Plantronics BT300 Manuel utilisateur

GUIDE DE DÉMARRAGE RAPIDE

GUÍA DE INICIO RÁPIDO

GUIA DE INÍCIO RÁPIDO

QUICK START GUIDE

B230 Bluetooth System

Voyager®PRO UC v2

BT300

Micro USB

Charger

BT300 USB Adapter

Voyager PRO UC

USB Charging Cable

Soft Gel Eartips (Small & Large) and

Foam Eartip Covers

Carry Case

What’s in the box

Headset controls

345

1 Volume/Mute button

Increase/decrease volume

Mute mic during a call

Pause/Play streaming audio

Tap + or – button per level change

1-second press of both + and – buttons

2Call button

Take a call or end it

Call back last call

Initiate phone’s voice-dialing

Reconnect lost connection

1 tap

2 taps

2-second press until tone heard

1 tap

3 Micro USB charging port 90 minutes for full charge

4 Power button

On or off

Talk time voice alert

Activate pairing mode

2-second press

1 tap

With headset off press until LED ﬂashes red/blue

5 LED

Charging

Battery status

Pairing mode

Solid red. When fully charged, LED is off.

Low = 2 red ﬂashes, Recharge = 3 red ﬂashes

Flashes red/blue

AUTO CALL ANSWER:automatically answer a mobile or softphone call by putting on the

headset. You do not have to press the call button. See Smart Sensor Features.

#1 change

Smart Sensor Features

Auto Answer Call:

When you are not wearing

your headset.

When you have an incoming call on

your mobile or softphone, put on the

headset and the call will be answered

automatically. You do not have to

press the call button.

Auto Pause Media:

When you are listening to

streaming audio.

When you are streaming audio from

your mobile phone or PC. Remove

the headset and the streaming audio

pauses. Place your headset back on

and the audio resumes.

NOTE If the media player has been

playing less than 10 seconds you will have

to manually restart the media player.

Auto Transfer Call:

Whether you are wearing your

headset or not.

If you are not wearing your headset

and there is an incoming call on

your mobile phone, the audio will be

routed to the mobile phone. When

you put the headset on, the audio will

be automatically transferred to the

headset and will auto answer.

If you are already wearing your

headset and there is an incoming call,

the audio will be routed to the headset

and you will need to press the call

button to answer the call.

Auto Lock Call Button:

When you are not wearing

your headset

Prevents accidental dialling from your

mobile phone.

NOTE These features are enabled by default and can be disabled in the

Plantronics Control Panel: Devices>Device Settings>Headset Tab. Changes to the

device settings requires that you are connected and within range of the USB

adapter. The Plantronics software must be downloaded to access the Control

Panel. Refer to Step 1 Set up your headset and computer.

#3 change

#2 change

#4 change

Step 2 Connect your headset and USB adapter

Pair your headset

VoyagerPRO UC v2

  

Ready1

Activate the Bluetooth feature on your phone, then use the phone’s settings

to add/search/discover new Bluetooth devices.

BlackBerry® Settings/options > Bluetooth: On > Search for devices.

iPhone Settings > General > Bluetooth > On (starts the search for devices)

Android Phone Settings > Wireless > Bluetooth: On > Scan for devices

Set2

To activate Bluetooth pairing mode, press and hold the power button until

LED ﬂashes red/blue to indicate pairing mode.

Connect3

Select• Voyager PRO UC from the list of Bluetooth devices shown on your

phone.

If phone asks for a passcode, enter four zeros• 0000. You may see **** on

screen.

Some phones also ask to conﬁrm headset connection after pairing.•

Headset LED will stop ﬂashing red/blue once your phone and headset are•

successfully paired/connected.

Step 1 Set up your headset and computer

Install the software

Download and install the Plantronics software at plantronics.com/software.

NOTE You must be connected to the internet in order to access the software.

Once the software is installed, Windows users can access the utility by

selecting Start > Programs > Plantronics > Plantronics Control Panel.

Charge your headset

To calibrate your headset and provide optimal

performance fully charge the headset before using.

The headset LED will be solid red to indicate that

the headset battery is charging. When fully charged

the LED goes off.

NOTE To charge the headset with USB charging cable the PC must be on and in

an active state.

Reset Smart Sensors

To reset the Smart Sensors, connect the headset to the charger and place the

headset on a ﬂat nonmetallic surface for 10 seconds.

 

30 min ...........................

Minimum charge

before ﬁrst use

1.5 hours ......................................

Full charge

#5 change

Step 3 Fit your headset

The headset comes conﬁgured for the right ear, with the medium eartip

installed, however you can replace it with the small or large eartip provided.

For the best sound clarity and comfort, make sure you have a secure ﬁt.

Replace the eartip for a better ﬁt

Grip the eartip and gently push it into the speaker housing.1

Rotate it a quarter turn to the left to unlock.2

Pull the eartip away from the headset.3

Attach a new eartip

Align the tabs on the eartip with the slots on the speaker housing.4

Gently push the eartip into housing while turning it a quarter turn to the5

right. The eartip will stop rotating when it is locked.

You may want to add a foam eartip cover for additional comfort.

USB adapter set-up

Your Bluetooth adapter is pre-paired to your headset.

NOTE refer to the complete user guide located at plantronics.com/support if you

need to re-pair. On the support page, click the Product Documentation tab and then

enter the model number or product name in the search ﬁeld.

Power on the headset1

Insert the USB adapter directly into the laptop or PC.2

NOTE Do not insert directly into a docking station.

The LED will become solid blue to indicate the adapter is powered on and is

connected to the headset.

USB Adapter LED indicators

Headset powered off None

Paired/connected Solid blue

Active call Flashing blue

Streaming audio Flashing blue

Step 4 Making calls with your softphone

You can make softphone calls with your computer using your Bluetooth

adapter which comes automatically paired with your headset.

Ensure the headset is powered on.1

Insert the USB adapter into USB Port on the PC. The LED on the adapter will2

ﬂash blue to indicate the adapter is connecting to the headset. The LED will

become solid blue to indicate the adapter is powered on and is connected to

the headset.

Check the audio settings in the softphone application to make sure that the3

speaker and microphone are set to the BT300 adapter.

To place a call using your softphone, dial the number or choose a contact4

using your softphone program. The audio connection to your headset will

activate automatically when your recipient’s phone begins to ring. The LED

on the adapter will slowly ﬂash blue while you are on an active call.

Learn More

To learn more about your system features, change default settings or read

troubleshooting tips, refer to the user guide online at plantronics.com/

documentation. You can also view online FAQ at plantronics.com/support.

Technical support is available at USA: 1.866.363.BLUE (2583).

Wearing the headset

Guide the earloop behind your ear and position the headset so that the1

speaker and eartip rest comfortably in your ear.

Pivot the boom up to point the microphone toward the corner of your mouth.2

Quick-turn adjustment for the left ear

Pivot the boom into an upright position.1

Rotate the boom and speaker to the other side of the headset and lower it2

before ﬁtting your other ear.

#6 change
