Prestigio multipad pmp5080b Manuel utilisateur
PMP5080B EN - 1
1. Packing List
1. Prestigio MultiPad
2. AC Adapter
3. Carrying Case
4. USB Cable
5. Quick Start Guide
6. Warranty Card
7. Legal and Safety Notices
2. Device Overview
Quick Start Guide
Prestigio MultiPad
PMP5080B
EN
3
5
6
10
4
7
8
11
12
13
14
9
2
1
EN –2 PMP5080B
Vol +\ Vol - Button
Adjust the volume level
Power
Turn on/off the device; Suspend/Activate
the device
ESC
Back up to the previous page
Menu
Display menu options
Home
Back to the Home screen
Search
Go to Google home search page directly
Camera
Take photos
Reset
Reset the device if it fails to operate
correctly.
Micro SD Card
Slot
Insert Micro SD card.
DC Port
AC adapter connection.
Mini-HDMI video
output
HDMI cable connection.
Built-in Microphone
Record sounds.
USB port
USB connection.
Earphone Jack
Earphones connection.
Getting Started
3. Charging
Insert the AC connector to the DC port on the device and connect the
power adapter to the wall socket for charging.
Normally it takes approximately 4 hours to fully charge the device.
Operating the device while charging with the AC adapter may extend
the time of full charging.
4. Power on/Power off
Press and hold the Power Button to turn on the device. It will
automatically enter the Home screen after the start-up screen.
Press the Power Button once to enter sleep mode and press it again
to awake the device.
Press and hold the Power Button, and then tap on Power
off/Standby to power off the device or to enter sleep mode.
13
12
11
10
8
9
14
7
6
5
4
3
2
1
EN
Quick Start Guide
Prestigio MultiPad
PMP5080B
PMP5080B EN - 3
5．Inserting a Memory Card
The device supports micro SD/SDHC cards.
To insert a Micro SD card, place the card connector towards the front
side of the device and the printing side of the card towards the rear
side of the device.
To remove the micro SD card, gently press the edge of the card to
release the safety lock and pull the card out of the slot.
To access the files on the memory card, select File icon and tap on SD
Card.
Notice:
When you are reading the file from micro SD card, please don’t
remove it, or the device could fail to operate correctly.
6. Home Menu
7. Shortcuts
On the Home screen the following shortcuts are available:
EN
Quick Start Guide
Prestigio MultiPad
PMP5080C
More Applications
Tap to pop up
applications page
Weather Forecast
(Wi-Fi connection is
required)
EN –4 PMP5080B
Back - returns to the previous screen.
Menu - offers menu options according to the current screen.
Home - press once: return to the Home screen. Press and
hold: jump to one of the recent applications.
Volume - adjust the volume
8. Using the Keypad
Tap on the Caps Lock button to toggle between uppercase/lowercase
letter input methods.
Tap on the Shift button to toggle between number/symbol/letter
input methods.
Press the Backspace button to delete a character before the cursor.
Press the Enter button to confirm the option. Press the Space button
to input a space.
9. Connecting to WiFi
In the Home menu press the icon and select Settings icon to
access the list of options. Select Wireless & networks.
If the WiFi is off, tap on the Wi-Fi line to turn it on. Then select the
Wi-Fi settings.
EN
Quick Start Guide
Prestigio MultiPad
PMP5080B
Caps Lock
Shift
Backspace
Enter
Space
PMP5080B EN - 5
The device will scan for available WiFi networks and display them at
the bottom of the screen.
Tap on the network you want to connect to. Then tap inside the
Wireless password field to make the virtual keyboard appear. Enter
the required network information, tap on Done, and then tap on
Connect.
Your device will now attempt to establish a connection to the WiFi
access point with the network parameters you entered.
10. Transferring content from PC
Connect the device to your PC/Notebook using the USB cable.
Select the content you want to transfer from your PC/Notebook.
Drag the content from the PC/Notebook to the device.
Please do not disconnect the USB cable during loading. It may cause
malfunction of the device and files.
Left click on to disconnect the device and PC/Notebook safely.
11.Downloading content from AppsLib
You can download free or paid applications directly from your device
using the AppsLib application marketplace.
Before entering the AppsLib make sure the WiFi connection is
established.
With Internet connection established, press the icon on the
Home screen.
Upon entering the AppsLib you can view the list of free and
purchasable applications as well as install the preferred applications.
After pressing the Menu tab the device will offer the following
options:
My apps
View the list of installed applications. Update or
uninstall apps.
Settings
Change AppsLib account settings, Clear cache and
Clear search cache.
About
Access the AppsLib End User Licence Agreement.
Exit
Exit the program.
Quick Start Guide
Prestigio MultiPad
PMP5080B
EN
EN –6 PMP5080B
Technical Specifications
Processor
High performance ARM Cortex A8 at 1 GHz
RAM
512MB DDR3
OS
Android 2.3 (Gingerbread)
Display
8”TFT LCD, Capacitive multitouch
Resolution
800 x 600 pixels
Supported File
Formats
Video:AVI、3GP、MP4、RM、RMVB、FLV、MOV
Audio: MP3/WMA/WAV/OGG/FLAC/APE/AAC
Picture: JPEG(Baseline)、BMP、GIF（Static）、 PNG
Storage capacity
4 GB flash memory (2.81GB are accessible by
user), Memory card slot supports micro SDHC card
up to 32 GB
Interfaces
USB 2.0, Micro SD (micro SDHC compatible), USB
Host, HDMI
Communications
WiFi (802.11 b/g/n)
Battery
5400 mAh Li-Pol battery
Dimensions
203.1*153.4*11.2（mm）(L x W x H)
Weight
510 g
Disclaimer
As the Prestigio products are constantly updated and improved, your
device’s software may have a slightly different appearance or modified
functionality than presented in this Quick Start Guide.
Quick Start Guide
Prestigio MultiPad
PMP5080B
EN
