Pride Wrangler Manuel utilisateur

Serial #

MV600

OWNER’S MANUAL

USA

182 Susquehanna Avenue

Exeter, PA 18643-2694

Canada

5096 South Service Road

Beamsville, Ontario L0R 1B3

Australia

20-24 Apollo Drive

Hallam, Victoria 3803

www.pridemobility.com.au

New Zealand

38 Lansford Crescent

Avondale

Auckland, New Zealand 1007

www.pridemobility.co.nz

32 Wedgwood Road

Bicester, Oxfordshire OX26 4UL

www.pride-mobility.co.uk

B.V.

(Authorised EU Representative)

De Zwaan 3

1601 MS Enkhuizen

The Netherlands

www.pride-mobility.nl

Italy

Via del Progresso, ang.Via del Lavoro

Loc. Prato della Corte

00065 Fiano Romano (RM)

www.pride-italia.it

France

26 rue Monseigneur Ancel

69 800 Saint-Priest

www.pridemobility.fr

Spain

Calle Velazquez 80 6D

28001 Madrid

www.pridemobility.com

4SAFETY GUIDELINES

INFMANU5056/Rev A/February 2019

WARNING! An authorized Pride dealer or qualiﬁed technician must perform the initial setup of

this vehicle and must perform all of the procedures in this manual.

The symbols below are used throughout this owner’s manual and on the vehicle to identify warnings and import-

ant information. It is very important for you to read them and understand them completely.

WARNING! Indicates a potentially hazardous condition/situation. Failure to follow designated

procedures can cause either personal injury, component damage, or malfunction. On the

product, this icon is represented as a black symbol on a yellow triangle with a black border.

MANDATORY! These actions should be performed as speciﬁed. Failure to perform mandatory

actions can cause personal injury and/or equipment damage. On the product, this icon is

represented as a white symbol on a blue dot with a white border.

PROHIBITED! These actions are prohibited. These actions should not be performed at any

time or in any circumstances. Performing a prohibited action can cause personal injury and/or

equipment damage. On the product, this icon is represented as a black symbol with a red circle

and red slash.

INTENDED USE

The intended use of the mobility device is to provide mobility to persons limited to a seated position that have the

capability of operating a scooter.

NOTE: This owner’s manual is compiled from the latest speciﬁcations and product information available at

the time of publication. We reserve the right to make changes as they become necessary. Any changes to our

products may cause slight variations between the illustrations and explanations in this manual and the product

you have purchased. The latest/current version of this manual is available on our website.

NOTE: This product is compliant with WEEE, RoHS, and REACH directives and requirements.

NOTE: This product meets IPX4 classiﬁcation (IEC 60529).

NOTE: The MV600 and its components are not made with natural rubber latex. Consult with the manufacturer

regarding any after-market accessories.

Dealer:

Address:

Phone Number:

Purchase Date: Serial Number:

Please ﬁll out the following information for quick reference:

MV600 3

CONTENTS

SAFETY GUIDELINES ............................................................................................... 2

I. SAFETY ............................................................................................................ 4

II. YOUR VEHICLE ............................................................................................... 7

III. BATTERIES AND CHARGING .......................................................................... 15

IV. OPERATION ................................................................................................... 22

V. COMFORT ADJUSTMENTS ............................................................................ 24

VI. DISASSEMBLY AND ASSEMBLY .................................................................... 28

VII. BASIC TROUBLESHOOTING ......................................................................... 29

VIII. CARE AND MAINTENANCE ........................................................................... 31

4 MV600

Manufactured in

Fully charge batteries before operating.

Remove key from an unattended vehicle.

Battery Set Conﬁguration:

+ = Positive (Red) Terminal Post

- = Negative (Black) Terminal Post

Connect Red wires to Red Positive (+) Terminal Posts.

Connect Black wire to Black Negative (-) Terminal Posts.

Read and follow the information in the owner’s manual.

I. SAFETY

PRODUCT SAFETY SYMBOLS

The symbols below are used on the vehicle to identify warnings, mandatory actions, and prohibited actions. It is

very important for you to read and understand them completely.

NOTE: There are more warnings identiﬁed and explained in the Consumer Safety Guide that is included with

your vehicle. Please become familiar with all the warnings and safety information found in the Consumer

Safety Guide and refer to this resource often.

Indicates UNOCCUPIED vehicle securement points

Does not meet ISO 7176-19 standards for occupied transport in a motor

vehicle. When travelling in a motor vehicle, do not sit in your vehicle.

MODEL #

Vehicle information label

MV600 5

I. SAFETY

GENERAL

MANDATORY! Do not operate your new vehicle for the ﬁrst time without completely reading and

understanding this owner’s manual and the Consumer Safety Guide.

Your vehicle is a state-of-the-art product. We provide an extensive variety of products to best ﬁt the individual

needs of the vehicle user.

There are certain situations where the vehicle user will need to practice operating the vehicle.

As you begin using your vehicle during daily activities, you will probably encounter situations in which you will

need some practice. Simply take your time and you will soon be in full and conﬁdent control as you maneuver

through doorways, on and off elevators, up and down ramps, and over moderate terrain.

Additional general information can be found on the supplemental information sheets and booklets included in your

Owner’s Package. Please fully read and review the information, and keep it readily available for future reference.

Below are some precautions, tips and other safety considerations that will help you become accustomed to operating

the vehicle safely.

PRE-RIDE SAFETY CHECK

Get to know the feel of your vehicle and its capabilities. We recommend that you perform a safety check before

each use to make sure your vehicle operates smoothly and safely.

Perform the following inspections prior to using your vehicle:

Check the condition of the tires. Make sure they are not damaged or excessively worn.

Check all electrical connections. Make sure they are tight and not corroded.

Check all harness connections. Make sure they are secured properly.

Check the brakes to ensure they operate properly.

Check the battery condition meter to ensure the batteries are fully charged.

Ensure the manual freewheel lever is in drive mode before sitting on the vehicle.

If you discover a problem, contact your authorized dealer for assistance. Please refer to the Contact Information

insert in your Owner’s Package.

BRAKING INFORMATION

Your vehicle is equipped with these powerful brake systems:

Regenerative: Uses electricity to rapidly slow the vehicle when the throttle control lever returns to the center/

stop position.

Disc Park Brake: Activates mechanically after regenerative braking slows the vehicle to near stop or when

power is removed from the system for any reason.

Handbrake: This lever provides you with emergency stopping power. See II. “Your Vehicle.”

6 MV600

I. SAFETY

HANDBRAKE LEVER

The handbrake lever contains hydraulic ﬂuid. When the lever is depressed, the ﬂuid is pushed through the brake

line to engage the brake pads against the brake discs. The handbrake lever is a completely sealed unit, meaning

that the hydraulic ﬂuid should not leak; however, there are certain safety measures that should be taken if the

handbrake lever becomes cracked or damaged.

Do not touch spilled material unless wearing protective equipment, such as safety goggles and gloves.

For small spills, cover the material with dry earth, sand or other non-combustible absorbent material. Once

absorbed, enclose the material in a plastic bag and contact your local waste disposal agency for proper disposal

measures. Do not expose the material to waterways or sewers.

If the eyes are exposed, check for and remove contact lenses. Flush eyes with cool, clean, low-pressure water

while occasionally lifting and lowering the eyelids. Seek medical attention if excessive tearing, redness or

pain persists.

If the skin is exposed, remove all contaminated clothing. Wipe off excess material and wash exposed skin

with soap and water. Seek medical attention if skin appears damaged or if irritation persists. Thoroughly clean

contaminated clothing before reuse. Discard contaminated leather goods.

If ingested, do not induce vomiting or give anything to drink unless directed to by a physician. Never give

anything by mouth to a person who is not fully conscious. Seek medical attention immediately.

If inhaled, move the affected individual to fresh air. If the affected individual is not breathing, immediately

begin rescue breathing. If breathing is difﬁcult, 100% humidiﬁed oxygen should be administered by a qualiﬁed

individual. Seek medical attention immediately and keep the affected individual warm and at rest.

If ignited, use dry chemical, foam, carbon dioxide or water fog to extinguish.

WARNING! Do not modify the handbrake lever or attempt to replace the hydraulic ﬂuid. If damage

occurs, follow the safety information in this section and contact your authorized dealer for

handbrake replacement. The hydraulic handbrake should only be serviced or replaced by your

authorized dealer.

WARNING! The handbrake contains hydraulic ﬂuid that can cause mild skin, eye and nasal/

bronchial irritation. Do not attempt to adjust or service the handbrake without proper protective

equipment such as safety goggles and gloves and wash hands after handling.

MV600 7

II. YOUR VEHICLE

TILLER CONSOLE

The tiller console houses all of the controls needed to drive your vehicle, including the LCD control panel,

handbrake lever, tiller adjustment lever, and the throttle control lever. See ﬁgure 1.

PROHIBITED! Do not expose the tiller console to moisture. In the event that the tiller console

does become exposed to moisture, do not attempt to operate your vehicle until the tiller console

has dried thoroughly.

IDENTIFICATION KEY

Figure 1.Tiller Console

Horn Buttons

These buttons activate a warning horn. Your vehicle must be powered up for the horn to be operational. Do not

hesitate to use the warning horn when doing so may prevent accident or injury.

Speed Adjustment Buttons

These adjustment buttons enable you to pre-select and limit your vehicle’s speed. This is indicated by the maximum

speed indicator on the LCD screen.

Press the image of the tortoise to decrease the speed of the vehicle.

Press the image of the rabbit to increase the speed of the vehicle.

Turn Signal Buttons

Press the appropriate turn signal button once to activate it. The turn signal will ﬂash on the LCD screen.

Press the same signal button to turn it off.

11 32

101112

1. HORN BUTTON

2. SPEED ADJUSTMENT

(INCREASE)

3. SPEED ADJUSTMENT

(DECREASE)

4. TURN SIGNAL BUTTONS

5. THROTTLE CONTROL LEVER

6. HI-LOW SWITCH

7. LIGHTS BUTTON

8. MIRROR AND MIRROR PLUGS

9. HANDBRAKE LEVER

10. MODE BUTTON

11. HAZARD LIGHTS BUTTON

12. SET BUTTON

13. LCD SCREEN

14. TILLER ADJUSTMENT LEVER

15. BRAKE LOCK

8 MV600

II. YOUR VEHICLE

Throttle Control Lever

This lever allows you to control the forward speed and the reverse speed of your vehicle up to the maximum speed

you preset with the speed adjustment. A throttle control lever is located on the underside of the left and right side

of the tiller handle. See ﬁgure 1.

To use throttle control lever:

To move Forward, use either of the following:

Use your left thumb to push the left side of the throttle control lever.

Use your right hand ﬁngers to pull back on the right side of the throttle control lever.

To move Rearward, use either of the following:

Use your right thumb to push the right side of the throttle control lever.

Use your left hand ﬁngers to pull back on the left side of the throttle control lever.

Release the throttle control lever and allow your vehicle to come to a complete stop before engaging the other side

of the lever. When the throttle control lever is completely released, it automatically returns to the center “stop”

position and engages your vehicle’s brakes.

High-Low Button

This button toggles the vehicle’s speed between HIGH and LOW.

Press the High-Low button once to set the speed adjustment to high. The High-Low indicator will display on

the LCD screen. See ﬁgure 1. Using this setting in conjunction with the speed adjustment buttons will allow

the vehicle to achieve speeds up to the maximum preprogrammed speed for the vehicle.

Press the High-Low button again to set the speed adjustment to Low. The High-Low indicator will not display

on the LCD screen. Using this setting in conjunction with the speed adjustment buttons will allow the vehicle

to achieve speeds up to the half the maximum preprogrammed speed for the vehicle.

Lights Switch

This switch controls your vehicle’s lighting system.

Press the lights button once to activate the lighting system. The light symbol will be shown on the LCD screen.

Press the lights button again to turn the lighting system off.

WARNING! Vehicle users are required to use their lights when visibility is restricted—day or night.

Hazard Lights Button

This button activates the 4-way yellow ﬂashers on your vehicle.

Press the button once to turn on the ﬂashers.

Press the button again to turn off the ﬂashers.

NOTE: The 4-way ﬂashers will ﬂash and a warning beep will sound as long as the hazard lights are on. See

ﬁgure 6 for volume control.

Tiller Adjustment Lever

For information on positioning and adjusting your tiller, see V. “Comfort Adjustments.”

Mirror Positioning and Adjustment

For information on positioning and adjusting your mirror, see V. “Comfort Adjustments.”

MV600 9

II. YOUR VEHICLE

IDENTIFICATION KEY

1. KEY SWITCH

2. OFF-BOARD CHARGER PORT

3. TILLER CONSOLE FUSES

1. OFF-BOARD CHARGER PORT

2. USB PORT

3. BATTERY FUSE

4. KEY FUSE

Figure 3. Lower Tiller Components

Figure 4. Off-board Charger Port/Tiller Console Fuses

Figure 2. Handbrake Lever and Brake Lock (in the

Locked Position)

LCD Screen and control panel settings

The LCD control panel offers easily intuited feedback

information via the LCD screen. See ﬁgure 1. The LCD

screen is also used during the set-up (activation) of the

various control panel settings.

Handbrake Lever

This lever provides you with emergency stopping power.

When in motion, release the throttle control lever and gently

squeeze the handbrake lever to come to a stop. Handbrake

effectiveness can be modiﬁed by tightening or loosening

the setscrew located on the handbrake lever. See ﬁgure 2.

The handbrake can be locked and used as as a parking brake

by squeezing the handbrake lever fully and moving the

brake lock to the locked position. See ﬁgure 2. To release

the brake lock, fully squeeze the handbrake.

WARNING! The handbrake is intended for

use as an emergency brake and/or parking

brake only.

Mode Button

Use the mode button to scroll between the odometer,

tripometer, temperature, and clock.

Off-board Charger Port

The off-board charger power cord plugs into this port during

battery charging. The off-board charger port is located on

the tiller.

Key Switch

Insert the key into the key switch and turn it clockwise

to power up (turn on) your vehicle.

Turn the key anticlockwise to power down (turn off)

your vehicle.

WARNING! If the key is turned to the “off”

position while your vehicle is in motion,

the electronic brakes will engage and your

vehicle will come to an abrupt stop!

Electrical System Fuses

Your vehicle is equipped with a series of electrical system

fuses, which help protect the off-board charging system,

key switch and lighting system from receiving an overload

of electrical current. These fuses are the same type used in

automobiles and are located in a compartment on the tiller.

NOTE: Keep all electrical areas clean and free of moisture

and foreign material.

IDENTIFICATION KEY

1. HANDBRAKE LEVER

2. SETSCREW

3. BRAKE LOCK

10 MV600

LCD SCREEN AND CONTROL PANEL SETTINGS

The LCD control panel offers easily intuited feedback information via the LCD screen. See ﬁgure 5. The LCD

screen is also used during the set-up (activation) of the various control panel settings. See chart 1.

II. YOUR VEHICLE

IDENTIFICATION KEY

Figure 5. LCD Screen

1. BATTERY CONDITION INDICATOR

2. LIGHTS INDICATOR

3. SPEED/ERROR CODE/VOLUME

4. HI-LOW INDICATOR

5. UNIT INDICATOR

6. MAXIMUM SPEED INDICATOR

7. RIGHT TURN INDICATOR

8. AM/PM

9. CLOCK

10. TEMPERATURE

11. DISTANCE/TIME/TEMP/ERROR MESSAGE

12. TRIPOMETER

13. ODOMETER

14. LEFT TURN INDICATOR

10121314 11 97

NOTE: To program control panel settings, Hi-Low Indicator must be switched off, and Maximum Speed

Indicator must be set to full.

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Pride Scooter

Pride

Pride Ultimate 3 CF3001 Manuel utilisateur

Pride

Pride Victory 9 Manuel utilisateur

Pride

Pride ELITE TRAVELLER PLUS Manuel utilisateur

Pride

Pride Victory Viper-3 Manuel utilisateur

Pride

Pride Icon Manuel utilisateur

Pride

Pride DESTINY Manuel utilisateur

Pride

Pride Go-Chair Manuel utilisateur

Pride

Pride PATHRIDER 140 XL Manuel utilisateur

Pride

Pride Libre SCOOTER SERIES Manuel utilisateur

Pride

Pride Hurricane Manuel utilisateur

Pride

Pride Hurricane PMV Manuel utilisateur

Pride

Pride Hurricane Manuel utilisateur

Pride

Pride Victory Manuel utilisateur

Pride

Pride CELEBRITY XL Manuel utilisateur

Pride

Pride Go-Go Elite Traveller SC40E Manuel utilisateur

Pride

Pride Hurricane PMV PMV5001 Manuel utilisateur

Pride

Pride MAXIMA Manuel utilisateur

Pride

Pride Jazzy 1113 Manuel utilisateur

Pride

Pride Celebrity X-6 Manuel utilisateur

Pride

Pride Victory 10 Manuel utilisateur

Pride

Pride Dynamo Manuel utilisateur

Pride

Pride PURSUIT Series Manuel utilisateur

Pride

Pride Sundancer Manuel utilisateur

Pride

Pride BAJA MOBILITY WRANGLER Manuel utilisateur

Manuels Scooter populaires d'autres marques

TEKTRO

TEKTRO CHEETAH Manuel utilisateur

Douglas

Douglas Vespa Sprint Guide d'installation

PLAYTIVE

PLAYTIVE AS-2448 Manuel utilisateur

Ebinger

Ebinger DONKEY XL Manuel utilisateur

Flyer

Flyer Mountain Guide de l'utilisateur

BackCountry eBikes

BackCountry eBikes Storm Manuel utilisateur

equipmed

equipmed FreeRoam II Manuel utilisateur

Yoto

Yoto Lion Manuel utilisateur

WESTHILL BIKES

WESTHILL BIKES LINK Manuel utilisateur

BAnff

BAnff eProdigy series Manuel utilisateur

Winther

Winther 475 Manuel utilisateur

Jetson

Jetson JBZL17 Manuel utilisateur

First Choice Mobility

First Choice Mobility Roma Medical Corella S741 Manuel utilisateur

Carrera

Carrera impel Manuel utilisateur

Afikim

Afikim Superlight SL-3 Manuel utilisateur

CareCo

CareCo ZOOM Manuel utilisateur

Douglas

Douglas Vespa G.S. Manuel utilisateur

Gazelle

Gazelle with BOSCH System Manuel utilisateur
