Pride Rally Manuel utilisateur

The Ultimate In Style & Performance

Owner’s Manual

www.pridemobility.com

21 Healey Road

Dandenong, 3175

Victoria, Australia ACN # 088 09 1

Please read and follow all instructions in this owners manual before attempting to operate your

Scooter for the first time. If there is anything in this manual you do not understand, or if you

require additional assistance for set-up, contact your local authorized Pride provider.

sing your Pride product safely depends upon your diligence in following the warnings, cautions,

and instructions in this owners manual. sing your Pride product safely also depends upon your

own good judgement and/or common sense, as well as that of your provider, caregiver, and/or

healthcare professional. Pride is not responsible for injuries and/or damage resulting from any

persons failure to follow the warnings, cautions, and instructions in this owners manual. Pride

is not responsible for injuries and/or damage resulting from any persons failure to exercise

good judgement and/or common sense.

The symbols below are used throughout this owners manual to identify warnings and cautions. It

is very important for you to read and understand them completely.

WARNING! Failure to heed the warnings in this owners manual may result in personal injury.

CAU ION! Failure to heed the cautions in this owners manual may result in damage to your

Scooter.

SAFETY GUIDELINES

Pride Mobility Products Australia Pty. Ltd.

INFMANU1438/REV D/OCTOBER 2002

Rally

I. INTRODUCTION ........................................................................................................................ 4

II. SAFETY .........................................................................................................................................

III. SPECIFICATIONS ..................................................................................................................... 9

IV. DESCRIPTION .......................................................................................................................... 11

V. BATTERIES AND CHARGING ........................................................................................... 1

VI. OPERATION ............................................................................................................................... 20

VII. COMFORT ADJUSTMENTS ................................................................................................ 22

VIII.DISASSEMBLY AND ASSEMBLY ..................................................................................... 24

IX. TROUBLESHOOTING ............................................................................................................ 2

X. CARE AND MAINTENANCE ............................................................................................... 27

XI. WARRANTY ............................................................................................................................... 28

CONTENTS

4Rally

I. INTRODUCTION

Welcome to

Pride Mobility Products Australia Pty. Ltd.

(Pride). Congratulations on the purchase of your new

Pride Scooter. Your Scooter design combines the most advanced state-of-the-art components with modern,

attractive styling. We are certain that the design features and trouble-free operation will add convenience to

your daily living and ensure complete satisfaction.

At Pride, your safety is important to us. Please read and follow all of the instructions in this manual before

you attempt to operate your Scooter for the first time. These instructions were produced for your benefit.

Your understanding of these instructions is essential for the safe operation of your new Pride Scooter.

Pride is not liable for damage to property or personal injury arising out of unsafe use of a Pride Scooter.

Pride is also not liable for any property damage or personal injury arising out of the failure of any person

and or/user to following the instructions and recommendations set forth in this manual or any other

instructions or recommendations contained in other Scooter related literature issued by Pride or contained

on the Pride Scooter itself.

This owners manual is compiled from the latest specifications and product information available at the time of

publication. We reserve the right to make changes as they become necessary. Any changes to our products may

cause slight variations between the illustrations and explanations in this manual and the product you had purchased.

If you experience any problems with your Scooter that your are unable to solve, or if you do not feel capable of

safely following any of the instructions and/or recommendations as contained in this manual, please contact

your authorized Pride provider for assistance.

Once you understand how to operate and take care of your Scooter, we are certain that it will give you years of

trouble-free service and enjoyment.

Information Exchange

We want to hear your questions, comments, and suggestions about this manual. We would also like to hear about

the safety and reliability of your new Pride Scooter, and about the service you received from your authorized

Pride provider.

Please notify us of any change of address, so we can keep you apprised of important information about safety,

new products, and new options that can increase your ability to use and enjoy your Pride Scooter. Please feel free

to write us at the address below:

Pride Mobility Products Australia Pty. Ltd.

21 Healey Road

Dandenong 3175

Victoria, Australia

Rally

My Authorized Pride Provider is:

Name:_______________________________________________________________________________

Address:_____________________________________________________________________________

Phone Number:________________________________________________________________________

Quick Reference Information:

Scooter Model:________________________________________________________________________

Serial Number:__________________________________________________________________________

Purchase Date:________________________________________________________________________

NOTE: If you ever lose or misplace your warranty card or your copy of this manual, call or write to us and

we will be glad to send you a new one immediately.

I. INTRODUCTION

Rally

As you begin to use your Rally during your daily activities, you will encounter situations that, at first, may

require some practice to negotiate on your Scooter. Simply take your time as you operate your Rally and

you will soon be in full and confident control as you maneuver through doorways, on and off of elevators,

up and down ramps, and over moderate terrain.

DOORS

nDetermine if the door opens toward or away from you.

nUse your hand to turn the knob or push the handle or push-bar.

nDrive your Rally gently and slowly forward to push the door open or drive your Rally gently and slowly

backwards to pull the door open.

ELEVATORS

Modern elevators have a door-edge safety mechanism that, when pushed, reopens the elevator door(s).

nIf you are in the doorway of an elevator when the door(s) begin to close, push on the rubber door edge

or allow the rubber door edge to contact your Scooter and the door will reopen.

nUse care that pocketbooks, packages, or Rally accessories do not become caught in the elevator door(s).

RAMPS AND OTHER INCLINES

More and more buildings have ramps with specified degrees of inclination. These ramps are designed for

easy and safe Scooter access. Some ramps may have turning switchbacks that require that you have good

cornering skills on your Rally.

nTake wide swings with your Rallys front wheel around any tight corners. If you do that, the Rallys rear

wheels will follow a wide arc, not cut the corner short, and not bump into or get hung up on any railing

corners.

nWhen driving down a ramp, keep the Rallys speed adjustment dial (see IV. Description) set to the

tortoise (slowest speed setting) to ensure a safely controlled descent.

nNever drive your Rally across the side of an incline or diagonally up or down an incline, and do not

stop, if possible, while driving up or down an incline.

nAvoid sudden stops and starts.

Other inclines may be natural or, if man-made, not designed specifically for Scooters. Figure 1 illustrates

your Rallys stability and its ability to climb grades under various weight loads.

II. SAFETY

68 kg 90 kg 113 kg

8,7% 7,0% 3,5%

Figure 1. Maximum Recommended Incline Angle

Rally

These tests were conducted with the Rallys seat in the highest position and adjusted backward on the seat

base to its farthest rearward position. Use this information as a guideline. Your Rallys ability to travel up

inclines is affected by your weight, your Scooters speed, your angle of approach to the incline, and your

Scooter setup.

nWhen you approach an incline, it is best to lean forward. See figures 2 and 3. This action will shift the

center of gravity of you and your Rally toward the front of your Scooter for improved stability.

DRIVING SURFACES

Your Rally was designed to provide optimum stability under normal driving conditions; dry, level surfaces

composed of concrete or asphalt. However, Pride recognizes the fact that there will be times when you will

operate your Rally on surfaces other than concrete or asphalt. So we have also designed your Rally to

perform admirably on packed soil, grass, and gravel.

nFeel free to use your Rally safely on lawns and in park areas.

nAvoid tall grass that can entangle the running gear.

nPacked soil and gravel, such as driveways or roads, will not present a problem for your Rally.

nAvoid loosely packed gravel and sand.

nIf you feel unsure about a driving surface, avoid that surface.

Figure 2. Normal Driving Position Figure 3. Increased Stabilit Driving Position

II. SAFETY

WARNING! Do not exceed the incline guidelines or any other specifications presented in this

manual.

8Rally

WARNING! Do not expose the electronics to any type of moisture at any time (rain, snow, mist, or

wash). Such exposure can damage the electronics. Never attempt to ride a Scooter that has been

exposed to moisture until it has dried thoroughly.

Do not operate or store your Scooter where it may be exposed to inclement weather conditions

such as rain, snow, mist, and below-freezing temperatures (such as storage on an outside car/van

potentially result in loss of control.

Do not operate your Scooter in icy or slippery conditions or on salted surfaces (i.e., footpaths or

roads). Such use may result in an accident, personal injury, or adversely affect the performance

and/or safety of your Scooter.

Always protect batteries from freezing temperatures and never charge a frozen battery. his will

damage the battery and may cause personal injury. Attempting to charge a battery in freezing

conditions does not prevent the battery from freezing.

SAFETY PRECAUTIONS

nDo not operate your new Rally for the first time without completely reading and understanding this

owners manual.

nDo not carry passengers on your Rally.

nDo not leave the key in the key switch when your Rally is unattended.

nMake certain that the seat is locked into place and that the key is removed from the key switch before

getting on or off of your Rally, and make certain that the seat is in a locked position when you are

operating your Scooter.

nReduce your Rallys speed when you are operating it on uneven terrain and soft surfaces.

nReduce your Rallys speed when you are driving it around a corner.

nNever drive your Rally across the side of an incline or diagonally up or down an incline, and do not

stop, if possible, while driving up or down an incline.

nProceed with extreme caution as you approach the downgrade of a ramp or other incline, and when

driving near a raised surface, unprotected ledges and drop offs (kerbs, porches, stairs, etc.).

nNever remove your Rallys anti-tip wheels or modify the Rally in any way that is not authorized by

Pride.

nUse extreme caution when operating your Rally on busy streets and in parking lots or shopping malls.

Never ride your Rally where you cannot safely and legally walk. Consult local municipal or state

agencies with regard to operating your Scooter on public roadways.

nDo not operate your Rally while you are under the influence of alcohol.

nCheck with your physician if you are taking any medications that may affect your ability to operate your

Rally safely.

nKeep your hands on the tiller and your feet on the floorboard when you are operating your Rally.

nMake certain that the tyres are properly inflated (30 pounds per square inch).

nNever use your Scooter as a seat in a moving vehicle.

nMake certain that the Rallys batteries are properly secured when you are transporting your Scooter in

another vehicle.

nDisconnect your Rallys batteries if you will not be using your Scooter for more than 48 hours.

nBattery posts, terminals and related accessories contain lead and lead compounds. Wash hands after

handling.

II. SAFETY

Rally

Figure 4. Rall Dimensions

80˚

Length

Rally Turning Radius

81 cm - 86 cm

30,5 cm

19 cm

42 cm - 47 cm

9 cm

104 cm

45,75 cm

40,5 cm

78,75 cm

53 cm

53 cm - 73,5 cm

III. SPECIFICATIONS

10 Rally

Length: 104 cm

Width: 53 cm

Tyre s: Type : Pneumatic

Front: 5 cm X 20 cm , Rear: 7,5 cm X 23 cm

Weight C apacity: 113 kg M aximum

Battery Type

(batteries not included): Two 12V, 17 AH, SLA (sealed lead-acid) or Two 12V, 32 AH, SLA

Horsepower: 1,0 hp (peak)

Charger: Onboard 2,5-Amp Charger

Speed (maximum): Variable up to 6,8 km/h

M a xim um G r a d e : S e e fig ur e 1 fo r inc line sta b ility d ia g ra m

Range: 19 - 24 km with 17 AH batteries, 24 - 32 km with 32 AH batteries

Turning Radius: 78,75 cm

Body Colours: Painted: Apple Red

Seating:

Style: Foldable molded plastic; removable seat covers with foam inserts are attached to seat.

Dimensions: 45,75 cm width (useable) x 30,5 cm height (useable) x 40,5 cm depth

Seat cover material: Gray fabric

Armrests: gray molded rubber

User-adjustable seat height, from ground: 53, 56, 58,5 cm

User-adjustable seat height, from scooter deck: 42; 44,5; 47 cm

Included Features:

Adjustable seat height and positioning, easily accessible battery-charger A/C plug receptacle,

external freewheel release lever, external circuit breaker reset button, removable floormat,

fro nt b a sk e t

Brakes: Electronic regenerative braking and electromechanical disc brake

Rear W heel Drive: Transaxle, 24 V

Wheels: Aluminum alloy wheels (rear wheels only), color matches shrouds

Tille r Typ e : A d justa b le

Freewheeling Mechanism

Av a ila b ility: External freewheel release lever located on upper left portion of rear shroud

Weight:

Total Weight of R ally

With two 12V 17 AH batteries: 53 kg

With two 12V 32 AH batteries: 63 kg

Component breakdown:

Front section: 11.3 kg

Rear section (without batteries or rear shroud): 18,4 kg

Rear plastic shroud: 1,2 kg)

Seat: 8,8 kg

Batteries: 12V, 17 AH: 6,3 kg; 12V, 32 AH: 11,3 kg

(NOTE: two batteries are required per scooter)

Basket: 0,7kg

Front-To-Rear Lockup: Lever lock system

Ground C learance: 9 cm

Optional Accessories:

R e a r b a s k e t, he a d lig ht, ta illight, sa fe ty fla g, s ingle c r ut c h h o ld e r, d o u b le c r utc h ho ld e r, o xygen

holder, walker holder, cane/crutch holder (bracket mount), cane crutch holder (armrest

mount), rearview mirror, cup holder

III. SPECIFICATIONS

Table des matières

Autres manuels Pride Scooter

Pride

Pride Libre SCOOTER SERIES Manuel utilisateur

Pride

Pride Victory 9 Manuel utilisateur

Pride

Pride MAXIMA Manuel utilisateur

Pride

Pride Victory Viper-3 Manuel utilisateur

Pride

Pride Victory 10 Manuel utilisateur

Pride

Pride Maxima Scooter SC900 Manuel utilisateur

Pride

Pride Hurricane PMV Manuel utilisateur

Pride

Pride Celebrity X LE Manuel utilisateur

Pride

Pride Sundancer Manuel utilisateur

Pride

Pride Go-Chair Manuel utilisateur

Pride

Pride Hurricane PMV Manuel utilisateur

Pride

Pride ELITE TRAVELLER PLUS Manuel utilisateur

Pride

Pride Cyclone Manuel utilisateur

Pride

Pride JAZZY 1113 ATS Manuel utilisateur

Pride

Pride PURSUIT Series Manuel utilisateur

Pride

Pride Jazzy 1105 Manuel utilisateur

Pride

Pride Sundancer Manuel utilisateur

Pride

Pride go-go ultra Manuel utilisateur

Pride

Pride Jazzy 1113 Manuel utilisateur

Pride

Pride Celebrity X-6 Manuel utilisateur

Pride

Pride Revo Manuel utilisateur

Pride

Pride Celebrity DX Sport Manuel utilisateur

Pride

Pride Legend Manuel utilisateur

Pride

Pride PATHRIDER 140 XL Manuel utilisateur

Manuels Scooter populaires d'autres marques

TEKTRO

TEKTRO CHEETAH Manuel utilisateur

Douglas

Douglas Vespa Sprint Guide d'installation

PLAYTIVE

PLAYTIVE AS-2448 Manuel utilisateur

Ebinger

Ebinger DONKEY XL Manuel utilisateur

Flyer

Flyer Mountain Guide de l'utilisateur

BackCountry eBikes

BackCountry eBikes Storm Manuel utilisateur

equipmed

equipmed FreeRoam II Manuel utilisateur

Yoto

Yoto Lion Manuel utilisateur

WESTHILL BIKES

WESTHILL BIKES LINK Manuel utilisateur

BAnff

BAnff eProdigy series Manuel utilisateur

Winther

Winther 475 Manuel utilisateur

Jetson

Jetson JBZL17 Manuel utilisateur

First Choice Mobility

First Choice Mobility Roma Medical Corella S741 Manuel utilisateur

Carrera

Carrera impel Manuel utilisateur

Afikim

Afikim Superlight SL-3 Manuel utilisateur

CareCo

CareCo ZOOM Manuel utilisateur

Douglas

Douglas Vespa G.S. Manuel utilisateur

Gazelle

Gazelle with BOSCH System Manuel utilisateur
