Pride Legend Manuel utilisateur

Owner’s Manual

The Ultimate In Style & Performance

www.pridemobility.com

21 Healey Road

Dandenong, 3175

Victoria, Australia

ATTENTION:

Read everything

in this manual

before operating

your Legend

2Legend

Please read and follow all instructions in this owners manual before attempting to operate your

Scooter for the first time. If there is anything in this manual you do not understand, or if you

require additional assistance for set-up, contact your local authorized Pride provider.

sing your Pride product safely depends upon your diligence in following the warnings, cau-

tions, and instructions in this owners manual. sing your Pride product safely also depends

upon your own good judgement and/or common sense, as well as that of your provider, caregiver,

and/or healthcare professional. Pride is not responsible for injuries and/or damage resulting

from any persons failure to follow the warnings, cautions, and instructions in this owners manual.

Pride is not responsible for injuries and/or damage resulting from any persons failure to exer-

cise good judgement and/or common sense.

The symbols below are used throughout this owners manual to identify warnings and cautions. It

is very important for you to read and understand them completely.

WARNING! Failure to heed the warnings in this owners manual may result in personal injury.

CAU ION! Failure to heed the cautions in this owners manual may result in damage to your

Scooter.

SAFETY GUIDELINES

Pride Mobility Products Australia Pty. Ltd.

INFMANU1334/REV D/OCTOBER 2002

3Legend

CONTENTS

I. INTROD CTION......................................................................................................................... 4

II. SAFETY .........................................................................................................................................

III. SPECIFICATIONS ..................................................................................................................... 9

IV. DESCRIPTION .......................................................................................................................... 11

V. BATTERIES AND CHARGING ............................................................................................ 17

VI. OPERATION ............................................................................................................................... 21

VII. COMFORT ADJ STMENTS................................................................................................ 23

VIII. DISASSEMBLY AND ASSEMBLY ..................................................................................... 2

IX. TRO BLESHOOTING ............................................................................................................ 29

X. CARE AND MAINTENANCE ................................................................................................ 31

XI. WARRANTY................................................................................................................................33

4Legend

I. INTRODUCTION

Welcome to Pride Mobility Products Australia Pty. Ltd. (Pride). Congratulations on the purchase of your new

Legend. The Legend design combines the most advanced state-of-the-art components with modern, attractive

styling. We are certain that the design features and trouble-free operation of your new Legend will add conve-

nience to your daily living.

At Pride, your safety is important to us. Please read and follow all instructions in this manual before at-

tempting to operate your Legend for the first time. These instructions were produced for your benefit. Your

understanding of these instructions is essential for the safe operation of your new Legend.

Pride is not liable for damage to property or personal injury arising out of unsafe use of a Legend. Pride is also not

liable for any property damage or personal injury arising out of the failure of any person and or/user to follow the

instructions and recommendations set forth in this manual or any other instructions or recommendations contained

in other Legend related literature issued by Pride or contained on the Legend itself.

This owners manual is compiled from the latest specifications and product information available at the time of

publication. We reserve the right to make changes as they become necessary. Any changes to our products may

cause slight variations between the illustrations and explanations in this manual and the product you have pur-

chased.

If you experience any problems with your Legend that you are unable to resolve, or if you do not feel capable of

safely following any of the instructions and/or recommendations contained in this manual, please contact your

authorized Pride provider for assistance.

Once you understand how to operate and take care of your Legend, we are certain that it will give you years of

trouble-free service and enjoyment.

INFORMATION EXCHANGE

We want to hear your questions, comments, and suggestions regarding this owners manual. We would also like to

hear about the safety and reliability of your new Legend, and about the service you receive from your authorized

Pride provider.

Please notify us of any change of address, so we can keep you apprised of important information regarding safety,

new products, and new options that can increase your ability to use and enjoy your Legend. Please feel free to

write us at the address below:

Pride Mobility Products Australia Pty. Ltd.

21 Healey Road

Dandenong, 3175

Victoria, Australia

5Legend

I. INTRODUCTION

PRIDE OWNERS CL B

As a Pride product owner, you are invited to register your products warranty and enroll in the Pride Owners Club.

You may do so by filling out and returning your enclosed registration card or by visiting Prides web site at

www.pridemobility.com. As a registered member, each time you visit our site, you will have access to the most

interactive and honest educational venue available today for people with mobility needs, their families, and friends.

From our home page, click on the button that reads Owners Club to enter a page dedicated to current and

potential Pride product owners. You will gain access to interviews, stories, recreation ideas, daily living tips,

product and funding information, and interactive message boards. Message boards invite you to communicate with

other Pride customers as well as Pride representatives who are available to assist you with any questions or

concerns you may have. You will receive a free gift simply for registering with the Pride Owners Club.

My Authorized Pride Provider Is:

Name:_______________________________________________________________________________

Address:_____________________________________________________________________________

Phone Number:________________________________________________________________________

Quick Reference Information:

Legend Model:__________________________________________________________________________

Serial Number:__________________________________________________________________________

Purchase Date:________________________________________________________________________

NOTE: If you ever lose or misplace your warranty card or owners manual,write to us and we will be glad

to send you a new one immediately.

Legend

II. SAFETY

You must read this entire manual and understand all of the safety precautions before attempting to operate your

new Scooter for the first time.

SAFETY PRECA TIONS

nDo not operate your Scooter in icy or slippery conditions or on salted surfaces (i.e., walks or roads). Such use

may result in an accident, personal injury, or adversely affect the performance and/or safety of your Scooter.

nDo not operate or store your Scooter where it may be exposed to inclement weather conditions such as rain,

snow, mist and below-freezing temperatures (such as storage on an outside car/van lift). Attempting to operate

the Scooter in such conditions can damage the electronics and potentially result in loss of control.

nDo not operate your Scooter where you cannot safely and legally walk. Use extreme caution when driving on

busy streets, in parking lots, or in shopping malls. Always assume that you cannot be seen by motor vehicle

drivers.

nLock your seat into place and remove the key from the key switch before you get on or off of your Scooter.

nLock the seat into position before you operate your Scooter.

nDo not operate your Scooter with the seat in the reclined position (if so equipped).

nMake certain that the tyres are properly inflated to (30 psi).

nDo not operate your Scooter while you are under the influence of alcohol. Operating powered vehicles while

you are under the influence of alcohol impairs your ability to operate the Scooter in a safe manner and may

violate certain laws.

nDo not operate your Scooter without first consulting your physician regarding any concerns you have about

physical limitations that could prevent you from safely operating your Scooter.

nDo not operate your Scooter if you are taking medication which may impair your ability to operate the Scooter

in a safe manner.

nDo not drive your Scooter across the side of a hill or diagonally up or down a hill; do not stop, if possible, while

driving up or down an incline.

nKeep both hands on the tiller and your feet on the floorboard at all times while operating your Scooter. This

driving position gives you the most control over your vehicle.

nProceed with extreme caution when driving near raised surfaces or unprotected ledges or drop-offs (kerbs,

porches, stairs, etc.).

nDrive slowly through turns.

nDo not use your Scooter as a seat in a moving vehicle. Your Scooter is not designed for such use and cannot

protect you in the event of an automobile accident or an abrupt stop.

nAlways protect batteries from freezing temperatures and never charge a frozen battery. This damages the

battery and may cause personal injury. Attempting to charge a battery in freezing conditions does not prevent

a battery from freezing.

nBattery posts, terminals and related accessories contain lead and lead compounds. Wash hands after handling.

CAU ION! Secure the batteries before loading your Scooter into another vehicle for transport.

CAU ION! Disconnect the batteries if you are not going to operate your Scooter for more than 48

hours.

WARNING! Do not expose the electronics to any type of moisture at any time (rain, snow, mist or

wash). Such exposure can damage the electronics. Never attempt to ride a Scooter that has been

exposed to moisture until it has dried thoroughly.

7Legend

II. SAFETY

As you begin to use your Scooter during daily activities, you will encounter situations that may require some

practice. Simply take your time as you operate your Scooter and you will soon be in full and confident control as

you maneuver through doorways, on and off of elevators, up and down ramps, and over moderate terrain.

DOORS

nDetermine if the door opens toward or away from you.

nUse your hand to turn the knob or push the handle or push-bar.

nDrive your Scooter slowly forward to push the door open, or drive your Scooter slowly backwards to pull the

door open.

ELEVATORS

Modern elevators have a door-edge safety mechanism that when pushed, reopens the elevator door(s).

nIf you are in the doorway of an elevator when the door(s) begin to close, push on the rubber door edge or

allow the rubber door edge to contact the Scooter to reopen the door.

nUse care that pocketbooks, packages, or Scooter accessories do not become caught in the elevator doors.

RAMPS AND OTHER INCLINES

More and more buildings have ramps with specified degrees of inclination, designed for easy and safe Scooter

access. Some ramps may have turning switchbacks that require you to have good cornering skills on your Scooter.

nTake wide swings with your Scooters front wheel(s) around any tight corners. If you do that, the rear wheels

will follow a wide arc and will not cut the corner short, bump into, or get hung up on any railing corners.

nWhen driving down a ramp, keep your Scooters speed adjustment dial. See IV. Description. Set to the

tortoise (slowest speed setting) to ensure a safely controlled descent.

nAvoid sudden stops and starts.

Other inclines may be natural or, if man-made, not designed specifically for Scooters. Figures 1 and 2 illustrate

your Scooters stability and its ability to climb grades under various weight loads and under controlled testing

conditions.

68 kg 90-113 kg 136 kg 68 kg 90 kg 113 kg 136 kg

8.7%

10.5%

12.3% 8.7%

10.5%

12.3%14.1%

FIGURE 2. MAXIMUM RECOMMENDED INCLINE

ANGLE 4-WHEEL

FIGURE 1. MAXIMUM RECOMMENDED INCLINE

ANGLE 3-WHEEL

8Legend

Controlled incline testing was conducted with the Scooters seat in the highest position, adjusted backward on the

seat base to the farthest rearward position. These tests show that your Scooters ability to travel up inclines is

affected by your weight, your Scooters speed, your angle of approach to the incline, and your Scooter setup.

When you approach an incline, it is best to lean forward. See figures 3 and 4. This shifts the center of gravity of

you and your Scooter toward the front of the Scooter for improved stability.

II. SAFETY

WARNING! Do not exceed the incline guidelines or any other specifications presented in

this manual.

DRIVING S RFACES

Your Scooter was designed to provide optimum stability under normal driving conditions  dry, level surfaces

composed of concrete or asphalt. However, Pride recognizes that there will be times when you will operate your

Scooter on surfaces other than concrete or asphalt. For this reason, we also designed your Scooter to perform

admirably on packed soil, grass, and gravel.

nUse your Scooter safely on lawns and in park areas.

nAvoid tall grass that can become tangled in the running gear.

nPacked soil, gravel, driveways, or roads will not present a problem for your Scooter.

nAvoid loosely packed gravel and sand.

nIf you feel unsure about a driving surface, avoid that surface.

FIGURE 4. INCREASED STABILITY DRIVING POSITION

FIGURE 3. NORMAL DRIVING POSITION

9Legend

III. SPECIFICATIONS

FIGURE 5. LEGEND SPECIFICATIONS

61 cm

114 cm104 cm

46 cm

41 cm

61 - 71 cm

123 cm

128 cm

4Wheel Turning Radius

4Wheel Length

3Wheel Length

3Wheel Turning Radius

8 cm

90˚,100˚

102˚,105˚

3 cm

47 cm

Adjustable

20-31cm

99 -109 cm

42 - 52 cm

10 Legend

Length: 3-wheel: 123 cm; or 4-wheel: 128 cm

Width: 61 cm

Tyres: Type: Pneumatic

Front: 7,5 cm 25 cm; Rear: 10 cm 25 cm

Weight Capacity: 136 kg ma imum

Battery Type (not included): Two 12-volt, 32 AH, U-1 type, sealed lead-acid (SLA); or

two 12-volt, 40 AH, U-1 type, SLA

Horsepower: 1,2 hp (peak)

Charger: Onboard 3-amp charger

Speed (Max): Variable up to 8,4 km/hr (60% reverse)

Maximum Grade: Please refer to figures 1 and 2.

ange: 12-volt 32 AH batteries: 32 - 40 km;

or 12-volt 40 AH batteries: 40 - 48 km

Turning adius: 3-wheel: 104 cm; or 4 wheel: 114 cm

Body Colour: Candy Apple Red

Seating: Style: Contour medium back with sliders

Dimensions: 47 cm width (usable) 47 cm height (usable)

41 cm depth

Seat Cover Material: Gray vinyl with coloured piping

Armrests: Black

User adjustable seat height from ground: 52 cm to 62 cm

User adjustable seat height from Scooter deck: 42 cm to 52 cm

Included Features: Dynamic front and rear suspension; non-marring bumpers; full directional light

package; adjustable seat height and positioning; height adjustable armrests;

sliding seat; energy saving auto shutoff feature

Brakes: Dynamic regenerative braking and electromechanical disc park brake

ear Wheel Drive: Sealed transa le, 24 VDC motor

Wheels: MicroMag aluminum alloy wheels; black

Tiller Type: Infinitely adjustable

Freewheel Mechanism: Manual freewheel release lever located on upper-right rear portion of rear shroud

Legend Weight: Total weight with batteries: 12-volt 32 AH: 3-wheel: 48 kg; 4-wheel: 51 kg ; or 12-volt

40 AH: 3-wheel: 94 kg; 4-wheel: 102 kg

Component Breakdown:

Front Section: 3-wheel: 65 kg; 4 wheel: 73 kg

Rear Section (w/out batteries, shroud, or tray): 3-and-4 wheel: 18 kg

Rear Plastic Shroud: 2 kg

Seat: 17 kg

Batteries: 12-volt 32 AH: 11 kg each; or 12-volt 40 AH: 15 kg each

Tray: 2 kg

Basket: 1 kg

Front-to-rear Lockup: Lock pin and lever system

Ground Clearance: 8 cm

Optional Accessories: Cane/crutch holder, cup holder, front basket, front bumper, headlight, o ygen

holder, power seat assembly, rear basket, rear bumper, rearview mirror, safety flag,

taillight, walker holder, seatbelt

III. SPECIFICATIONS

Specifications

Table des matières

Autres manuels Pride Scooter

Pride

Pride Pursuit Manuel utilisateur

Pride

Pride Celebrity X LE Manuel utilisateur

Pride

Pride DESTINY Manuel utilisateur

Pride

Pride 36 Manuel utilisateur

Pride

Pride CELEBRITY XL DELUXE Manuel utilisateur

Pride

Pride Hurricane PMV PMV5001 Manuel utilisateur

Pride

Pride Victory XL Manuel utilisateur

Pride

Pride Celebrity Deluxe Manuel utilisateur

Pride

Pride Wrangler Manuel utilisateur

Pride

Pride Sundancer Manuel utilisateur

Pride

Pride Hurricane Manuel utilisateur

Pride

Pride Victory Manuel utilisateur

Pride

Pride Hurricane PMV Manuel utilisateur

Pride

Pride Go-Go ES8 Manuel utilisateur

Pride

Pride Victory XL-4 Manuel utilisateur

Pride

Pride Victory Viper-3 Manuel utilisateur

Pride

Pride MAXIMA Manuel utilisateur

Pride

Pride Hurricane PMV Manuel utilisateur

Pride

Pride BAJA BANDIT Manuel utilisateur

Pride

Pride Sundancer Manuel utilisateur

Pride

Pride Celebrity X-6 Manuel utilisateur

Pride

Pride CELEBRITY X Manuel utilisateur

Pride

Pride JAZZY 1113 ATS Manuel utilisateur

Pride

Pride Victory ES Series Manuel utilisateur

Manuels Scooter populaires d'autres marques

TEKTRO

TEKTRO CHEETAH Manuel utilisateur

Douglas

Douglas Vespa Sprint Guide d'installation

PLAYTIVE

PLAYTIVE AS-2448 Manuel utilisateur

Ebinger

Ebinger DONKEY XL Manuel utilisateur

Flyer

Flyer Mountain Guide de l'utilisateur

BackCountry eBikes

BackCountry eBikes Storm Manuel utilisateur

equipmed

equipmed FreeRoam II Manuel utilisateur

Yoto

Yoto Lion Manuel utilisateur

WESTHILL BIKES

WESTHILL BIKES LINK Manuel utilisateur

BAnff

BAnff eProdigy series Manuel utilisateur

Winther

Winther 475 Manuel utilisateur

Jetson

Jetson JBZL17 Manuel utilisateur

First Choice Mobility

First Choice Mobility Roma Medical Corella S741 Manuel utilisateur

Carrera

Carrera impel Manuel utilisateur

Afikim

Afikim Superlight SL-3 Manuel utilisateur

CareCo

CareCo ZOOM Manuel utilisateur

Douglas

Douglas Vespa G.S. Manuel utilisateur

Gazelle

Gazelle with BOSCH System Manuel utilisateur
