PRIXTON TE-001 Manuel utilisateur

SUITCASE STYLE BLUETOOTH TURNTABLE

Model No.: TE-001

Instruction Manual

Dear Customer,Thank you very much for your purchasing. Before using your new

product, please read these instructions to prevent any damage, and keep it for future

reference.

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use the speakers near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus

(including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. If the provided plug doesnot fit

into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience

receptacles, and the point where they exit from the unit.

11. Only use attachments/accessories specified by the manufacturer.

12. Unplug these speakers during lightning storms or when unused for long periods of time.

13. Refer all servicing to qualified service personnel. Servicing is required when the speakers have

been damaged in any way, such as the power-supply cord or plug is damaged, liquid has been

spilled or objects have fallen into the unit, the unit has been exposed to rain or moisture, does not

operate normally, or has been dropped.

14. To reduce the risk of fire or electric shock, do not expose the speakers to rain, moisture, dripping

orsplashing, and no objects filled with liquids, such as vases, must be placed on them.

15. DO NOT overload wall outlets or extension cords beyond their rated capacity as this can cause

anelectric shock or fire.

16. The wall plug is the disconnecting device. The plug must remain readily operable.

17. No naked flame sources, such as lit candles, should be placed on the speakers.

18. The ventilation should not be impeded by covering the ventilation openings with items such as

newspapers, tablecloths, curtains, etc.

This symbol indicates

that dangerous voltage

constituting a risk of

electric shock is

present within the unit.

This symbol indicates that

there are important

operating and maintenance

instructions in the literature

accompanying the unit.

BEFORE USING THE UNIT

As the unit may become warm during operation, always leave sufficient space around the unit for

ventilation.

The voltage supplied to the unit should match the voltage as printed on the rear panel.If you are in any

doubt regarding this matter, consult an electrician.

Choose the installation location of your unit carefully. Avoid placing it in direct sunlight orclose to a

source of heat. Also avoid locations subject to vibrations and excessive dust, heat,cold or moisture.

Do not place the unit on an amplifier/receiver.

Do not open the cabinet as this might result in damage to the circuitry or electrical shock. If aforeign

object should get into the unit, contact your dealer or service company.

When removing the power plug from the wall outlet, always pull directly on the plug, never yank the

cord.

To keep the laser pickup clean, do not touch it, and always close the disc tray.

Do not attempt to clean the unit with chemical solvents as this might damage the finish. Use a clean,

dry cloth.

Keep this manual in a safe place for future reference

DO NOT MOVE THE UNIT DURING PLAYBACK

During playback, the disc rotates at high speed.

Doing so may damage the disc or the unit.

WHEN MOVING THIS UNIT

When changing the unit’s location or packing the unit for moving, be sure to remove therecord or disc.

Moving this unit with the record or disc loaded may result in damage to thisunit. If the unit is to be packed

and moved a great distance, it is also advisable to tightenthe turntable transport locking screw.

HANDLING RECORDS

Do not touch the record's grooves. Only handle records by the edges or the label. Make sure your

hands are clean. Skin oils from even clean hands can leave a residue on the recordsurface that will

gradually deteriorate the quality of your record.

Should the record become dirty, gently wipe the surface in a circular motion, using a soft anti-static

cloth.

Keep your records away from dust. Keep them in a cool, dry place.

To avoid dust and scratches, keep records in their sleeves and jackets when not in use.

Store records upright on their edges. Records stored horizontally will eventually bend and warp.

Do not expose records to direct sunlight or high humidity and temperature. Long exposure to high

temperatures will warp the record.

Do not store your records in the trunk of your car.Thetemperature in a closed trunk can ruinyour

collection.

Store records in an area with a stable temperature and low humidity.

LOCATION OF CONTROLS

1. Turntable Platter

2. Turntable spindle

3. 45 RPM adaptor

4. Tone arm lift lever

5. Tone arm holder

6. Auto stop ON/OFF switch

7. Tone arm

8. Speeds select switch

9. Power ON-OFF/Volume knob

10. Headphone jack

11. Stylus

12. USB connector

13. TF connector

14. Button- Play modes select key/ Record

button

15. Next music or FM program switch

16. Pause and Play switch and DEL button

17. Previous music or FM program switch

18. LED Display

19. Aux in jack

20. Lock catch

21. Handle

22. Speakers

23. FM Antenna

24. LINE OUT jacks

25. DC In jack

GETTING STARTED

General Operation:

1. Open the top cover as the illustrated follows:

2. Connected the unit to AC power as instruct below.

Ensure that the mains voltage of your home corresponds to the operating voltage of the adaptor. Your unit

is ready to be connected to a mains voltage of 5V DC adaptor.

Connect the Power adapter to the wall outlet.

Connect the DC connector to the “DC IN” jack on the rear of the unit.

3. Turn the Power ON/OFF--Volume knob clockwise to power on the unit and set the volume to

thedesiredlevel.”-Pho”will show on the display.

4. When finished listening, turn the Power ON/OFF--Volume knob counterclockwise until display not light.

5. Close the cover then lock it.

Amplifier Connection (if required)

Whilst you can listen to your new Retro Suitcase Turntable using thebuilt in speakers, you may also wish to

connect it to your existing Hi-Fisystem. Connect the “line out” RCA ports to the “line input” on

yourmixer or amplifier using an RCA cable (not supplied).

Red plug into the Right Channel Input.

White plug into Left Channel Input.

Playing a record

1. In first time use, take off the protective cover from the stylus as the illustrated below:

2. Unlock the Tone Arm from the holder as the illustrated above.

3. Place the Record on the center spindle .

4. Note: If you are playing a 45 RPM Single (small size record), place the supplied 45 RPM adapter to

the center spindle then place the record on it.

5. Slide the Speed selector to 33 45 or 78 to match the play speed of the record.

6. Set the auto stop control to ON if you want the turntable to stop turning when it has reached the

end of the record. If the switch is set to OFF , the turntable will continue turning at the end of the

record.

7. Turn on the Power Switch , it comes to Phono mode automatically , And the display show “-Pho”.

Pleas note the Switchalso controls volume.

8. Raise the Lever to raising the Tone Arm then move it to the top of the desired location of the record.

Release the Lever to put the Tone Arm onto the record. Plays will auto start.

9. When finished playback, the unit will auto stop turning when Auto stop switch at “ON”position. If

Auto stop switch at “OFF’position, the turntable will continue turning at the end of the record.

10. Raise the Lever to rising the Tone Arm then put it back to the Holder . Release the Lever then

lock the Tone Arm on the Holder.

Bluetooth function

(lift up the tone arm and put it on the rest)

For first time use or re-pairing to a new BT Device, pairing it as below:

Turn on the Power Switch , thenpress “ M” button till it enter into Bluetooth mode. The display

shows “ bt” .

Note: The display shows“-Lod” when loading time .

Turn on the Bluetooth function of your device and enable the search or scan feature to find the

Bluetooth pairing name “***”. (See your device’s instructions to add or setup a Bluetooth device).

Select "***" from the device list when it appears on your device screen. If required, enter the pass

code “0000” to pair (link) with your device.

It will has beep sound if connected successful, then you can play music from your Bluetooth device.

Press theButton or to select previous or next track.

Press button to pause and play music.

Adjust volume by volume control or by your Bluetooth device.

Normal operation after paired:

Turn on the Power Switch , thenpress “ M” button till it enter into Bluetooth mode. The display

shows “ bt” .

Wait a few seconds until the unit auto paired to the external BT Device.

It will has beep sound if connected successful, then Plays the music in the paired BT Device as usual.

During playback, using the control buttons on the paired cell phone to skip the tracks; pause; play...etc.

USB/TF function

(lift up the tone arm and put it on the rest)

Turn on the Power Switch , and Insert your USBor TF card to slot or . If USBor TF card

inserted before, press “M”button till enter into USBor TF card mode.

The display will show “-Lod”, then it displays “USB” or “TF”, music will begin.

Press theButton or to select previous or next track.Press and hold theButton or

to fast-forward or fast-backward.

Press button to pause and play music.

Press and hold the button , the display will show “dEL”, then press the button again to

delete the current playing music.

Adjust volume by volume control .

FM function

(Lift up the tone arm and put it on the rest)

Turn on the Power Switch , thenpress “M”button till enter into FM mode. The display

shows “FM 87.5 MHz”.

Release the FM antenna and adjust the position to get clear channels.

Press the button to mute the sound . Press again to restore the sound.

Press and hole the button to automatic search FM radio. The tracks will be saved as P01, P02,

P03 ... when finished scan.

Press theButton or to select previous or next track.

Press and hold theButton or to previous or next track scan.

Adjust volume by volume control .

Aux in function

(Lift up the tone arm and put it on the rest)

USB/TF recording

Turn on the Power Switch , and Insert your USBor TF card to slot or . Press “M”button

till enter into Phono /Aux in /FM mode.

Then press and hold the “M” button till hear one time beep sound. It begins to record songs from

Phono /Aux in /FM to USB or TF card.

Stop recording. Press and hold the “M” button till hear two times beep sound. It stop recording and

save the recorded songs to USB or TF card as the last song.

Press “M”button till enter into USBor TF card mode to enjoy the recorded song.

Clear recorder music. Press and hold the button , the display will show “dEL”, and you will hear

beep sound twice , the currently playing music has been deleted.

HEADPHONE:

For private listening, connect the 3.5mm plug from the Earphone/Headphone (not supplied) into the

HEADPHONE jack on the top of unit. Sound from speakers will be auto cut.

MAINTENANCE

Turn on the Power Switch , and Insert aux in cable

(not supplied) to Aux in jack thenpress “M”

button till enter into Aux in mode. The display

shows “LINE”.

The other side of aux in cable connect your devise,

then you can enjoy the music.

Press the button to mute the sound . Press

again to restore the sound.

Adjust volume by volume control .

Note:The buttons or is useless when Aux in

mode. You can adjust the tracks by your devise.

How to replace the stylus

The stylus should last about 50 hours under normal use. However, it is recommended that the stylus be

replaced as soon as you notice a change in sound quality

Removing an old stylus:

1. Set a screwdriver at the tip of the stylus and push

down to the direction "A".

2. Pull the stylus out toward direction "B".

Installing a new stylus

1. Hold the tip of the stylus and insert the other

edge by pressing toward direction "C".

2. Push the stylus up toward direction "D" until it

locks at the tip.

Caution:

Do not remove or bend the stylus.

To avoid injury, do not touch the needle.

Turn off the unit's power before you replace the stylus.

Keep out of the reach of children.

Handle with care, as the stylus is delicate. Use of a bent or broken stylus may damage therecord and

cause the turntable stylus to malfunction.

Do not expose stylus to extreme heat.

Contact a qualified repair company if you experience difficulty in changing the stylus.

SPECIFICATIONS

Product Name

Suitcase Style Bluetooth Turntable

Speaker Driver

5W *2

Dimensions (each speaker)

L13.8” x D10.2’’x H4.9’’(L350 x D260 x H125mm)

Power

DC5V 1A

Inputs

1 x 3 .5 mm stereo mini-jack

1 x Bluetooth

1 x USB card

1 x TF card

PowerOutput

5Watts

Frequency Range:

FM : 87.5-108 MHz

3 Speeds

33; 45; 78 rpm

Auto stop

Auto Stop ON or OFF

RCA out

Yes

Recording

USB/TF card recording

ACCESSORIES

1 x User’s Manual

1 x AC/DC Adaptor (Input: AC 100-240V~; 50/60 Hz; Output: DC 5V, 1A, )

1 x 45 RPM Adaptor

TROUBLE SHOOTING GUIDE

PROBLEM

POSSIBLE CAUSE

REMEDY

GENERAL

No sound in general.

Volume not adjusted.

Adjust the Volume knob.

Source mode in wrong position.

Using the Mode button, select the

proper function as required.

Power cable disconnected or

loose.

Check the connection or the

Power cable.

The unit does reset to operation of

any button

Under the influence of electrostatic

phenomenon, the product may

malfunction and require user to

disconnect

Turn off the unit, disconnect the

mains plug, and reconnect after a

few seconds.

PHONO

No sound when playing vinyl

records

Volume not adjusted.

Adjust the Volume knob.

The sound is breaking up or

buzzing.

There are many dust on vinyl

records

Clean your records with an anti-static

cloth.

45RPM vinyl without use 45RPM

adaptor

Use 45RPM adaptor when play 45

RPM vinyl records

There has obstacles when rotating

Remove the obstacles and put the

devise on a horizontal table or place.

BLUETOOTH

No sound when playing audio via

Bluetooth

Your Bluetooth device has not been

paired properly.

Pairing your Bluetooth device

according to the Pairing name

“KXRM19”to a Device Section.

and playingAudio.

Table des matières

Autres manuels PRIXTON Platine

PRIXTON

PRIXTON VC400 Manuel utilisateur

PRIXTON

PRIXTON DETROIT Manuel utilisateur

PRIXTON

PRIXTON Century Manuel utilisateur

PRIXTON

PRIXTON VC600 Manuel utilisateur

PRIXTON

PRIXTON STUDIO DELUXE Manuel utilisateur

Manuels Platine populaires d'autres marques

Gemini

Gemini CDT-05 MKII Manuel utilisateur

Rotel

Rotel RP-820 Manuel utilisateur

Shuman

Shuman MC-250BT Manuel utilisateur

Stanton

Stanton STR8-150 Manuel utilisateur

Audio Technica

Audio Technica AT-LPW40WN Manuel utilisateur

Crosley

Crosley McQueen CR7011-GY Manuel utilisateur

Reloop

Reloop SMP-1 Manuel utilisateur

auna

auna TT-Classic Plus Manuel utilisateur

COMO AUDIO

COMO AUDIO Turntable Analog Manuel utilisateur

Dual

Dual 1009 F Manuel utilisateur

REED

REED Muse3C Manuel utilisateur

AXIOMTEK

AXIOMTEK OPS883-H Series Manuel utilisateur

Pioneer

Pioneer PL-71 Manuel utilisateur

Vestax

Vestax PDX-a1 Manuel utilisateur

Denon

Denon DP-400 Manuel utilisateur

Dual

Dual 504 Manuel utilisateur

Audio-Techica

Audio-Techica AT-LP60XBT Manuel utilisateur

Goldring

Goldring G99 Manuel utilisateur
