Enterprise Mobility
PM451
User Manual
For AndroidTM 9
Google, Android, Google Play and other marks are
trademarks of Google LLC.
Copyright © 2006 – 2020
Point Mobile Co., Ltd. All rights reserved
PM451 Android 9.0 User Manual
1
© 2006 –2020 POINTMOBILE Co., Ltd. All rights reserved
Instruction
This manual provides information about basic features and using the PM451. Please read this manual
carefully before using your handy terminals and peripherals to ensure safe and proper use.
Revision History
Revision
Date
Description
V01
26 June 2020
Initial release.
V02
21 Jul 2020
Added mark of microphone and speaker location in Device Parts figures
Note: Screenshots in this manual may differ from actual screens.
PM451 Android 9.0 User Manual
2
© 2006 –2020 POINTMOBILE Co., Ltd. All rights reserved
Table of Contents
INSTRUCTION ..........................................................................................................1
Revision History.......................................................................................................................1
TABLE OF CONTENTS.............................................................................................2
GETTING STARTED .................................................................................................5
Device Parts ............................................................................................................................5
Product Standard Accessories.................................................................................................7
Setup .......................................................................................................................................8
Install & Remove Battery......................................................................................................8
Remove the battery ....................................................................................................................8
Install the battery........................................................................................................................9
Install SIM card & SD card..................................................................................................10
Charge the device ..............................................................................................................11
Battery Specification.................................................................................................................11
LED Indicator............................................................................................................................12
Turn on & off the PM451.....................................................................................................13
Turn on.....................................................................................................................................13
Turn off.....................................................................................................................................14
Battery Hot Swap......................................................................................................................14
Use a touch screen................................................................................................................15
LEARNING THE BASICS........................................................................................17
Setup Wizard.........................................................................................................................17
Home Screen.........................................................................................................................18
Status Bar...........................................................................................................................19
Status icons..............................................................................................................................19
Notification Icons......................................................................................................................20
Notification Panel......................................................................................................................20
PM451 Android 9.0 User Manual
3
© 2006 –2020 POINTMOBILE Co., Ltd. All rights reserved
Quick Setting Panel..................................................................................................................21
Apps & Widget....................................................................................................................22
App Folder................................................................................................................................22
App Drawer ..............................................................................................................................23
Favorites Tray...........................................................................................................................23
Organize App in Home screen..................................................................................................24
Widget......................................................................................................................................24
Recently Used Apps.................................................................................................................26
MTP Connection with PC.......................................................................................................27
Manage Files and Folders .....................................................................................................28
Settings..................................................................................................................................30
Adjust Display Brightness...................................................................................................30
Adjust Sound......................................................................................................................30
Use Keyboard Backlight .....................................................................................................31
Adjust Font Size .................................................................................................................31
Use a Camera........................................................................................................................32
SCANNER...............................................................................................................33
Turn on the Scanner..............................................................................................................33
ScanSettings..........................................................................................................................33
Basic...................................................................................................................................34
Options...............................................................................................................................35
Notification..........................................................................................................................35
Wedge................................................................................................................................36
Extended Wedge......................................................................................................................36
Symbologies.......................................................................................................................39
About..................................................................................................................................39
Scan a barcode......................................................................................................................40
ScanDemo..........................................................................................................................41
WIRELESS..............................................................................................................42
Mobile Network (LTE SKU Only)............................................................................................42
PM451 Android 9.0 User Manual
4
© 2006 –2020 POINTMOBILE Co., Ltd. All rights reserved
Wi-Fi ......................................................................................................................................43
Bluetooth................................................................................................................................44
NFC .......................................................................................................................................45
SYSTEM MAINTENANCE.......................................................................................46
System Information ...............................................................................................................46
On Settings.........................................................................................................................46
On EmKit............................................................................................................................46
OS Update.............................................................................................................................47
OS Update via Storage.......................................................................................................47
OS update from OTG Port..................................................................................................48
OS update via FOTA..........................................................................................................48
Factory Data Reset................................................................................................................50
Factory Data Reset via Settings app..................................................................................50
Factory Data Reset via Recovery mode.............................................................................51
GUN HANDLE.........................................................................................................52
Attach Gun Handle.................................................................................................................52
USING THE KEYPAD..............................................................................................54
Numeric Keypad ....................................................................................................................54
Alpha/Numeric Keypad..........................................................................................................57
Function/Numeric Keypad......................................................................................................60
Functions...............................................................................................................................63
Program Buttons....................................................................................................................64
Microphone............................................................................................................................65
SAFETY INFORMATION.........................................................................................66
PM451 Android 9.0 User Manual
5
© 2006 –2020 POINTMOBILE Co., Ltd. All rights reserved
Getting Started
Device Parts
No
Name
Description
1
Front LED indicators
Indicate the power status and notification. See LED Indicator.
2
Display
Display all operating screen
3
Keypad
For detail information, refer to Using the Keypad
4
Microphone
Use for communications. Find the location on the other keypad
type in Microphone
5
I/O connector
Pogo 7 pin type I/O connector
6
Battery lock (Left)
Press to release the battery from PM451. For more detail, see
Install & Remove Battery
7
Scan button (Left)
Scan a barcode by pressing
8
USB connector with cap
USB 2.0 Type C / OTG
9
Center LED indicator (Left)
Indicates success/failure of barcode reading. See LED
Indicator
Figure 1 PM451 front view
PM451 Android 9.0 User Manual
6
© 2006 –2020 POINTMOBILE Co., Ltd. All rights reserved
Getting Started
No
Name
Description
1
Scanner & Top camera
Scan a barcode and take a photo
2
Speaker
Provide system and multimedia sound
3
Gun handle
connection part
Plug the gun handle. Refer to Gun Handle.
4
Battery
Provide power to device
5
Battery lock (Right)
Press to release the battery from PM451. For more detail, see
Install & Remove Battery
6
Scan button (Right)
Scan a barcode by pressing
7
Center LED indicator (Right)
Indicates success/failure of barcode reading. See LED
Indicator
8
Power button
Press to turn on/off the device or the screen
Figure 2 PM451 Back view
PM451 Android 9.0 User Manual
7
© 2006 –2020 POINTMOBILE Co., Ltd. All rights reserved
Getting Started
Product Standard Accessories
The following items are in the product box.
Accessory
Name
Extended battery pack (5,700mAh)
AC/DC power supply
Country plug (UK / US / EU / KR plug)
USB type C cable
Stylus pen and tether
LCD protection film
Handstrap
PM451 Android 9.0 User Manual
8
© 2006 –2020 POINTMOBILE Co., Ltd. All rights reserved
Getting Started
Setup
Install & Remove Battery
Remove the battery
1. Press and hold left & right battery lock simultaneously to release the battery
2. Pull up the bottom of the battery to remove from the device and release the battery lock
Figure 3 Press battery lock
Figure 4 Remove battery
PM451 Android 9.0 User Manual
9
© 2006 –2020 POINTMOBILE Co., Ltd. All rights reserved
Getting Started
Install the battery
Insert the top of the battery first, and then push down the bottom. Make sure the battery is attached
firmly.
Figure 5 Install battery
