PNI PT802P Manuel utilisateur
PNI PT802P
Switch Wifi circuit breaker
Tuya app P2P
Quick Start Guide / Ghid rapid de congurare
EN User manual ............................................. 2
RO Manual de utilizare ................................... 9
EN
2
1. ABOUT PNI PT802P WIFI CIRCUIT BREAKER
Product introduction and main features:
PNI PT802P product is an inteligent circuit breaker intended for residential or industrial use to remotely
switch ON or OFF a circuit, delay or program a certain connection. Also it has classic functions of a circuit
breaker: to protect from from overload and short circuit .
The breaker can be installed in any standard Circuit Panel because it has standard DIN dimensions and
rail connection.
● Standard DIN dimensions ● Delay, Timer functions
● 2 poles connection ● Wireless conection
● Status LED ● Oine Notication function
● Tuya Smart iOS & Android App
2. SMART BREAKER INSTALLATION
WARNING: - Installation must be made only by authorized electrician.
Important conditions:
Strictly follow the front diagram wiring operation: the Neutral Line and Phase Line must be connected to
corresponding position.
Connect the product to a 230V power supply according to diagram;
- First configuration of product should be made with breaker closer to the Internet source / Router device;
Search for “Tuya Smart” app for iOS/Android Smartphones in App Store/Google Play store, or
scan the below QR code to download and install dedicated app:
3. REGISTER / LOG IN WITH EXISTING ACCOUNT
3.1 Register
If you don not have a Tuya App account yet, you can register an account or log in via personal e-mail
or personal phone number using a verication code procedure. Please read and follow next steps for the
description of registration process:
EN
3
3.2 Register
If you have already registered an account, you can skip the creating a new account,click “Log in with
existing account”, enter the log in page.
(1) The system automatically select the current Country/Region, or you can manually select the Country/
Region.
(2) Enter your registered e-mail address or mobile number enter your password to log in the system.
If your phone has installed WeChat App or QQ App, click WeChat/QQ icon in the log in with social media
acount area. After accessing the authorization page, and lled in received code from your e-mail/phone log in
the system.
EN
4
4. ADD DEVICE
4.1 Product description
LED explanation:
- Blue led On - Breaker ON Position
- Blue led O - Breaker O Position
- Red led blinking quickly - product in pairing mode
- Red led On - Product paired, connected to wi and connected in the application
- Red led O - Product unpaired / disconnected from Wi and deleted from the application.
- Red + Blue = Purple
Red Switch explanation: Quick/Compatible
This multifunction switch allows the initial conguration of the device, and its reset / deletion.
Set device into pairing mode
- Move the Switch from Compatible to the Quick position, wait 10 seconds
- Switch the Switch from the Quick position to the Compatible position
- The red LED starts ashing quickly, which conrms that product was reset and enters pairing mode
- This mode has a limited time period. Please restart if mode ends.
Reset / disconnect / delete procedure
- Move the Switch from Compatible to the Quick position, wait 10 seconds
- Switch the Switch from the Quick position to the Compatible position
- The red LED starts ashing quickly, which conrms that product was reset and enters pairing mode
- This procedure also deletes product from Tuya App .
4.2 Compatibility pairing mode (Recommended)
The product only support 2.4GHz Wi-Fi network. It does not support 5GHz Wi-Fi network. Before
conguring Wi-Fi, please check and conrm you have a 2.4 GHz network, and activate GPS Location on
your phone. The Wi-Fi password should not contain special characters of ~!@#$%^&*(). When conguring
Wi-Fi, make sure your router, mobile and device are as close as possible for a quick conguration of the
device.
Connect smartphone to this Wi-Fi 2.4 GHz router with internet access. Activate GPS location from phone.
If any of this condition are not met conguration will fail.
● App supports EZ-Mode and AP mode connection ( Figure 4). This Compatibility procedure uses only EZ-
Mode by default.
EN
5
● When the mobile phone is connected to Wi-Fi, click “Add Device” or “+“ icon (right upper corner) on the
Home screen of the App, select “Electrician”(gure 1)→ “Breaker(Wi-Fi)”
● Check Wi-Fi network name and enter Wi password, click “Next” (gure 2).
Figure 1 Figure 2 Figure 3
● Set device into pairing mode acording to described procedure. Check “Conform indicator rapidly blink“ and
click Next. ( Figure 3)
Figure 4 Figure 5 Figure 6
EN
6
● The pairig conguration and connection to wi is carried out ( Figure 5).
● Device added successfully (gure 6), you can choose the device name and room scene.
4.3 AP mode Connection is an alternative that can be selected from Figure 3 Step from Right
Corner. After selecting this procedure you must folloy the On-screen steps.
● To Switch Device into AP Pairing mode you must se breaker into pairing mode rst. With RED led blinking
quick you must move again the RED Switch from Compatible to Quick mode and from Qiock to Compatible
mode in maximum 10 seconds. Wait for 5 seconds and Breaker will conrm it has entered AP mode pairing
when RED led Blinks slowly.
● Follow on screen procedure.
5. FUNCTION DESCRIPTION
Real-time preview interface
1. Setting & Management
2. Main switch
3. Switch Button
4. Timer Button
5. Countdown Button
6. CLICK “ 1 “ IN THE UPPER RIGHT CORNER OF THE CONTROL PAGE FOR THE MANAGEMENT
AND SETTING OF THE DEVICE.
● Device Name - can modify the device name and device location;
● Device Information - to view: Device ID, Wi-Fi signal strength, IP address, Mac address, Device time zone.
● Tap-to-Run and Automation - View automations and scenaries created for this device
● Third Party Control - Compatible smart services
● Offline Notification - Activates an alarm is camera goes Offline
● Share Device - can share this device to other people, enter the people’s e-mail or mobile phone number;
(Note: the entered e-mail / mobile phone number should be registered with a Tuya App account).
EN
7
● Create Group - Devices under same group can be controlled simultaneously
● FAQ & Feedback - Questions and solutions for any problems with product behaviour.
● Add to home screen - Add a shortcut to this device to your phone’s home screen
● Check Device Network -check the quality of the network connection
● Check for Firmware Update - Support OTA Remote Upgrade (Do not disconnect during upgrading).
7. CLICK “ME” ON THE HOME SCREEEN OF TUYA APP FOR MORE SERVICES
1. Home Management
2. Message Center
3. FAQ & Feedback
4. More Services
- Free Services: IFTTT , Google Assistant, Alexa, etc;
- Value-added Services : you can check the purchasing record of purchased value-added services: Cloud
Storage for Cameras, AI Filtered Notications etc;
5. Settings and informations for your Tuya app account: Sound, Notications, Network, Cache
8. FREQUENTLY ASKED QUESTIONS
Q:Indicator light is not ON :
A:Under normal conditions the Blue indicator light will be on when Breaker is On, and will be o when
breaker is O .
Q:Indicator light is O no mather the Breaker position
A:Check product Input . Check if supply voltage is normal. Check is connection diagram is correct ( Null line
and phase line).
9. PRODUCT SPECIFICATIONS
Nume PT802P
APP Tuya Smart / SmartLife
Input Voltage AC 230V
Output Voltage AC 230V
Number of poles 2P
Rated current 100 A
Rated short-circuit breaking
capacity
Icn=6kA Ics=6kA
Applicable places 2P usually for home & shop use
Switch mode Manual Switch / Smartphone remote switch
WiFi Standards IEEE 802.11 b/n/g 2.4G Hz
WiFi frequency 2.4GHz
Transmission power 100mW
Support Voice Control Compatible with Amazon Alexa / Google Assistant
Installation DIN Rail
Operating temperature –25°C to +65°C
Humidity 5%--95% non-condensing
Dimensions 87x79x55 mm
Weight 333 g
RO
8
1. DESPRE SIGURANTA AUTOMATA WIFI PNI PT802P 1080P DISJUNCTOR
Introducere produs si caracteristici principale:
Produsul PNI PT802P este o siguranta automata inteligenta destinata utilizarii rezidentiale sau
industriale pentru a porni sau opri de la distanta un circuit, intarzia sau programa o anumita alimentare de
curent. De asemenea produsul are si functiile clasice ale unei sigurante automate: protectie la suprasarcina
si scurtcircuit.
Intrerupatorul poate instalat in orice panou/tablou de sigurante si circuite standard, deoarece are
dimensiuni DIN standard si conexiune pentru sina de tablou.
● dimensiune DIN standard ● Functii de intarziere si temporizare
● Conexiune 2 poli ● Conexiune wireless
● LED stare ● Functie de noticare dispozitiv Oine
● Aplicatie Tuya Smart pentru iOS & Android
2. INSTALARE SIGURANTA AUTOMATA
AVERTISMENT: - Instalarea trebuie facuta numai de catre electrician autorizat.
Conditii importante:
Urmati cu strictete operatia de cablare conform schitei de la punctul 4.1: Firul de nul si firul de faza trebuie
conectate la pozitia corespunzatoare.
Conectati produsul pe un circuit / o sursa de alimentare de 230V conform schemei;
- Prima configurare a produsului ar trebui sa fie facuta cu siguranta mai aproape de sursa Internet /
dispozitivul Router;
Cautati aplicatia „Tuya Smart” pentru smartphone-uri iOS / Android in App Store / magazin Google
Play sau scanati codul QR de mai jos pentru a descarca si instala aplicatia dedicata:
3. INREGISTRARE / CONECTATI-VA CU UN CONT EXISTENT
3.1 Inregistrare
Daca nu aveti inca un cont in aplicatia Tuya, puteti sa va inregistrati/creati un cont sau sa va autenticati
prin e-mail personal sau prin numarul de telefon personal, folosind o procedura cu cod de vericare. Cititi si
urmati pasii urmatori in care este descris procesul de inregistrare:
RO
9
3.2 Inregistrare
Daca aveti deja un cont in aplicatia Tuya, puteti sari peste crearea unui cont nou si faceti clic pe „Log in
with existing account” pentru a accesa pagina de autenticare.
(1) Sistemul selecteaza automat Tara / Regiunea curenta sau puteti selecta manual Tara / Regiunea.
(2) Introduceti adresa dvs. de e-mail inregistrata sau numarul mobil si o parola pentru a va autentica in
sistem.
Daca telefonul dvs. are instalata aplicatia WeChat sau QQ App, faceti clic pe pictograma WeChat / QQ in
zona de logare cu un cont de social media. Dupa ce ati accesat pagina de autorizare si ati completat codul
primit pe e-mail / telefon puteti sa accesati contul dumneavoastra.
RO
10
4. ADAUGARE / IMPERECHERE DISPOZITIV
4.1 Descriere produs
LED detaliere:
- Led albastru aprins - Siguranta pe pozitia ON ( pornit)
- Led albastru stins - Siguranta pe pozitia OFF (oprit)
- Led rosu clipeste rapid - produs in modul de asociere/imperechere
- Led rosu aprins - Produs imperecheat/asociat, conectat la wi si conectat in aplicatie
- Led rosu oprit - Produs deconectat de la Wi si sters din aplicatie.
- Rosu aprins + Albastru aprins = Violet
Explicatia comutatorului rosu: rapid / compatibil
Acest comutator multifunctional permite congurarea initiala a dispozitivului si resetarea / stergerea
acestuia.
Setati dispozitivul in modul de asociere/imperechere
- Mutati comutatorul de la pozitia compatibil la pozitia quick, asteptati 10 secunde
- Mutati din nou comutatorul din pozitia quick in pozitia compatibil
- LED-ul rosu incepe sa clipeasca rapid, ceea ce conrma faptul ca produsul a fost resetat si intra in modul
de asociere/imperechere
- Acest mod are o perioada limitata de timp. Va rugam sa reporniti daca timpul se termina.
Procedura de resetare / deconectare / stergere
-- Mutati comutatorul de la pozitia compatibil la pozitia quick, asteptati 10 secunde
- Mutati din nou comutatorul din pozitia quick in pozitia compatibil
- LED-ul rosu incepe sa clipeasca rapid, ceea ce conrma faptul ca produsul a fost resetat si intra in modul
de asociere/imperechere
- Aceasta procedura sterge, de asemenea, produsul si din aplicatia Tuya.
4.2 Procedura de asociere/imperechere mod compatibil (recomandat)
Produsul accepta doar reteaua Wi-Fi de 2,4 GHz. Nu accepta reteaua Wi-Fi de 5 GHz. Inainte de a
incepe imperecherea Wi-Fi, vericati si conrmati ca aveti o retea de 2,4 GHz si activati Locatia GPS pe
telefon. Parola Wi-Fi nu trebuie sa contina caractere speciale de tipul: ~! @ # $% ^ & * (). Cand faceti
imperecherea Wi-Fi, asigurati-va ca routerul, mobilul si dispozitivul sunt cat mai aproape posibil pentru o
congurare rapida a dispozitivului.
Conectati smartphone-ul la acest router Wi-Fi de 2,4 GHz cu acces la internet. Activati locatia GPS de pe
telefon. Daca oricare dintre aceste conditii nu este indeplinita, conguratia va esua.
● Aplicatia accepta 2 moduri de conectare EZ-Mode si AP (Figura 4). Aceasta procedura de imperechere
utilizeaza numai modul EZ in mod implicit.
Autres manuels pour PT802P
1
Table des matières
Langues :
Autres manuels PNI Changer
PNI
PNI SmartHome SM433 Manuel utilisateur
PNI
PNI SH101 Manuel utilisateur
PNI
PNI CS101 Manuel utilisateur
PNI
PNI SH101 Manuel utilisateur
PNI
PNI ES100 Manuel utilisateur
PNI
PNI Safe House PG08 Manuel utilisateur
PNI
PNI CT25WIFI Manuel utilisateur
PNI
PNI SH121 Manuel utilisateur
PNI
PNI ES100 Manuel utilisateur
PNI
PNI SafeHome PT141D Manuel utilisateur
