

ghten the side knob to secure.

ATTACHING QUICK LOCK BUTTON WITH MOTOR

PROAIM DRIVE WIRELESS FOLLOW FOCUS 6

 Loosen the boom knob and adjust the

gear to match with the follow focus ring.

 Insert motor assembly power cord into

receiver outlet.

YOUR PROAIM DRIVE WIRELESS FOLLOW FOCUS

ALL DRESSED UP AND GOOD TO GO

(SHOWN WITH OTPIONAL ACCESSORIES)

PROAIM DRIVE WIRELESS FOLLOW FOCUS 7

WARRANTY

We oer a one year warranty for our products from the date of purchase.

We will repair or replace your product, free of charge, in the event of a defect in materials or

crasmanship obtained during normal use or handling based on the user manual. Please note

that we will not cover any shipping costs for returning the product to us. If any VAT or import

dues are applied to the return, we will also charge these costs to the customer.

The warranty does not include, by the way of example, damage caused by products that we do

not supply or from mishandling in transit, accident, misuse, neglect, lack of care of the product ,

or service by anyone other than our company.

We are not liable for incidental or consequenal damages resulng from the use of the unit or

occurring due to any breach of this warranty.

Replacement parts of the product will be provided at nominal cost (covering the cost price of the

replacement parts only) to the customers aer the Warranty Period has expired. We will cover

the complete cost of sending replacement parts within the warranty period. Aer that, Nominal

cost of the product & Actual shipping cost will be charged.

Do not send the unit to us without rst geng a response and geng the approval to send back

the item.

In case of any kind of dissasfacon, we urge you to Contact us immediately and we shall do our

Best to help you out. For any other assistance you can reach us via email.

For any other assistance you can reach us via email.
