Polygroup TG46M4E28D00 Manuel utilisateur

ASSEMBLY INSTRUCTIONS MADE IN CHINA

3. Please identify all sections before assembling.

4. Assemble the tree from the bottom to the top. Start with the bottom section and insert it into the

assembled stand.Make sure the pole is firmly inserted and secured into the stand.

5. Continue by inserting the upper tree section(s) to the lower section(s) until inserting the tree top.

6. Allow branches to fall into place or gently pull up and out.When adjusting branches, be sure that all

wires are free of branch hinges.

7. Insert green label extension cord into adaptor and adaptor insert into the wall outlet. (See Fig. B), your

entire tree should now be lit.If some bulbs do not light or flickers, search for any loose plugs and/or

broken, loose or missing bulbs. Connecting the plugs or replace the bad bulbs promptly in order to

maintain the performance and life expectancy of your pre-lit tree.

8. Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from

the pole and fan out one to the right,one to the left and one at the center of the main stem.(See Fig. C)

9. After shaping the entire tree following the previous step, slightly upsweep all branch tips for a uniform

look. Shift branches to fill any gaps.Your Christmas tree is now complete and ready to be decorated.

1. Before you start to assemble your tree, choose an appropriate location near a wall outlet.

2. Assemble the tree stand and place on a level surface. (See Fig. A)

Congratulations on purchasing your new tree from Polygroup®! Carefully follow the instructions

below on how to quickly and easily set up your new tree.

TREE ASSEMBLY INSTRUCTIONS

Top view Side view

Fig. C

MODEL #: TG46M4E28D00 SKU: 741-743

*Electrical Rating For The Tree

(For Indoor Use Only)

Input: 120V, 60Hz, 0.16A

Output: 29V DC 0.28A

Fig. B - Tree and Light Assembly

Fig. A - Tree Stand Assembly

Unfold the legs and lay the

stand in a flat area.Then slide

the locking disc downward and

snap into place.

Tree top

Section 1

Adaptor

To Be Plugged

Into Wall

Outlet

Insert Green

Label Extension

Cord into Adaptor

Control box

Insert Red Label

Plugs Into Red

Labeled Extension Cord

ASSEMBLY INSTRUCTIONS MADE IN CHINA

1. Remove all ornaments and decorations. For pre-lit trees, first unplug adaptor from the wall outlet and

then disconnect light extension cord between each section of the tree.

2. Disassemble the tree from the top to the bottom. Start with the tree top and gently lift straight up to

remove from section below and fold all branches toward the pole.

3. In case of difficulty separating the tree pole (trunk), apply a small amount of lubricant at the joint and

rotate the upper pole in both directions. Lift up the upper pole again.

4. Continue by gently lifting straight up each section(s) from the section below and fold all branches

toward the pole until the bottom section is removed from the tree stand.

5. Carefully place all tree sections into shipping box and tape it shut.

6.When not in use, please store your tree in a cool, dry place away from sunlight. Exposing your tree to

excessive heat or humidity may damage your tree.

STORAGE INSTRUCTIONS

For Pre-lit Trees, If The Tree Does Not Illuminate

1. Please check to make sure that all plugs are properly connected according to the color labels indicated

in Fig.B and the adaptor is plugged into the wall outlet. Refer to assembly guide for instructions.

2. Please check for loose, broken or missing light bulbs and replace as needed.

Loose Hinge Pin

1. Extra hinge pins are included for repairing the hinges.

Place the branch into the slot of the bracket.

2. Insert a new hinge pin through the hole and secure

using the retainer washer. (See Fig. D)

TROUBLESHOOTING TIPS

Each tree includes hinge pins/washers, and for pre-lit trees spare bulbs are also included. If extra parts are

needed, please contact our customer service center.

SPARE PARTS

HOW TO USE THE DUAL COLOR LIGHT CONTROLLER :

Press the selector button on the “Dual Color Light Controller” to

select among: (1) CLEAR AND MULTI-COLOR ALTERNATING;

(2) CLEAR LIGHTS; (3) MULTI LIGHTS and (4) TURN OFF BOTH

LIGHTS.

Light

Controller

Selector

Button

IMPORTANT SAFETY INSTRUCTIONS

When using electrical products, basic precautions should always be followed including the following:

a. READ AND FOLLOW ALL SAFETY INSTRUCTIONS.

b. Do not use seasonal products outdoors unless marked suitable for indoor and outdoor use.When

products are used in outdoor applications, connect the product to a Ground Fault Circuit Interrupting

(GFCI) outlet. If one is not provided, contact a qualified electrician for proper installation.

c.This seasonal use product is not intended for permanent installation or use.

d. Do not mount or place near gas or electric heaters, fireplaces, candles or other similar sources of heat.

e. Do not secure the wiring of the product with staples or nails, or place on sharp hooks or nails.

f. Do not let lamps rest on the supply cord or on any wire.

g. Unplug the product when leaving the house, when retiring for the night, or if left unattended.

h.This is not a toy. For decorative use only! To avoid risk of fire, burns, personal injury and electric shock it

should not be played with or placed where small children can reach it.

i. Do not use this product for other than its intended use.

j. Do not hang ornaments or other objects from cord, wire, or light string.

k. Do not close doors or windows on the product or extension cords as this may damage wire insulation.

l. Do not cover the product with cloth, paper or any material not part of the product when in use.

m.This product is equipped with push-in type lamps. Do not twist lamps.

WARNING

1. Use only the adaptor supplied with this product. Using a different adaptor will damage the lights

and cause fire, electrical shock hazards.

2. FOR INDOOR USE ONLY.

3.The external flexible cable or cord of this luminaire cannot be replaced; If the cord is damaged,

the luminaire shall be destroyed.

ASSEMBLY INSTRUCTIONS MADE IN CHINA

CUSTOMER SERVICE FOR CHRISTMAS TREES

For any questions, assistance, or missing parts, Do Not Return To Place Of Purchase. Please contact

us at 1-888-919-0070 or visit our website at www.polygroupstore.com. One of our customer service

representatives will be happy to assist you.

TREE ID# IS LOCATED ON END PANEL OF BOX.TREE ID# IS REQUIRED WHEN REQUESTING REPLACEMENT PARTS.

Customer Name:

Address(No P.O. Boxes):

City & State:

Zip Code:

Day Phone:

Date Purchased:

Tree ID#:

Tree UPC#:

Store Purchased:

Specify Problem:

n. Read and follow all instructions that are on the product or provided with the product.

o. SAVE THESE INSTRUCTIONS

USER SERVICING INSTRUCTIONS

Lamp Replacement

Step 1.

Unplug from power source, by pulling out the adaptor itself - do not pull on the power cord.

(For reference only)

Step 3. Replace with a new spare

LED lamp (included).

Step 2. Lift up the lamp lock tab,

and pull the bulb and its

plastic base straight out

from the lampholder.

CAUTION:

1. Risk of fire. Use only the power adaptor provided with this product. Do not replace lamps with other

than the spare lamps provided with this product.

2.To reduce the risk of fire and electric shock:

a. Do not mount or support light strings in a manner that can cut or damage wire insulation, and

b. Use only the power supply cord provided with this product.
