Polygroup TG76P4870C00 Manuel utilisateur

MODEL #: TG76P4870C00 1

ASSEMBLY INSTRUCTIONS MADE IN CHINA

• Before you start to assemble your tree, choose an appropriate location near a wall outlet.

• Do not plug the extension cord into the wall outlet while it in the packaging.

• Assemble the tree stand and place on a level surface. (See Fig. B)

Congratulations on purchasing your new tree from Polygroup®!

Carefully follow the instructions below on how to quickly and easily set up your new tree.

TREE ASSEMBLY INSTRUCTIONS

SET UP INSTRUCTIONS WITH QUICK FOLDTM

Insert Section 1 into the tree stand.

Section 1

A. Locate “Pull Here” tab and corresponding

Cinch Handle

B. Hold Cinch Clip firmly with one hand and

press down on clip

C. With Cinch Clip depressed, pull clip away from

tree until all branches are released.

Cinch

Handle

Cinch Clip

Section 1

Section 3

Section 2

Each tree section is numbered

with a tag. Please identify all

sections before assembling.

Fig. A - Tree and Light Assembly

Fig. B - Tree Stand Assembly

Unfold the legs and lay the

stand in a flat area.Then slide

the locking disc downward and

snap into place.

Do Not Tamper

Internal Parts

Open the

protective

cover

Do Not Tamper

Internal Parts

Open the

protective

cover

Insert

Green Label

Plug Into Wall

Outlet

Section 1

Section 2

Section 3

Quick FoldTM Cinch

Quick Set®

Connections

Quick Set®

Connections

Foot Pedal

on/off Switch

ASSEMBLY INSTRUCTIONS MADE IN CHINA

Top view Side view

Fig. C

• Insert green label plug into the wall outlet. (see Fig. A ), your entire tree should now be lit. If some bulbs

do not light or flickers, search for any loose plugs and/or broken, loose or missing bulbs. Connecting the

plugs or replace the bad bulbs promptly in order to maintain the performance and life expectancy of

your pre-lit tree.

• Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from

the pole and fan out one to the right, one to the left and one at the center of the main stem. (See Fig. C)

• After shaping the entire tree following the previous step, slightly upsweep all branch tips for a uniform

look. Shift branches to fill any gaps.Your Christmas tree is now complete and ready to be decorated.

STORAGE INSTRUCTIONS WITH QUICK FOLDTM

• Unplug extension cord from the wall outlet first and then remove all ornaments and decorations.

• When not in use, please store your tree in a cool, dry place away from sunlight. Exposing your tree to

excessive heat or humidity may damage your tree.

Section 2

Section 1

Detach Section 2 and put it into

the box.

Section 3

Detach tree top and store it

in box.

Section 1

Section 2

Section 3

Detach section1 from the tree stand

and place into box. Then fold up tree

stand by unlock the disc and then

store in box.

Release all branches using the same

procedures described in step 3.

Section 1

Section 2

Section 1

Fold the lower layer of Section 2

like step 2.

Section 1

Cover the protective cap of tree

bottom Section 1, then follow step 2

to fold tree.

Remove the protective cap of Section 2

and add Section 3.

Section 3

A. Cover the protective cap of the Section 2.

B. Hold Cinch Handle with one hand.

C. Hold Cinch Clip firmly with other hand and press down on clip.

D. Pull handle toward you while pushing away cinch clip

until the upper branches of tree middles Section 2 are

folded completely.

C D

Remove the protective cap of Section1

and add Section 2.

Section 1

Section 2

ASSEMBLY INSTRUCTIONS MADE IN CHINA

TROUBLE SHOOTING TIPS

SPARE PARTS

For Pre-lit Trees, If The Tree Does Not Illuminate

1. Please check to make sure that all plugs are properly connected and power cord is plugged into the wall

outlet. (If the tree comes with a foot pedal, try stepping on the on/off button).

2.Turning the poles gently to make sure pole to pole are connected into place.

3. Check for loose connection between light string plugs and extension cords.

4. Please check for loose, broken or missing light bulbs and replace as needed.

1. Extra hinge pins are included for repairing the hinges. Place the branch into the slot of the bracket.

2. Insert a new hinge pin through the hole and secure using the retainer washer.(See Fig. D)

Each tree includes hinge pins/washers, and for pre-lit

trees spare bulbs and fuses are also included. If extra

parts are needed, please contact our customer service

center.

Loose Hinge Pin

Fig.D

CUSTOMER SERVICE FOR CHRISTMAS TREES

For any questions, assistance, or missing parts, Do Not Return To Place Of Purchase. Please contact

us at 1-888-919-0070 or visit our website at www.polygroup.com. One of our customer service

representatives will be happy to assist you.

TREE ID# IS LOCATED ON END PANEL OF BOX. TREE ID# IS REQUIRED WHEN REQUESTING REPLACEMENT PARTS.

Customer Name:

Address:(No P.O. Boxes)

City & State:

Zip Code:

Day Phone:

Date Purchased:

Tree ID#:

Tree UPC#:

Store Purchased:

Specify Problem:
