Prince Castle 297-T12 Manuel utilisateur

297-1/07

297 SERIES

SLIM-LINE VERTICAL

CONTACT TOASTER

SLIM-LINE VERTICALCONTACTTOASTER 297 SERIES

STANDARDFEATURES

• Delivers higher speeds and temperature while

maintaining proven reliable design

• Stronger motor and higher temperature platen

increases performance

•Unique two-level platen design allows operators

to toast thicker bun crowns and thinner bun

heels at the same time

•Adjustable bun crush controls and thermostat

allows precise toasting for various bread

products

•Compact design requires only 8" (20.3cm) of

counter space depth

• 12-, 20- and 40-second toasting models are

available

• Re-designed conveyor assembly improves

reliability

• Easy to clean and maintain

• Adjustable thermostat for precise toasting

•One-year parts and labor warranty

Prince Castle's Slim-line Bun Toaster provides perfect

carmelization by contact toasting. These toasters put

versatility in your kitchen by using less counter space. A

unique two-level platen design allows operators to toast

thicker bun crowns and thinner bun heels at the same

time. A self-adjusting chain assembly provides proper

tensioning and helps prevent binding. Model 297-T12

toasts 2000 buns per hour, Model 297-T20 toasts up

to 1400 buns per hour, and Model 297-T40 toasts up

to 720 buns per hour. Stainless-steel construction

makes this toaster durable and easy-to-clean.

All Prince Castle Slim-line Toasters include a Teflon

sheet kit consisting of a stainless-steel clamp and two

Teflonsheets to protect against bun sticking. These

sheets are used one at a time over the platen to protect

the toasting surface, to eliminate bun sticking, and to

keep the toaster clean and working properly.

Model 297-T12

355 E. Kehoe Blvd. - Carol Stream, IL 60188

Toll Free 1-800-PCASTLE - Tel (630) 462-8800 - Fax (630) 462-1460

ACCESSORIES

Part # Description

511 Top mounting bun dresser (manual only)

SPECIFICATIONS

*Designs and specifications are subject to change without notice.

297 SERIES SLIM-LINE VERTICAL CONTACT TOASTERS

297 SERIES

SLIM-LINE VERTICAL

CONTACT TOASTER

DIMENSIONS

ELECTRICAL

*297 units equipped with 6 ft. (182.8cm) line cord.

8.62

(21.9cm)

2.19 (5.56cm) TO

CENTER OF POWERCORD

25.67

(65.2cm)

25.50

(64.77cm)

3.11

(7.9cm)

MODEL PLUG PLUG

NUMBER VOLT HZ WATTS AMPS NUMBER CONFIG.

297-T12 120 60 1500 13 5-15P

297-T20

297-T40

297-T12FCE 230 50 1700 8 CEE 7-7

297-T20FCE

297-T40FCE

PRODUCT

OUTPUT

Model

Number Buns/Hour

297-T12 2000

297-T20 1400

297-T40 720

*Moisture content of bakery products will

affect rates and settings. Individual results

may vary.

MODEL HEIGHT WIDTH DEPTH SHIPPING WT.

NUMBER DESCRIPTION IN. (CM) IN. (CM) IN. (CM) LB. (KG)

297-T12P 12-Sec. Vertical Contact Toaster

297-T20 20-Sec. Vertical Contact Toaster

297-T40 40-Sec. Vertical Contact Toaster 25.7 25.5 8.6 75

297-T12PFCE 12-Sec. Vertical Contact Toaster (65.8) (64.8) (21.9) (34.3)

297-T20FCE 20-Sec. Vertical Contact Toaster

297-T40FCE 40-Sec. Vertical Contact Toaster

355 E. Kehoe Blvd. - Carol Stream, IL 60188

Toll Free 1-800-PCASTLE - Tel (630) 462-8800 - Fax (630) 462-1460
